Summary of Contents for Giatsu AROMA 2E GIA-S09AR2E-R32
Page 1
AROMA 2E GIA-S09AR2E-R32 GIA-S12AR2E-R32 GIA-S18AR2E-R32 GIA-S24AR2E-R32 Manual instalación. Split 1x1 Installation manual. Split 1x1 Manuel d’installation. Split 1x1 Manual de instalação. Split 1x1 Manuale d'installazione. Split 1x1 + info Por favor lea atentamente este manual antes de usar este producto | Please, read carefully this manual before using the product | Avant d’utiliser l’équipement, lisez attentivement les instructions | Por favor leia atentamente este manual antes de usar o equipamento | Per favore leggere attentamente questo manuale prima di utilizzare questo prodotto Gracias | Thank you | Merci | Obrigado | Grazie...
Page 3
AROMA 2E GIA-S09AR2E-R32 | GIA-S12AR2E-R32 | GIA-S18AR2E-R32 | GIA-S24AR2E-R32 ENGLISH Installation manual. Split 1x1...
INSTALLATION MANUAL SPLIT 1X1 AROMA 2E THANK YOU Thank you for choosing our products and we greatly appreciate your trust in us. This is the Split Aroma 2E, which combines silent operation with its high energy efficiency and a design that adapts harmoniously to any environment.
INSTALLATION MANUAL SPLIT 1X1 AROMA 2E 0. SAFETY PRECAUTIONS Read safety precautions before operation and installation Improper installation due to ignoring instructions can cause serious damage or injury. The severity of possible damage or injury is classified as a WARNING or CAUTION. WARNING CAUTION This symbol indicates the...
SPLIT 1X1 AROMA 2E INSTALLATION MANUAL 0. SAFETY PRECAUTIONS CLEANING AND MAINTENANCE WARNINGS • Turn off the device and turn off the power before cleaning. Otherwise, it may cause an electric shock. • Do not clean the air conditioner with excessive amounts of water. •...
Page 8
INSTALLATION MANUAL SPLIT 1X1 AROMA 2E 0. SAFETY PRECAUTIONS TAKE NOTE OF THE FUSE SPECIFIATIONS The air conditioning circuit board (PCB) is designed with a fuse to provide overcurrent protection. Fuse specifications are printed on the circuit board, such as: Indoor unit: T3.15AL / 250VAC, T5AL / 250VAC, T3.15A / 250VAC, T5A / 250VAC, etc.
Page 9
SPLIT 1X1 AROMA 2E INSTALLATION MANUAL 0. SAFETY PRECAUTIONS WARNING FOR THE USE OF R-32 REFRIGERANT • When flammable refrigerant is used, the appliance must be stored in a well ventilated area where the size of the room corresponds to the area of the room as specified for its operation. For R-32 refrigerant models: The device must be installed, operated and stored in a room with a surface area greater than 4m2.
INSTALLATION MANUAL SPLIT 1X1 AROMA 2E 1. ACCESSORIES The air conditioning system comes with the following accessories. Use all of the installation parts and accessories to install the air conditioner. Improper installation may result in water leakage, electrical shock and fire, or cause the equipment to fail. Name Shape Quantity...
Page 11
SPLIT 1X1 AROMA 2E INSTALLATION MANUAL 1. ACCESSORIES Name Shape Quantity Owner’s manual Installation manual Remote controller manual WiFi control module manual WARNING Appliance shall be stored in a well -ventilated area where the room size corresponds to the room area as specifiec for operation.
Page 13
SPLIT 1X1 AROMA 2E INSTALLATION MANUAL 2. INSTALLATION SUMMARY – INDOOR UNIT Connect piping (page 73) Connect wiring (page 64) Prepare drain hose (page 61) Wrap piping and cable (not applicable for some locations in the US) (page 66) Mounting of the indoor unit (page 67) ...
INSTALLATION MANUAL SPLIT 1X1 AROMA 2E 3. UNIT PARTS NOTE: The installation must be performed in accordance with the requirement of local and national standards. The installation may be slightly different in different areas. Air-break switch Fig. 3.1. 1. Wall mounting plate 5.
