  • Page 1 EN Cordless lawn mower 36 V 41 cm EN ORIGINAL INSTRUCTIONS IMPORTANT - These instructions are for your safety. Please read through them thoroughly prior to handling ERT1041GLM the product and retain them for future reference. 5059340904832 5059340904610 V10724_5059340904832_MAND2_2324 5059340904832_MNL_IN_V01.indd 1 5059340904832_MNL_IN_V01.indd 1...
  • Page 2 EN Parts 01. x1 02. x1 03. x1 04. x1 EN You will need (items not supplied) Suitable personal protective equipment Suitable wrench Suitable lubricating oil Battery pack (23) Charger (24) and its manual EN Contents Product description Safety Guarantee Preparation Assembly Functions &...
  • Page 3 EN Product description 5059340904832_MNL_IN_V01.indd 3 5059340904832_MNL_IN_V01.indd 3 15-07-2024 14:34:47 15-07-2024 14:34:47...
  • Page 4 1. Safety switch button 16. Cutting blade compartment 2. Start lever a. Spindle a. Protective sleeve b. Blade holder 3. Grip handle c. Cutting blade 4. Upper handle bar d. Hex bolt with washers 5. Control cord 17. Lever for cutting height adjustment 6.

  • Page 5: Work Area Safety

    EN Safety General Machine Safety Warnings WARNING! READ ALL SAFETY WARNINGS, INSTRUCTIONS, ILLUSTRATIONS AND SPECIFICATIONS PROVIDED WITH THIS MACHINE. FAILURE TO FOLLOW ALL INSTRUCTIONS LISTED BELOW MAY RESULT IN ELECTRIC SHOCK, FIRE AND/OR SERIOUS INJURY. SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE.

  • Page 6: Personal Safety

    Avoid body contact with earthed or grounded surfaces, • such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded. • Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.
  • Page 7 Do not overreach. Keep proper footing and balance at all • times. This enables better control of the machine in unexpected situations. • Dress properly. Do not wear loose clothing or jewellery. Keep your hair and clothing away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
  • Page 8 Keep cutting machines sharp and clean. Properly maintained • cutting machines with sharp cutting edges are less likely to bind and are easier to control. • Use the machine, accessories and machine bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed.

  • Page 9: Lawnmower Safety Warnings

    Do not expose a battery pack or machine to fire or • excessive temperature. Exposure to fire or temperature above 130 °C may cause explosion. • Follow all charging instructions and do not charge the battery pack or machine outside the temperature range specified in the instructions. Charging improperly or at temperatures outside the specified range may damage the battery and increase the risk of fire.
  • Page 10 Keep all cooling air inlets clear of debris. Blocked air inlets • and debris may result in overheating or risk of fire. • While operating the lawnmower, always wear non-slip and protective footwear. Do not operate the lawnmower when barefoot or wearing open sandals. This reduces the chance of injury to the feet from contact with the moving blade. While operating the lawnmower, always wear long trousers.
  • Page 11 Additional safety instructions for lawn mower Training • Read the instructions carefully. Be familiar with the controls and the proper use of the product. • Never allow children, persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge or people unfamiliar with these instructions to use the product.

  • Page 12: Operation

    Operation • Operate the product only in daylight or in good artificial light. • Avoid operating the product in wet grass, where feasible. • Always be sure of your footing on slopes. • Walk, never run. • Mow across the face of slopes, never up and down. • Exercise extreme caution when changing direction on slopes. •...

  • Page 13: Maintenance And Storage

    • If the product starts to vibrate abnormally (check immediately) • inspect for damage, • replace or repair any damaged parts, • check for and tighten any loose parts. Maintenance and storage • Remove the battery pack before checking, cleaning or working on the product and when it is not in use.
  • Page 14 Additional safety warnings for battery pack • Battery pack needs to be charged before use. Always refer to the charger’s instruction and charge it properly. Remove the battery pack from the product when not in use. • Don’t maintain the battery pack on the charger when not •...

  • Page 15: Health Surveillance

    • Do not place the battery in or near fire, on stoves or on other high temperature locations. Do not place the battery in direct sunlight, or use or store the battery inside cars in hot weather. • Do not place the battery in microwave ovens, high pressure containers or on induction cookware. •...

