09/07/24

XX/XX/24

MOHIT

NAME

EN ORIGINAL INSTRUCTIONS

IMPORTANT - These instructions are for your safety.

Please read through them thoroughly prior to handling

the product and retain them for future reference.

V10724_5059340904955_MAND2_2324

5059340904955_MNL_IN_V01.indd 1

XX/XX/24

XX/XX/23

Impala Ref: PRJ31510

NAME

EAN: 5059340904955

Page Size: A5

EN Cordless hand-push

lawn mower 36 V

46 cm

ERT1042GLM

5059340904955

5059340904542

5063022544469

11-07-2024 12:57:31

Table of Contents

Need help?

Do you have a question about the ERT1042GLM and is the answer not in the manual?

Questions and answers

Summary of Contents for Kingfisher ERT1042GLM

Page 1 NAME EN Cordless hand-push lawn mower 36 V 46 cm EN ORIGINAL INSTRUCTIONS ERT1042GLM IMPORTANT - These instructions are for your safety. Please read through them thoroughly prior to handling 5059340904955 the product and retain them for future reference. 5059340904542...
Page 2 EN Parts 01. x1 02. x1 03. x1 04. x1 EN You will need (items not supplied) Suitable personal protective equipment Suitable wrench Suitable lubricating oil Battery pack (24) Charger (25) and its manual EN Contents Product description Safety Guarantee Preparation Assembly Functions &...
Page 3 EN Product description 24a 24b 24c 24 5059340904955_MNL_IN_V01.indd 3 5059340904955_MNL_IN_V01.indd 3 11-07-2024 12:57:35 11-07-2024 12:57:35...
Page 4 1. Safety switch button 17. Cutting blade compartment 2. Start lever a. Spindle 3. Grip handle b. Blade holder 4. Control cord c. Cutting blade 5. Upper handle bar d. Hex bolt with washers 6. Middle handle bar 18. Lever for cutting height adjustment a.
Page 5: Work Area Safety
EN Safety General Machine Safety Warnings WARNING! READ ALL SAFETY WARNINGS, INSTRUCTIONS, ILLUSTRATIONS AND SPECIFICATIONS PROVIDED WITH THIS MACHINE. FAILURE TO FOLLOW ALL INSTRUCTIONS LISTED BELOW MAY RESULT IN ELECTRIC SHOCK, FIRE AND/OR SERIOUS INJURY. SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE.
Page 6: Personal Safety
Avoid body contact with earthed or grounded surfaces, • such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded. • Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.
Page 7 Do not overreach. Keep proper footing and balance at all • times. This enables better control of the machine in unexpected situations. • Dress properly. Do not wear loose clothing or jewellery. Keep your hair and clothing away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
Page 8 Keep cutting machines sharp and clean. Properly maintained • cutting machines with sharp cutting edges are less likely to bind and are easier to control. • Use the machine, accessories and machine bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed.
Page 9: Lawnmower Safety Warnings
Do not expose a battery pack or machine to fire or • excessive temperature. Exposure to fire or temperature above 130 °C may cause explosion. • Follow all charging instructions and do not charge the battery pack or machine outside the temperature range specified in the instructions. Charging improperly or at temperatures outside the specified range may damage the battery and increase the risk of fire.
Page 10 Keep all cooling air inlets clear of debris. Blocked air inlets • and debris may result in overheating or risk of fire. • While operating the lawnmower, always wear non-slip and protective footwear. Do not operate the lawnmower when barefoot or wearing open sandals. This reduces the chance of injury to the feet from contact with the moving blade. While operating the lawnmower, always wear long trousers.
Page 11 Additional safety instructions for lawn mower Training • Read the instructions carefully. Be familiar with the controls and the proper use of the product. • Never allow children, persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge or people unfamiliar with these instructions to use the product.
Page 12: Operation
Operation • Operate the product only in daylight or in good artificial light. • Avoid operating the product in wet grass, where feasible. • Always be sure of your footing on slopes. • Walk, never run. • Mow across the face of slopes, never up and down. • Exercise extreme caution when changing direction on slopes. •...
Page 13: Maintenance And Storage