SPLIT 1X1 AROMA 2E INSTALLATION MANUAL 4. INDOOR UNIT INSTALLATION Fig. 3.1-a INSTALLATION INSTRUCTIONS – INDOOR UNIT PRIOR TO INSTALLATION Before installing the indoor unit, refer to the label on the product box to make sure that the model number of the indoor unit matches the model number of the outdoor unit.
INSTALLATION MANUAL SPLIT 1X1 AROMA 2E 4. INDOOR UNIT INSTALLATION Refer to the following diagram to ensure proper distance from walls and ceiling: 15 cm (5,9 in) or more 12 cm (4,75 in) 12 cm (4,75 in) or more or more 2,3 m (90,55 in) or more Fig.
SPLIT 1X1 AROMA 2E INSTALLATION MANUAL 4. INDOOR UNIT INSTALLATION Wall Indoor Outdoor MOUNTING PLATE DIMENSIONS Different models have different mounting plates. In order to ensure that you have ample room to mount the indoor unit, the diagrams to the right show different types of mounting plates along with the following dimensions: •...
Page 18
INSTALLATION MANUAL SPLIT 1X1 AROMA 2E 4. INDOOR UNIT INSTALLATION 398 mm (15,98 in) 228,5 mm (8,99 in) 241 mm (9,48 in) Indoor unit outline Right rear wall hole 65 mm (2,5 in) Left rear wall 45mm (17 in) 183,6mm (7,2 in) 123,6mm (4,86 in) 117,5mm (4,62 in) hole 65 mm 805 mm (31,7 in)
SPLIT 1X1 AROMA 2E INSTALLATION MANUAL 4. INDOOR UNIT INSTALLATION 4.4 PREPARE REFRIGERANT PIPING The refrigerant piping is inside an insulating sleeve attached to the back of the unit. You must prepare the piping before passing it through the hole in the wall. Refer to the Refrigerant Piping Connection section of this manual for detailed instructions on pipe flaring and flare torque requirements, technique, etc.
INSTALLATION MANUAL SPLIT 1X1 AROMA 2E 4. INDOOR UNIT INSTALLATION 4.5 CONNECT DRAIN HOSE By default, the drain hose is attached to the lefthand side of unit (when you’re facing the back of the unit). However, it can also be attached to the right-hand side. 1.
Page 21
SPLIT 1X1 AROMA 2E INSTALLATION MANUAL 4. INDOOR UNIT INSTALLATION BEFORE PERFORMING ELECTRICAL WORK, READ THESE REGULATIONS 1. All wiring must comply with local and national electrical codes, and must be installed by a licensed electrician. 2. All electrical connections must be made according to the Electrical Connection Diagram located on the panels of the indoor and outdoor units.
INSTALLATION MANUAL SPLIT 1X1 AROMA 2E 4. INDOOR UNIT INSTALLATION 4.6 CONNECT SIGNAL CABLE The signal cable enables communication between the indoor and outdoor units. You must first choose the right cable size before preparing it for connection. Cable types: •...
Page 23
SPLIT 1X1 AROMA 2E INSTALLATION MANUAL 4. INDOOR UNIT INSTALLATION PAY ATTENTION TO LIVE WIRE While crimping wires, make sure you clearly distinguish the Live (“L”) Wire from other wires. 2. Open front panel of the indoor unit. 3. Using a screwdriver, open the wire box cover on the right side of the unit. This will reveal the terminal block.
INSTALLATION MANUAL SPLIT 1X1 AROMA 2E 4. INDOOR UNIT INSTALLATION NOTE ABOUT WIRING The wiring connection process may differ slightly between units. 4.7 WRAP PIPING AND CABLES Before passing the piping, drain hose, and the signal cable through the wall hole, you must bundle them together to save space, protect them, and insulate them.