  • Page 16: Residual Risks

    • Prolonged use of the product exposes the user to vibrations that can cause a range of conditions collectively known as hand-arm vibration syndrome (HAVS) e.g. fingers going white; as well as specific diseases such as carpal tunnel syndrome. To reduce this risk when using the product, always wear protective gloves and keep your hands warm. Emergency Familiarise yourself with the use of this product by means of this instruction manual.
  • Page 17 WARNING! THIS PRODUCT PRODUCES AN ELECTROMAGNETIC FIELD DURING OPERATION! THIS FIELD MAY UNDER SOME CIRCUMSTANCES INTERFERE WITH ACTIVE OR PASSIVE MEDICAL IMPLANTS! TO REDUCE THE RISK OF SERIOUS OR FATAL INJURY, WE RECOMMEND PERSONS WITH MEDICAL IMPLANTS TO CONSULT THEIR DOCTOR AND THE MEDICAL IMPLANT MANUFACTURER BEFORE OPERATING THIS PRODUCT! Symbols...
  • Page 18 Always wear eye protection. Wear a dust mask. Wear protective gloves. Wear protective, slip-resistant footwear. Wear tight-fitted protective clothes. WARNING – Disconnect battery before maintenance! Switch the product off and remove battery pack before assembly, cleaning, adjustments, maintenance, storage and transportation. This product is of protection class III. Do not expose the product to rain or wet conditions (moisture). Mow across the face of slopes, never up and down.
  • Page 19 The product complies with the applicable European directives and an evaluation method of conformity for these directives was done. UK Conformity Assessed. Rating label explanation ERT1041GLM = Model number ERT = Erbauer (brand) 1041 = Sequential code GLM = Grass Lawn Mower 5059340904832_MNL_IN_V01.indd 19...

  • Page 20: Technical Specifications

    Technical specifications General > Rated voltage : 36 V > Rated no load speed n 2800 min > Max. cutting width : 41 cm > Cutting height range : 25 - 75 mm, 7 levels > Grass catcher volume : 60 L >...

  • Page 21: Recycling And Disposal

    The sound values have been determined according to noise test code given in EN 62841-1, EN IEC 62841-4-3 using the basic standards EN ISO 11094 and EN ISO 3744. The sound intensity level for the operator may exceed 80 dB(A) and ear protection measures are necessary. The declared vibration total values and the declared noise emission values have been measured in accordance with a standard test method (EN 62841-1, EN IEC 62841-4-3) and may be used for comparing one machine with another; they may also be used in a preliminary assessment of exposure.
  • Page 22 This guarantee covers product failures and malfunctions provided the product was used for the purpose for which it is intended and subject to installation, cleaning, care and maintenance in accordance with the information contained in these terms and conditions, in the user manual and standard practice, provided that standard practice does not conflict with the user manual.
  • Page 23 You will need (items not supplied) (items supplied) Suitable personal protective equipment Cutting blade (16c) Suitable wrench Grass catcher (19) Suitable lubricating oil Mulching insert (22) Battery pack (23) Charger (24) and its manual NOTE: The accessories required depend on the intended application. Ask your dealer for advice.
  • Page 24 Fig. 1 3. Grasp the grip handle (3) and keep rotating the handle assembly until the lock pin (8a) of the lock lever (8) automatically engaged in one of the holes (9a) of the handle support (9), depended on the need of handle height; Rotate the two lock levers (8) clockwise to secure the assembly (Fig. 2, steps 1, 2).
  • Page 25 NOTE: For first assembly, secure the handle assembly with the two lock levers (8) in the middle position of the tilt adjustment mechanism. Ensure the handle assembly is assembled on the same height level on both sides. 4. Fully loosen the two lock knobs (6) but don’t remove them, then grasp the grip handle (3) and keep rotating the handle assembly until the upper handle bar (4) aligns with the low handle bar (7) (Fig.

  • Page 26: Grass Catcher

    Grass catcher 1. The grass catcher (19) is partly assembled at delivery status. 2. Clip the three rubber clips (19c) onto the supporting rod (19d) of the grass catcher (19) (Fig. 5) and the grass catcher (19) is ready for use. Fig.
  • Page 27 Battery pack (not included) Attaching the battery pack 1. Hold the lip (12d) and open the battery compartment cover (12) (Fig. 7, step 1). 2. Align the battery pack (23) with the sliding slots (12b) of the battery compartment (12e) and slide the battery pack (23) in to attach it (Fig.

