17.5x-80x Retractor Telescope with Tabletop Tripod
Congratulations on selecting your new Aim
optimum performance, please follow instructions for proper use and care.
PRODUCT SPECIFICATIONS
Up to 78x
Magnification:
K20 (17.5x), K9 (39x), Barlow lens 2x (doubles magnification)
Eyepiece:
50mm
Aperture:
350mm
Focal Len�th:
1.3 lbs
Wei�ht:
Dimensions:
15.8" X 13.5" X 13.0"
Erecting Prism and Tabletop Tripod
Accessories:
COMPLETE OPTICAL TUBE ASSEMBLY
Focuser Draw
Tube
ft@
Erecting Prism
SETTING UP TRIPOD AND ATTACHING OPTICAL TUBE
1. Separate Tripod legs
and place on flat surface.
®
™
"
===
\
Focus Knob
Optical Tube Saddle Plate
i�
]
Barlow Lens
2. Align Optical Tube Saddle Plate
with Tripod Connector Screw.
Telescope! In order to achieve
JJ
�
Kellner 9mm Eyepiece
MTEL-50
Tripod Connector
Screw".
Tabletop Tripod
g
Kellner 20mm Eyepiece
3. Attach Optical Tube to Tripod
by tightening Tripod Connector
Screw.
