FPLMP450BS-HP-2
Original instructions
Oryginalna instrukcja
SEPARATIONS JOB INFO
PID #: SUME10936
Agency job #: 00001
Product Description: FPLMP450BS-
HP-2 - Petrol Lawnmower 125cc IM A5
v1 Lawnmower IM
PROCESS
BLACK
VERSION #
1
12/09/17
INITIALS
This file is the property of Kingfisher Group Plc. No copying, alteration or amendment is permitted without
written authorisation from the Kingfisher Brand Team.
3663602705284
Instrucciones originales
Brand: Mac Allister
Brand Contact: jennifer.bliss@kingfisher.com
Barcode: 3663602705284
Vendor: Sumec
No. of new line drawings: xx
Page size A5 / No. of printed pages 112
2
3
R
5
26/09/17
13/10/17
13/10/17
00/00/17
00/00/17
TjB
DLS
DLS
INITIALS
INITIALS
Instruções originais
6
7
8
00/00/17
00/00/17
INITIALS
INITIALS
V1.1
V11017

Advertisement

Table of Contents
loading

Related Manuals for Kingfisher FPLMP450BS-HP-2

Summary of Contents for Kingfisher FPLMP450BS-HP-2

  • Page 1 VERSION # 12/09/17 26/09/17 13/10/17 13/10/17 00/00/17 00/00/17 00/00/17 00/00/17 INITIALS INITIALS INITIALS INITIALS INITIALS This file is the property of Kingfisher Group Plc. No copying, alteration or amendment is permitted without written authorisation from the Kingfisher Brand Team. V1.1...
  • Page 2 Preparation Przygotowanie Preparación Preparação Assembly Montaje Montagem Cuidados y Mantenimiento...
  • Page 3 These instructions Te instrukcje maj Estas instrucciones Estas instruções are for your safety. s u y T ojemu son para su propia são para sua Please read them be iec e st u. seguridad. Léalas segurança. Leia-as thoroughly before ale y je dok adnie atentamente antes atentamente antes use and retain...
  • Page 4 1. Upper handle bar 2. Brake bar 3. Brake wire 4. Cup head square neck bolts M8X45(x 2) 5. Locking knob with M8 nut(x4) 6. Lower handle bar 7. Wire Clip 8. Fuel tank a. Cap 9. Air vents 10. Primer 11. Air lter case a.

  • Page 5: Safety Instructions

    Preparation Przygotowanie Preparación Preparação Safety Instructions Training 1. Read the instructions carefully. Be familiar with the controls and the proper use of the product. 2. Never allow children or people unfamiliar with these instructions to use the product. Local regulations can restrict the age of the operator.
  • Page 6 Operation 4. Avoid operating the product in wet grass, where feasible. 5. Always be sure of your footing on slopes. 6. Walk, never run. 7. Mow across the face of slopes, never up and down. 8. Exercise extreme caution when changing direction on slopes. 9.

  • Page 7: Fuel Handling

    3. Improper maintenance or using non genuine parts may lead to malfunction/failure of the product. Many accidents are caused by poorly maintained products. 4. Never store the product with petrol in the tank inside a building where fumes can 5. Allow the engine to cool before storing in any enclosure. 6.

  • Page 8: Residual Risks

    WARNING! Never use water to extinguish a product on re. Burning fuel must be extinguished with special extinguishing agents! We recommend that you keep a suitable re extinguisher within reach of your work area! Residual risks Even if you are operating this product in accordance with all the safety requirements, potential risks of injury and damage remain. The following dangers can arise in connection with the structure and design of this product: 1.
  • Page 9 Read the instruction manual Wear hearing protection. Wear eye protection. Wear respiratory protection. Wear protective gloves. Wear protective, slip-resistant footwear. Wear tight- tted protective clothes. Do not expose the product to rain or wet conditions. Open ames in the work area, around the product and in the vicinity of ammable materials are prohibited! Do not smoke in the work area, around the product and in the vicinity of ammable materials! Risk of re / ammable materials...
  • Page 10 STOP Engine manual start; recoil starter Guaranteed sound power level in 96dB FPLMP450BS-HP-2 Designation of the tool (FP_Brand Name; LM_Lawn mower; P_Petrol Power) The product complies with the applicable European directives and an evaluation method of conformity for these directives was done.
  • Page 11 General: Dimensions: Approx. 1290 x 495 x 990mm Machine mass with empty tanks and in normal Approx. 20kg Fuel tank capacity: 800ml (cm Petrol type: #93, unleaded Engine oil capacity: 470ml (cm Engine oil type: 4-stroke engine oil (e.g. SAE 10W – 30) 397 g/kWh Fuel consumption at max.
  • Page 12 WARNING! Depending on the actual use of the product the vibration values can differ from the declared total! Adopt proper measures to protect yourself against vibration exposures. Take the whole work process including times the product is running under no load or switched off into consideration. Proper measures include among others regular maintenance and care of the product and application tools, keeping hands warm, periodical breaks and proper planning of work processes.

  • Page 13: Before You Start

    Assembly Montaje Montagem WARNING! The product must be fully assembled before operation! Do not use a product that is only partly assembled or assembled with damaged parts! Follow the assembly instructions step-by-step and use the pictures provided as a visual guide to easily assemble the product! Disconnect the spark plug connector (12) from the spark plug! Reconnect it after assembly.
  • Page 14 3. Fix the lower handle bar (6) with the Arc-head blot M8X35 (18) to the handle supports (17) Fig. 3. Fig. 3 4. Align the mounting holes of the upper handle bar (1) with the ones on the lower handle bar (6). Ensure the rope guide (21) is properly aligned.