  • Page 28: Intended Use

    Fig. 9 EN Functions & Settings Intended use This cordless lawn mower ERT1041GLM is designated with a rated voltage of 36 V . It is designed only to be used with the battery pack which is listed in the chapter of “Technical specifications”. The product is intended for mowing grass in domestic gardens only. It must not be used to mow unusually high, dry or wet grass, e.g.

  • Page 29: Cutting Height Adjustment

    Adjust the handle assembly to a suitable height according to your needs. There are three handle heights to choose. 1. Squeeze and disengage the two lock levers (8) on both sides of the lower handle bar (7) (Fig.10, step 1). 2.
  • Page 30 1. Pull the lever (17) towards the rear wheel (18) (Fig. 11, step 1). 2. Move the lever (17) forward or backward to adjust the cutting height (Fig. 11, step 2). 3. Release the lever (17) and ensure it engaged in the slot properly (Fig. 11, step 3). Fig.
  • Page 31 Indicator The grass catcher (19) is equipped with a hatch (19b) that indicates the filling during operation. Fig. 12 Fig. 13 1. When the hatch (19b) is opened the grass catcher (19) has sufficient volume left to collect grass (Fig. 12). 2. When the hatch (19b) is closed, the grass catcher (19) is full and must be emptied (Fig. 13). Emptying Empty the grass catcher (19) frequently during use. Do not wait until it is completely full. We recommend emptying it when it is half full.

  • Page 32: Mulching Insert

    Mulching insert The mulching insert (22) prevents grass from being collected by blocking the rear discharge chute (21). This allows the grass clippings to be deposited back on the lawn during cutting. NOTE: Mulching means cutting and returning the grass clippings to the lawn in one step: the grass clippings are cut very fine and then distributed evenly back onto the lawn.
  • Page 33 WARNING! IN SOME COUNTRIES REGULATIONS DEFINE AT WHAT TIME OF THE DAY AND ON WHAT SPECIAL DAYS PRODUCTS ARE ALLOWED TO BE USED AND WHAT RESTRICTIONS APPLY! ASK YOUR COMMUNITY FOR DETAILED INFORMATION AND OBSERVE THE REGULATIONS IN ORDER TO PRESERVE A PEACEFUL NEIGHBOURHOOD AND AVOID COMMITTING ADMINISTRATIVE OFFENCES! (STATEMENT NOT REQUIRED FOR THE UK)
  • Page 34 Stopping 1. Release the start lever (2) to stop the lawn mower (Fig. 17). Fig. 17 Mowing 1. Make sure that the lawn is clear of stones, sticks, wire or other objects that could damage the product or its product. 2.

  • Page 35: After Use

    WARNING! IF THE PRODUCT STRIKES A FOREIGN OBJECT STOP IMMEDIATELY! LET THE PRODUCT COOL DOWN AND THOROUGHLY INSPECT THE PRODUCT FOR DAMAGE! HAVE ANY DAMAGE REPAIRED BEFORE RESTARTING! EXTENSIVE VIBRATION OF THE PRODUCT DURING OPERATION IS AN INDICATION OF DAMAGE! THE PRODUCT SHOULD BE PROMPTLY INSPECTED AND REPAIRED! 9.

  • Page 36: Troubleshooting

    Troubleshooting Suspected malfunctions are often due to causes that the users can fix themselves. Therefore check the product using this section. In most cases the problem can be solved quickly. WARNING! ONLY PERFORM THE STEPS DESCRIBED WITHIN THESE INSTRUCTIONS! ALL FURTHER INSPECTION, MAINTENANCE AND REPAIR WORK MUST BE PERFORMED BY AN AUTHORISED SERVICE CENTRE OR A SIMILARLY QUALIFIED SPECIALIST IF YOU CANNOT SOLVE THE PROBLEM YOURSELF! Problem Possible cause...