• If the product starts to vibrate abnormally (check immediately) • inspect for damage, • replace or repair any damaged parts, • check for and tighten any loose parts. Maintenance and storage • Remove the battery pack before checking, cleaning or working on the product and when it is not in use.
Page 14 Additional safety warnings for battery pack • Battery pack needs to be charged before use. Always refer to the charger’s instruction and charge it properly. Remove the battery pack from the product when not in use. • Don’t maintain the battery pack on the charger when not •...
Page 15: Health Surveillance
• Do not place the battery in or near fire, on stoves or on other high temperature locations. Do not place the battery in direct sunlight, or use or store the battery inside cars in hot weather. • Do not place the battery in microwave ovens, high pressure containers or on induction cookware. •...
Page 16: Residual Risks
• Prolonged use of the product exposes the user to vibrations that can cause a range of conditions collectively known as hand-arm vibration syndrome (HAVS) e.g. fingers going white; as well as specific diseases such as carpal tunnel syndrome. To reduce this risk when using the product, always wear protective gloves and keep your hands warm. Emergency Familiarise yourself with the use of this product by means of this instruction manual.
Page 17 WARNING! THIS PRODUCT PRODUCES AN ELECTROMAGNETIC FIELD DURING OPERATION! THIS FIELD MAY UNDER SOME CIRCUMSTANCES INTERFERE WITH ACTIVE OR PASSIVE MEDICAL IMPLANTS! TO REDUCE THE RISK OF SERIOUS OR FATAL INJURY, WE RECOMMEND PERSONS WITH MEDICAL IMPLANTS TO CONSULT THEIR DOCTOR AND THE MEDICAL IMPLANT MANUFACTURER BEFORE OPERATING THIS PRODUCT! Symbols...
Page 18 Always wear eye protection. Wear a dust mask. Wear protective gloves. Wear protective, slip-resistant footwear. Wear tight-fitted protective clothes. WARNING – Disconnect battery before maintenance! Switch the product off and remove battery pack before assembly, cleaning, adjustments, maintenance, storage and transportation. This product is of protection class III. Do not expose the product to rain or wet conditions (moisture). Mow across the face of slopes, never up and down.
Page 19 The product complies with the applicable European directives and an evaluation method of conformity for these directives was done. UK Conformity Assessed. Rating label explanation ERT1042GLM = Model number ERT = Erbauer (brand) 1042 = Sequential code GLM = Grass Lawn Mower 5059340904955_MNL_IN_V01.indd 19...
Page 20: Technical Specifications
Technical specifications General > Rated voltage : 36 V > Rated no load speed n 2800 min > Max. cutting width : 46 cm > Cutting height range : 25 - 75 mm, 7 levels > Grass catcher volume : 60 L >...
Page 21: Recycling And Disposal
The sound values have been determined according to noise test code given in EN 62841-1, EN IEC 62841-4-3 using the basic standards EN ISO 11094 and EN ISO 3744. The sound intensity level for the operator may exceed 80 dB(A) and ear protection measures are necessary. The declared vibration total values and the declared noise emission values have been measured in accordance with a standard test method (EN 62841-1, EN IEC 62841-4-3) and may be used for comparing one machine with another; they may also be used in a preliminary assessment of exposure.
Page 22 This guarantee covers product failures and malfunctions provided the product was used for the purpose for which it is intended and subject to installation, cleaning, care and maintenance in accordance with the information contained in these terms and conditions, in the user manual and standard practice, provided that standard practice does not conflict with the user manual.
Page 23 You will need (items not supplied) (items supplied) Suitable personal protective equipment Cutting blade (17c) Suitable wrench Grass catcher (20) Suitable lubricating oil Side discharge attachment (22) Battery pack (24) Mulching insert (23) Charger (25) and its manual NOTE: The accessories required depend on the intended application. Ask your dealer for advice.
