zPix
300
Digital Microscope
PRODUCT SPECIFICATION
Optics:
5.3x Zooms Lens System
Weight: 0.337 lbs
OPTICAL SPECIFICATION
Effective Magnification*:
90x-480x @ 27" Screen
108x-569x @ 32" Screen
*Please note, the effective magnification is a combination of the optical system and high powered digital zoom based upon the above screen sizes.
PACKAGE CONTENTS
Digital
Microscope
SETTING UP
1. Pressing the slide release button will open
the arms so you can position your slide
on the specimen stage. Once positioned,
release the button and the arms will
secure the slide in place.
DOWNLOAD AND CONNECT THE DEVICE
• Go to www.carson.com/zpic940 to download and install the latest Xploview software for your operating system.
• Connect device to a computer using the attached USB cable. The LED light will turn on indicating that the device is
powered on.
• When device is connected to the computer for the first time, a driver will automatically be installed by Windows or Mac OS.
Dimensions: 4.72" x 3.14" x 3.38"
Illumination:
LED
Image Sensor Format:
Image Resolution:
2.0M Pixel UXGA
1600 x 1200 Pixels
CMOS
(UXGA)
1 Prepared
3 Blank
Cotton Swatch
Specimen
Slide
Slides
Tweezers
Dropper
CUSTOMER SERVICE:
If you experience any difficulties, please
contact us and we will be happy to help you.
Effective Viewing Area:
4.96 mm x 3.72 mm
(without zoom)
0.93 mm x 0.70 mm
(at max zoom)
PRODUCT OVERVIEW
1
Shutter Button
2
Focus Ring
3
Zoom Ring
5
Specimen Slide
Release Button
2. Attach microsc
body to base.
Power Ratings:
5V DC 250mA
USB 2.0/3.0
4
LED
7
Specimen Stage
ope
MM-940
6
USB Cable
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the zPix 300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Carson zPix 300

  • Page 1 DOWNLOAD AND CONNECT THE DEVICE • Go to www.carson.com/zpic940 to download and install the latest Xploview software for your operating system. • Connect device to a computer using the attached USB cable. The LED light will turn on indicating that the device is powered on.
  • Page 2 ZOOMING FOCUSING TAKING PHOTOS Slowly rotate Zoom Ring clockwise or Slowly rotate Focus Ring clockwise or To take a quick image, counterclockwise to zoom in or out. Adjust counterclockwise until viewing image shown press the shutter button.* focus ring if necessary. on the monitor is clear and sharp.
  • Page 3 CUSTOMER SERVICE: If you experience any difficulties, please contact us and we will be happy to help you. www.carson.com Carson Optical 2070 5th Avenue, Ronkonkoma, NY 11779 | Tel: 631-963-5000 For warranty information, visit www.carson.com/warranty...
