Related Manuals for Carson AIM MTEL-50
Summary of Contents for Carson AIM MTEL-50
-
Page 1: Specifications
SPECIFICATIONS Focal length: 350 mm Diameter of Objective Lens: 50 mm Eyepieces: K-9, K-20 Accessories: 2x Barlow Lens, 45 Corner Lens, Table Top Tripod ©2009 CARSON OPTICAL HAUPPAUGE NY 11788 www.carsonoptical.com MADE IN CHINA... - Page 2 mtel-50 Instruction Manual VISUAL KEY DIAGRAM VISUAL KEY 1. Main Tube 2. Diagonal Prism 3. Diagonal Prism Holding Screw 4. Eyepiece Lens 5. Eyepiece Holding Screw 6. Tripod Holder 7. Tripod Platform 8. Tripod Securing Screw 9. Focus Wheel 10. Mount Adjustment Handle 11.
- Page 3 mtel-50 Instruction Manual ASSEMBLY Take the tripod out of the pouch and extend the legs (11). Put the tripod holder (6) of the main tube (1) on to the tripod plat- form (7) and tighten it together with the tripod securing screw (8), make sure the tube is placed in the right direction as shown in the Take the tripod out of the pouch and extend the legs (11).
- Page 4 This product is designed and intended for ages 13 years and older. ©2009 CARSON OPTICAL HAUPPAUGE NY 11788 Carson | 2070 5th Avenue | Ronkonkoma, New York 11779 www.carsonoptical.com MADE IN CHINA Phone 631-963-5000 | Fax 631-427-6749 For information, call toll-free: 1-800-967-8427 info@carson.com | sales@carson.com | www.carson.com...