Page 24 Fig. 1 3. Grasp the grip handle (3) and keep rotating the handle assembly until the lock pin (8a) of the lock lever (8) automatically engaged in one of the holes (9a) of the handle support (9), depended on the need of handle height; Rotate the two lock levers (8) clockwise to secure the assembly (Fig. 2, steps 1, 2).
Page 25 4. Pull open the two clamp levers (6a), then grasp the grip handle (3) and gradually pull out upper handle bar (5) all the way until an audible click is heard (Fig. 3, steps 1, 2). Fig. 3 5. Close the two clamp levers (6a) and check whether the upper handle bar (5) is secured. Fig.
Page 26: Grass Catcher
Grass catcher 1. The grass catcher (20) is partly assembled at delivery status. 2. Clip the three rubber clips (20c) onto the supporting rod (20d) of the grass catcher (20) (Fig. 5) and the grass catcher (20) is ready for use. Fig.
Page 27 Battery pack (not included) Attaching the battery pack 1. Hold the lip (12d) and open the battery compartment cover (12) (Fig. 7, step 1). 2. Align the battery pack (24) with the sliding slots (12b) of the battery compartment (12e) and slide the battery pack (24) in to attach it (Fig.
Page 28: Intended Use
Fig. 9 EN Functions & Settings Intended use This cordless lawn mower ERT1042GLM is designated with a rated voltage of 36 V . It is designed only to be used with the battery pack which is listed in the chapter of “Technical specifications”. The product is intended for mowing grass in domestic gardens only. It must not be used to mow unusually high, dry or wet grass, e.g.
Page 29: Cutting Height Adjustment
Adjust the handle assembly to a suitable height according to your needs. There are three handle heights to choose. 1. Squeeze and disengage the two lock levers (8) on both sides of the lower handle bar (7) (Fig.10, step 1). 2.
Page 30 Adjust the cutting height according to the needs of your lawn. The cutting height depends on the kind of lawn and its actual height. When mowing high grass, start with the maximum cutting height and make a second cut with a lower cutting height. 1.
Page 31: Mulching Insert
Indicator The grass catcher (20) is equipped with a hatch (20b) that indicates the filling during operation. Fig. 12 Fig. 13 1. When the hatch (20b) is opened the grass catcher (20) has sufficient volume left to collect grass (Fig. 12). 2. When the hatch (20b) is closed, the grass catcher (20) is full and must be emptied (Fig. 13). Emptying Empty the grass catcher (20) frequently during use. Do not wait until it is completely full. We recommend emptying it when it is half full.
Page 32: Side Discharge Attachment
1. Open the deflector guard (10), hold the recess handle (23b) in position and insert the mulching insert (23) into the rear discharge chute (21) (Fig. 14). Ensure the locking latch (23a) snap into the rear discharge chute (21). 2. Hold the recess handle (23b) and pull the mulching insert (23) out of the rear discharge chute (21), then remove the mulching insert (23) (Fig.
Page 33: General Operation
EN Use General operation 1. Check the product, its battery pack and charger as well as accessories for damage before each use. Do not use the product if it is damaged or shows wear. Take care of any problem you find or have the product checked by qualified specialist. 2. Double check that the accessories and attachments are properly fixed. 3. Always push the product using the grip handle (3). Keep the handles dry to ensure safe support. 4.
Page 34 Fig. 18 Stopping 1. Release the start lever (2) to stop the lawn mower (Fig. 19). Fig. 19 Mowing 1. Make sure that the lawn is clear of stones, sticks, wire or other objects that could damage the product or its product.
Page 35 Fig. 20 6. Circle around flower beds. When reaching a flower bed in the middle of the lawn, cut a row or two around the circumference of the bed. 7. Pay special attention when changing direction. 8. Empty the grass catcher (20) regularly. WARNING! IF THE PRODUCT STRIKES A FOREIGN OBJECT STOP IMMEDIATELY! LET THE PRODUCT COOL DOWN AND THOROUGHLY INSPECT THE PRODUCT FOR DAMAGE! HAVE ANY DAMAGE REPAIRED BEFORE RESTARTING! EXTENSIVE VIBRATION OF THE PRODUCT DURING OPERATION IS...
Page 36: After Use
3. Set the cutting height to about one third of the grass blade length, ideally no more than 35 mm at one time for best mulching performance. If the lawn is overgrown, it may be necessary to increase the cutting height to reduce the pushing effort and prevent the motor overloading. For extremely heavy mulching, it is advisable to first cut at a high cutting height, and then again to a lower cutting height. Otherwise, make narrower cuts and mow slowly.
