  • Page 1 USER MANUAL LPS600A-SFP, LPS601A-MM1300, LPS602A-MM850, LPS603A-SM1310 POWER OVER ETHERNET MEDIA CONVERTER 15W/25.5W/30W...
  • Page 2: Chapter 1: Overview & Installation

    CHAPTER 1: OVERVIEW & INSTALLATION 1.1 OVERVIEW The PoE series of media converters allows the user to connect fiber to copper to power PoE devices. This product features a UTP RJ-45 port and an empty SFP port, which is customizable with the use of a swappable SFP for single or multimode applications.
  • Page 3: Chapter 2: Specifications

    CHAPTER 2: SPECIFICATIONS TABLE 1-1. LEDS (FRONT VIEW OF PoE GIGABIT SFP CONVERTER) SPECIFICATION DESCRIPTION FXAct Lit when FX connection is good. Blinks when FX data is transmitting. Power Lit when power is on. Lit when PoE is working. Link/Act Lit when TP connection is good.
  • Page 4 CHAPTER 2: SPECIFICATIONS TABLE 1-4. TECHNICAL SPECIFICATIONS SPECIFICATION DESCRIPTION IEEE 802.3q; Standard Protocol IEEE 802.3z 1000Base-TX/FX standard; IEEE 802.3 af Interface Operation Mode Full/Half duplex mode UTP: RJ-45; Connectors Fiber connector: SC; AC-inlet connector RJ-45 Interface The transmission media adopts CAT5 twisted pair with maximum length of 100 meters (330 ft.) SC fiber interface is a duplex-mode type which includes two sets of optical transceivers: TX and RX.
  • Page 5: Appendix A: Regulatory Information

    APPENDIX A: REGULATORY INFORMATION A.1 FCC STATEMENT This equipment has been tested and found to comply with the regulations for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 6 APPENDIX A: REGULATORY INFORMATION A.4 NOM STATEMENT 1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato eléctrico sea operado. 2. Las instrucciones de seguridad y operación deberán ser guardadas para referencia futura. 3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de operación deben ser respetadas. 4.
  • Page 7: Appendix B: Tech Support/Disclaimer/Trademarks

    B.2 DISCLAIMER Black Box Corporation shall not be liable for damages of any kind, including, but not limited to, punitive, consequential or cost of cover damages, resulting from any errors in the product information or specifications set forth in this document and Black Box Corporation may revise this document at any time without notice.
  • Page 8 © COPYRIGHT 2024, 2025. BLACK BOX CORPORATION. ALL RIGHTS RESERVED. EN_NET_MANUAL_LPS600A-SFP_REV2_2504.PDF...
