- Page 1 MP110 HARDWARE MANUAL • MP110 PLC Series 12 / 2019 MIKRODEV_HM_MP110_EN v1.3...
-
Page 2: Table Of Contents
General Device Specifications ..............7 INSTALLATION INFORMATION................8 Rail Installation ..................8 Expansion Installation ................9 CONNECTION DIAGRAMS ................10 Supply Connection ..................10 Digital Inputs ...................11 Digital Outputs ..................12 Analog Inputs ..................13 RS485 SERIAL PORT .................14 MP110 SERIES – HARDWARE MANUAL... -
Page 3: Figures List
Figure 4 Power Connection Diagram ................10 Figure 5 Digital Input Connection Diagram ...............11 Figure 6 Digital Output Connection Diagram .............12 Figure 7 Analog Input Connection Diagram ..............13 Figure 8 RS485 Serial Port Connection Diagram ............14 MP110 SERIES – HARDWARE MANUAL... -
Page 4: Preface
Preface Mikrodev MP201 and MP110 PLC series are programmable control devices that are used in a wide range of applications from process automation to building automation, from machine automation to telemetry applications. In this document, you can find information about the hardware specifications of Mikrodev MP201/MP110 series PLCs. -
Page 5: About Mikrodev
MIKRODEV is one of the few companies in the world that has its own designed IEC 61131-3 compliant library for its programmable logic control devices. In addition, the open, flexible, programmable SCADA solution developed by MIKRODEV is also available to customers. -
Page 6: Warning
✓ Make sure that the environment in which your device is being used is free of moisture, electric shock, vibration and dust. ✓ Pay attention to the supply voltage and the connections of the product. Mikrodev is not responsible for any issues due to power failure since there is no auxiliary supply (UPS) on the device. -
Page 7: Mp110 General Information
Digital Input Connections System Power /Running LED SIM Card Slot Digital Input Status Information Analog Input Connections Digital Output Status Information Digital Output Connections Protocol Data Transfer LED Expansion Connector Device Power (V+/V-) Connection RS485 Connections MP110 SERIES – HARDWARE MANUAL... -
Page 8: General Device Specifications
1 Port, 3 Kv ESD Protection 1 Port, Mini USB Type B Wireless Quad-Band GSM / GPRS* Communication 850/900/1800/1900 MHz Din RAIL Type- CANBUS Up to 512 I/O Points Expansion Capacity Expansion Modules *May differ on some models MP110 SERIES – HARDWARE MANUAL... -
Page 9: Installation Information
DIN Rail Demountage To demount the device, firstly it is pulled from the bottom using flexibility of the spring, the device is removed from the DIN Rail and the demounting is completed. Figure 2 Mounting MP110 SERIES – HARDWARE MANUAL... -
Page 10: Expansion Installation
2.2 Expansion Installation The MP110 product and its extensions are mounted by sliding over the rail in such a way that the connectors correponds. Figure 3 Expansion Installation MP110 SERIES – HARDWARE MANUAL... -
Page 11: Connection Diagrams
CONNECTION DIAGRAMS 3.1 Supply Connection Supply: 12-36 VDC, Protected Power: < 13 W Figure 4 Power Connection Diagram MP110 SERIES – HARDWARE MANUAL... -
Page 12: Digital Inputs
>2M Isolation: Optical OFF to ON Response: 20 us ON to OFF Response: 90 us Fast Counter Inputs: DI1, DI2, DI3, DI4 Fast Counter Inputs Max. Frequency: 200 kHz Figure 5 Digital Input Connection Diagram MP110 SERIES – HARDWARE MANUAL... -
Page 13: Digital Outputs
Isolation: Optical Pulse Width Modulation Output and Pulse Train Output: DO1, DO2, DO3, DO4 Pulse Train Output Max. Frequency(PTO): 50 kHz Pulse Width Modulation Output Max. Frequency(PWM): 65 kHz Figure 6 Digital Output Connection Diagram MP110 SERIES – HARDWARE MANUAL... -
Page 14: Analog Inputs
Module Input: 2 Channel Analog Input Type 0-20 mA, 4-20 mA Analog Input Resolution: 12 Bit Analog Input Precision: %1 Precision Common Input GND: 1 GND (4 Point / Common) Figure 7 Analog Input Connection Diagram MP110 SERIES – HARDWARE MANUAL... -
Page 15: Rs485 Serial Port
1 Port, 3 kV ESD Protection Maximum Slave Counts: Limited to Hardware Isolation: Galvanic and Optical Communication Distance: 1000 m Data Bits: Stop Bits: Parity: None-Even-Odd Baudrate: 300 bps to 200 kbps Figure 8 RS485 Serial Port Connection Diagram MP110 SERIES – HARDWARE MANUAL...