Page 37: General Cleaning
Problem Possible cause Solution 3. Unsatisfactory 3.1. Cutting blade is dull / damaged 3.1. Replace with a new one cutting result 3.2. Cutting material exceeds capacity 3.2. Only cut materials according to the product capacity. 3.3. Cutting height is incorrect 3.3.
Page 38: Maintenance
4. Check for any damage and wear. Repair damages in accordance with this instruction manual or take it to an authorised service centre before using the product again. Spare parts / Replacement parts The following parts of this product may be replaced by the consumer. Spare parts are available at an authorized dealer or through our customer service.
Page 39 Fig. 21 Grass catcher 1. Inspect the grass catcher (20) before each use. Do not use it if you find any damage. 2. Clean the grass catcher (20) after operation using water and mild soap. 3. Let the grass catcher (20) dry thoroughly before storing to avoid mildew. Control cord Check the control cord (4) before each use. WARNING! DO NOT USE THE PRODUCT WITH A DEFECTIVE OR A LOOSE CONTROL CORD (4)! Repair...
Page 40 4. Store the product and its accessories in a dark, dry, frost-free, well-ventilated place. 5. Always store the product in a place that is inaccessible to children. The ideal storage temperature is between 10 °C and 30 °C. 6. We recommend using the original package for storage or covering the lawn mower (without battery pack) with a suitable cloth or enclosure to protect it against dust.
Page 41: Availability Of Spare Parts
Customer care and technical helpline A better way to repair your tools Kingfisher takes special care in creating high-quality garden power tools that are designed to last. But if a fault develops with your garden power tool and you need to claim under the guarantee, the Customer Care and Technical Helpline can support with technical assistance or if required, arrange a free courier collection from your home, assess your garden power tool for fault, repair it, and return it.
Page 42 (UK) DECLARATION OF CONFORMITY Product • 36 V Lawn Mower • ERT1042GLM • SN: 000001-999999 Name and address of the manufacturer or his authorised representative: Kingfisher International Products Limited, 1 Paddington Square, London, W2 1GG, United Kingdom This declaration of conformity is issued under the sole responsibility of the manufacturer.
Page 43 (ES) DECLARACIÓN UE DE CONFORMIDAD (PT) DECLARAÇÃO DE CONFORMIDADE UE Product/ Produit/ Produkt/Produsul/Produkt/Producto/Produto • 36 V Lawn Mower • ERT1042GLM • SN: 000001-999999 Name and address of the manufacturer or his authorised representative: Nom et adresse du fabricant ou de son mandataire: Nazwa i adres producenta lub jego upoważnionego przedstawiciela: Denumirea și adresa producătorului sau a reprezentantului său autorizat:...
Page 44 Name, address and identification number of the notified body: TÜV Rheinland LGA Products GmbH Tillystraße 2 - 90431 Nürnberg, Germany No.0197 Number of the EC type-examination certificate: xxxxxxxxxx Authorized Signatory and technical file holder/ Signataire et responsable de la documentation technique autorisé/ Podmiot uprawniony do wystawienia i adres przechowywania dokumentacji technicznej/ Semnatar autorizat şi deţinătorul dosarului ethnic/ Firmante autorizado y titular del expediente técnico/ Signatário autorizado e detentor da ficha técnica: Kingfisher International Products B.V., Rapenburgerstraat 175E, 1011 VM Amsterdam, The Netherlands David Awe Group Quality & Sustainability Director : 04/30/2022 5059340904955_MNL_IN_V01.indd 44 5059340904955_MNL_IN_V01.indd 44...
Page 45 Manufacturer: EN www.diy.com www.screwfix.com UK Manufacturer: www.screwfix.ie Kingfisher International Products Limited, To view instruction manuals online, 1 Paddington Square, London, W2 1GG, visit www.kingfisher.com/products United Kingdom EU Manufacturer: Kingfisher International Products B.V. Rapenburgerstraat 175E 1011 VM Amsterdam The Netherlands 5059340904955_MNL_IN_V01.indd 45 5059340904955_MNL_IN_V01.indd 45 11-07-2024 12:57:48 11-07-2024 12:57:48...