  • Page 15: Grass Catcher

    5. Fix the wires (4) with the clip wire (7) to the lower handle bar (6) Fig.5. Fig. 5 Grass Catcher 1. Attach the grass bag to the frame by xing all plastic hooks. (Fig. 6) 2. Open the de ector guard (19) and hold it in the open position. Hang the grass catcher on the rod. (Fig.7) Fig.
  • Page 16 WARNING! Fuel and oil are highly ammable! Fumes will explode if lit. Ensure there are no naked ames around the product! Do not smoke while lling fuel and oil. 3. Always dispose of fuel and oil and objects contaminated with them in accordance with local regulations. Fuel NOTE: This product is not supplied with fuel! Before operating this product, it is essential to ll it with fuel! Fill fuel and engine...

  • Page 17: Engine Oil

    Engine oil WARNING! This product is not supplied with oil. However, for manufacturing reasons it is possible that a small quantity may be in the engine! Before operating this product it is essential to ll it with proper oil (see the separate engine handbook (26)! 1.

  • Page 18: Operating Controls

    Product Functions Intended use This petrol lawnmower FPLMP450BS-HP-2 is designated with a power output of 1.8kW. 1. The product is intended for mowing grass in domestic gardens only. It must not be used to mow unusually high, dry or wet grass, e.g.

  • Page 19: Recoil Starter

    Brake bar 1. Pull the brake bar (2) towards the Upper handle bar (1) and hold it in position when starting the engine. Keep it squeezed during operation (Fig. 11). 2. Release the brake bar (2) to stop the engine. Fig.

  • Page 20: Cutting Height Adjustment

    Grass catcher Emptying Empty the grass catcher (20) frequently during use. Do not wait until it is completely full. NOTE: A full grass catcher will reduce the performance of this product. 1. Lift the rear de ector guard (19) and pull the grass catcher (20) off the rod. 2.

  • Page 21: General Operation

    WARNING! Ensure that the lever engages between two of the prongs! Switch the engine off and wait that the blade had come to a complete stop before adjusting the cutting height! Primer The primer (10) is positioned in the air lter case (11). Use the primer (10) when starting the product with cold engine (Fig. 15). Fig.
  • Page 22 Set Up This product is equipped with a 4-stroke engine. Before operation it is necessary to add proper fuel and engine oil separately. Assemble Adjust Add fuel Add oil Starting/Stopping WARNING! Before starting, put on a at surface free of high grass! Clean the underside of the deck! Keep yourself ready! Start the engine carefully according to instructions.
  • Page 23 Fig. 16 Fig. 17 WARNING! The starting position should be as described in the instruction handbook. (Fig. A) is the de ned starting position. User should start the engine behind the lever. DO NOT start the engine standing beside the deck as (Fig. B). Fig.

  • Page 24: After Use

    Fig. 18 Mowing 1. Make sure that the lawn is clear of stones, sticks, wire or other objects that could damage the product or its engine. 2. Do not cut wet grass because it tends to stick to the underbody of the product, preventing the proper discharge of grass clippings, and it could also cause you to slip and fall.

  • Page 25: Product Maintenance

    Cuidados y Mantenimiento Care WARNING! Always switch the product off, disconnect the spark plug connector and let the product cool down before performing inspection, maintenance and cleaning work! DO NOT touch a rotating blade. 1. Keep the product clean. Remove debris from it after each use and before storage. 2.
  • Page 26 NOTE: We strongly recommend jacking the product up when performing inspection and work on the cutting device. Avoid tilting the product in order to prevent fuel and oil leakages. 1. Keep the underbody and cutting device (23) clean and free of debris. Remove clippings from the discharge chute (24). 2.
  • Page 27 WARNING! Do not use the product with defective or loose wires! Engine NOTE: An instruction manual of the engine is provided with your product. Follow the engine handbook for maintenance and care for of engine. Refer to the B&S operator’s manual for maintaining below parts: Air lter Spark plug Fuel...

  • Page 28: Troubleshooting

    Transportation 1. Switch the product off and disconnect the spark plug connector. 2. Adjust the height to the highest position as described above. 3. Attach transportation guards, if applicable. 4. Always transport the product by its handle (1). 5. Protect the product from any heavy impact or strong vibrations which may occur during transportation in vehicles. 6.

  • Page 29: Recycling And Disposal

    Problem Possible cause Solution 7. Engine overheats 7.1 Air vents are clogged 7.1 Remove debris from vents 7.2 Incorrect spark plug 7.2 Install correct spark plug and cylinder 8. Unsatisfactory results 8.1 Cutting device dull 8.1 Replace with a new one 8.2 Cutting material exceeds capacity 8.2 Only cut materials acc.

  • Page 30: Ec Declaration Of Conformity

    3 Sheldon Square London W2 6PX United Kingdom Declare that the product Petrol Lawnmower FPLMP450BS-HP-2 Serial number: from 000001 to 999999 Complies with the essential health and safety requirements of the following directives: The Machinery Directive 2006/42/EC • EN ISO 5395-1:2013+A1:2018 •...
