5. Bit identification input
İki: 6. Bit input
6. Bit identification input
İki: 7. Bit input
7. Bit identification block
#BMB0: Output of the block
Output where bits are combined and written in decimal
1.12.9 Block Settings
There are no block settings.
1.12.10 Block Explanations
It is used to combine a maximum of 8 bits in binary and transfer them to the block output as 1
byte. If all the bits connected to the block input are high (1), the block output takes the maximum
value (255). Of the block inputs, the 0th bit input is for the least significant bit (LSB), and the 7th
Bit input is for the most significant bit (MSB).