  • Page 37: General Cleaning

    EN Care and maintenance The golden rules for care WARNING! ALWAYS SWITCH THE PRODUCT OFF, REMOVE THE BATTERY PACK (23) AND LET THE PRODUCT COOL DOWN BEFORE PERFORMING INSPECTION, MAINTENANCE AND CLEANING WORK! ONLY PERFORM CARE AND MAINTENANCE WORK ACCORDING TO THESE INSTRUCTIONS! ALL FURTHER WORKS MUST BE PERFORMED BY A QUALIFIED SPECIALIST! 1.
  • Page 38 Underbody and cutting blade WARNING! WEAR SAFETY GLOVES WHEN WORKING ON THE CUTTING BLADE (16C) AND CLOSE TO IT! USE PROPER MACHINES TO REMOVE DEBRIS, E. G. A WOODEN STICK! NEVER USE YOUR BARE HANDS! ALWAYS USE ORIGINAL SPARE PARTS FOR REPLACEMENT. THE CUTTING BLADE MUST BE REPLACED BY AN IDENTIFICATION NO.
  • Page 39 Grass catcher 1. Inspect the grass catcher (19) before each use. Do not use it if you find any damage. 2. Clean the grass catcher (19) after operation using water and mild soap. 3. Let the grass catcher (19) dry thoroughly before storing to avoid mildew. Control cord Check the control cord (5) before each use. WARNING! DO NOT USE THE PRODUCT WITH A DEFECTIVE OR A LOOSE CONTROL CORD (5)! Repair...

  • Page 40: Availability Of Spare Parts

    Customer care and technical helpline A better way to repair your tools Kingfisher takes special care in creating high-quality garden power tools that are designed to last. But if a fault develops with your garden power tool and you need to claim under the guarantee, the Customer Care and Technical Helpline can support with technical assistance or if required, arrange a free courier collection from your home, assess your garden power tool for fault, repair it, and return it.
  • Page 41 (UK) DECLARATION OF CONFORMITY Product • 36 V Lawn Mower • ERT1041GLM • SN: 000001-999999 Name and address of the manufacturer or his authorised representative: Kingfisher International Products Limited, 1 Paddington Square, London, W2 1GG, United Kingdom This declaration of conformity is issued under the sole responsibility of the manufacturer.
  • Page 42 (ES) DECLARACIÓN UE DE CONFORMIDAD (PT) DECLARAÇÃO DE CONFORMIDADE UE Product/ Produit/ Produkt/Produsul/Produkt/Producto/Produto • 36 V Lawn Mower • ERT1041GLM • SN: 000001-999999 Name and address of the manufacturer or his authorised representative: Nom et adresse du fabricant ou de son mandataire: Nazwa i adres producenta lub jego upoważnionego przedstawiciela: Denumirea și adresa producătorului sau a reprezentantului său autorizat:...
  • Page 43 Name, address and identification number of the notified body: TÜV Rheinland LGA Products GmbH Tillystraße 2 - 90431 Nürnberg, Germany No.0197 Number of the EC type-examination certificate: xxxxxxxxxx Authorized Signatory and technical file holder/ Signataire et responsable de la documentation technique autorisé/ Podmiot uprawniony do wystawienia i adres przechowywania dokumentacji technicznej/ Semnatar autorizat şi deţinătorul dosarului ethnic/ Firmante autorizado y titular del expediente técnico/ Signatário autorizado e detentor da ficha técnica: Kingfisher International Products B.V., Rapenburgerstraat 175E, 1011 VM Amsterdam, The Netherlands David Awe Group Quality & Sustainability Director : 04/30/2022 5059340904832_MNL_IN_V01.indd 43 5059340904832_MNL_IN_V01.indd 43...
  • Page 44 Manufacturer: EN www.diy.com www.screwfix.com UK Manufacturer: www.screwfix.ie Kingfisher International Products Limited, To view instruction manuals online, 1 Paddington Square, London, W2 1GG, visit www.kingfisher.com/products United Kingdom EU Manufacturer: Kingfisher International Products B.V. Rapenburgerstraat 175E 1011 VM Amsterdam The Netherlands 5059340904832_MNL_IN_V01.indd 44 5059340904832_MNL_IN_V01.indd 44 15-07-2024 14:34:58 15-07-2024 14:34:58...