SPLIT 1X1 AROMA 2E INSTALLATION MANUAL 4. INDOOR UNIT INSTALLATION 4.8 MOUNT INDOOR UNIT If you installed new connective piping to the outdoor unit, do the following: 1. If you have already passed the refrigerant piping through the hole in the wall, proceed to Step 4. 2.
INSTALLATION MANUAL SPLIT 1X1 AROMA 2E 5. OUTDOOR UNIT INSTALLATION INSTALLATION INSTRUCTIONS – OUTDOOR UNIT 5.1 SELECT INSTALLATION LOCATION Before installing the outdoor unit, you must choose an appropriate location. The following are standards that will help you choose an appropriate location for the unit. Proper installation locations meet the following standards: •...
SPLIT 1X1 AROMA 2E INSTALLATION MANUAL 5. OUTDOOR UNIT INSTALLATION SPECIAL CONSIDERATIONS FOR EXTREME WEATHER If the unit is exposed to heavy wind: Install unit so that air outlet fan is at a 90° angle to the direction of the wind. If needed, build a barrier in front of the unit to protect it from extremely heavy winds.
INSTALLATION MANUAL SPLIT 1X1 AROMA 2E 5. OUTDOOR UNIT INSTALLATION 5.3 ANCHOR OUTDOOR UNIT The outdoor unit can be anchored to the ground or to a wall-mounted bracket. Unit mounting dimensions: Air inlet The following is a list of different outdoor unit sizes and the distance between their mounting feet.
SPLIT 1X1 AROMA 2E INSTALLATION MANUAL 5. OUTDOOR UNIT INSTALLATION If you will install the unit on a wall-mounted bracket, do the following: CAUTION Before installing a wall-mounted unit, make sure that the wall is made of solid brick, concrete, or of similarly strong material.
Page 30
INSTALLATION MANUAL SPLIT 1X1 AROMA 2E 5. OUTDOOR UNIT INSTALLATION WARNING BEFORE PERFORMING ANY ELECTRICAL OR WIRING WORK, TURN OFF THE MAIN POWER TO THE SYSTEM. 1. Prepare the cable for connection: Use the right cable: • Indoor Power Cable (if applicable): H05VV-F or H05V2V2-F •...
SPLIT 1X1 AROMA 2E INSTALLATION MANUAL 6. REFRIGERANT PIPING CONNECTION 6.1 NOTE ON PIPE LENGTH The length of refrigerant piping will affect the performance and energy efficiency of the unit. Nominal efficiency is tested on units with a pipe length of 5 meters (16.5ft). A minimum pipe run of 3 metres is required to minimise vibration &...
Page 32
INSTALLATION MANUAL SPLIT 1X1 AROMA 2E 6. REFRIGERANT PIPING CONNECTION DO NOT DEFORM THE PIPE WHILE CUTTING Be extra careful not to damage, dent, or deform the pipe while cutting. This will drastically reduce the heating efficiency of the unit. Pipe Step 2: Remove burrs Burrs can affect the air-tight seal of refrigerant piping...
SPLIT 1X1 AROMA 2E INSTALLATION MANUAL 6. REFRIGERANT PIPING CONNECTION 6. Place flaring tool onto the form. 7. Turn the handle of the flaring tool clockwise until the pipe is fully flared. 8. Remove the flaring tool and flare form, then inspect the end of the pipe for cracks or even flaring. Step 4: Connect pipes When connecting refrigerant pipes, be careful not to use excessive torque or to deform the piping in any way.
INSTALLATION MANUAL SPLIT 1X1 AROMA 2E 6. REFRIGERANT PIPING CONNECTION INSTRUCTIONS FOR CONNECTING PIPING TO OUTDOOR UNIT 1. Unscrew the cover from the packed valve on the side of the outdoor unit (see Fig. 5.9) Valve cover Fig. 5.9 2. Remove protective caps from ends of valves. 3.
SPLIT 1X1 AROMA 2E INSTALLATION MANUAL 7. AIR EVACUATION PREPARATIONS AND PRECAUTIONS Air and foreign matter in the refrigerant circuit can cause abnormal rises in pressure, which can damage the air conditioner, reduce its efficiency, and cause injury. Use a vacuum pump and manifold gauge to evacuate the refrigerant circuit, removing any non-condensable gas and moisture from the system.
