Time4Sleep ESSENTIALS Assembly Instructions Manual page 2

Parts Checklist
PACK
1/1
1 Top Panel
2 Left Side Panel
3
Right Side Panel
4 Left Decor Panel
Right Decor Panel
5
Plinth
6
Bottom Rail
7
8
Back Rail
Fittings Checklist
Code Description
Metal Cam Dowel
a
(Ø7 x 40mm )
Cam Lock ( Ø 15 x 12mm )
b
Thin Thread Metal Cam Dowel
c
(Ø5 x 34mm )
d Cam Lock ( Ø12 x 10mm )
e
Wooden Dowel ( Ø 8 x 30mm )
f Wooden Dowel ( Ø 6 x 30mm )
g
Screw ( Ø 4 x 35 mm )
h Screw ( Ø 3.5 x 12 mm )
j
Screw ( Ø 3 x 16 mm )
k
Back Panel Support Fitting
l ( Ø 12 x 5 mm )
Foot Pad
HARDWARE NEEDED FOR CABINET ASSEMBLY
Qty
x16
x16
x4
x4
x14
x8
x8
x28
x6
x6
x4
Page 2 of 19
Qty
1 Back Panel
9
10
1 Upper Cross Rail
Drawer Left Side Panel
1 11
Drawer Right Side Panel
12
1
Drawer Back Panel
13
1
Drawer Base
14
1
15 Drawer Front
1
1
Code Description
m Handle
n
Screw ( Ø 4 x 25mm )
Drawer slide Set
CL CR DR
Qty
1
1
2
2
2
2
2
Qty
x2
x4
x2
DL