Page 36
INSTALLATION MANUAL SPLIT 1X1 AROMA 2E 7. AIR EVACUATION 6. Close the Low Pressure side of the manifold gauge, and turn off the vacuum pump. 7. Wait for 5 minutes, then check that there has been no change in system pressure. 8.
SPLIT 1X1 AROMA 2E INSTALLATION MANUAL 8. ELECTRICAL AND GAS LEAK CHECKS ELECTRICAL SAFETY CHECKS After installation, confirm that all electrical wiring is installed in accordance with local and national regulations, and according to the Installation Manual. BEFORE TEST RUN Check Grounding Work Measure grounding resistance by visual detection and with grounding resistance tester.
INSTALLATION MANUAL SPLIT 1X1 AROMA 2E 9. TEST RUN BEFORE TEST RUN Only perform test run after you have completed the following steps: • Electrical Safety Checks - Confirm that the unit’s electrical system is safe and operating properly. • Gas Leak Checks - Check all flare nut connections and confirm that the system is not leaking. •...
Page 39
SPLIT 1X1 AROMA 2E INSTALLATION MANUAL 9. TEST RUN DOUBLE-CHECK THE PIPE CONNECTIONS During operation, the pressure of the refrigerant circuit will increase. This may reveal leaks that were not present during your initial leak check. Take time during the Test Run to double-check that all refrigerant pipe connection points do not have leaks.
INSTALLATION MANUAL SPLIT 1X1 AROMA 2E 10. EUROPEAN DISPOSAL GUIDELINES This appliance contains refrigerant and other potentially hazardous materials. When disposing of this appliance, the law requires special collection and treatment. Do not dispose of this product as household waste or unsorted municipal waste. When disposing of this appliance, you have the following options: •...
SPLIT 1X1 AROMA 2E INSTALLATION MANUAL 11. INFORMATION SERVICING (REQUIRED FOR THE UNITS THAT ADOPT R32 REFRIGERANT ONLY) 1. CHECKS TO THE AREA Prior to beginning work on systems containing flammable refrigerants, safety checks are necessary to ensure that the risk of ignition is minimised. For repair to the refrigerating system, the following precautions shall be complied with prior to conducting work on the system.
Page 42
INSTALLATION MANUAL SPLIT 1X1 AROMA 2E 11. INFORMATION SERVICING • refrigeration pipe or components are installed in a position where they are unlikely to be exposed to any substance which may corrode refrigerant containing components, unless the components are constructed of materials which are inherently resistant to being corroded or are suitably protected against being so corroded.
SPLIT 1X1 AROMA 2E INSTALLATION MANUAL 11. INFORMATION SERVICING not be adequate, or may need re-calibration.(Detection equipment shall be calibrated in a refrigerant-free area.) Ensure that the detector is not a potential source of ignition and is suitable for the refrigerant. Leak detection equipment shall be set at a percentage of the LFL of the refrigerant and shall be calibrated to the refrigerant employed and the appropriate percentage of gas (25% maximum) is confirmed.
Page 44
INSTALLATION MANUAL SPLIT 1X1 AROMA 2E 11. INFORMATION SERVICING c) Before attempting the procedure ensure that: • mechanical handling equipment is available, if required, for handling refrigerant cylinders. • all personal protective equipment is available and being used correctly. • the recovery process is supervised at all times by a competent person. •...
Page 45
SPLIT 1X1 AROMA 2E INSTALLATION MANUAL 11. INFORMATION SERVICING 3. Disposal of equipment using flammable refrigerants. Compliance with national regulations. 4. Storage of equipment/appliances. The storage of equipment should be in accordance with the manufacturer’s instructions. 5. Storage of packed (unsold) equipment. Storage package protection should be constructed such that mechanical damage to the equipment inside the package will not cause a leak of the refrigerant charge.
Page 47
