- Page 1 Regumat S Operating instructions...
-
Page 2: Table Of Contents
Regumat S Table of contents Page General information ......................3 Validity of the instructions ........................3 Scope of delivery ............................ 3 Contact ..............................3 Symbols used ............................3 Safety-related information ....................3 Intended use ............................3 Warnings ..............................3 Safety instructions ..........................4 2.3.1... -
Page 3: General Information
Validity of the instructions The Regumat S heating circuit station enables connection to an unmixed heating circuit. These instructions are valid for the Regumat S station for unmixed heating circuits. The product is completed by the installation of a suitable pump. -
Page 4: Safety Instructions
Regumat S Safety-related information Safety instructions 2.3.6 Risk of injury due to the weight of the product We have developed this product in accordance with current safety requirements. Always wear safety shoes during mounting. Observe the following instructions for safe use. -
Page 5: Technical Description
Regumat S Technical description 3. Technical description 3.1.2 Design of the product assembly Design 3.1.1 Design of the station Fig. 1: Design of the station Upper shell Insertion block Product assembly Fig. 2: Design of the product assembly Wall bracket... -
Page 6: Functional Description
50. However, the supply and the return pipe can be swapped on site (see section 6.2 on page 10). The Regumat S enables the heating circuit to be shut off. It consists of a shutoff device with thermometers integrated in the handles. The check valve in the return pipe prevents incorrect circulation. -
Page 7: Technical Data
Max. Operating temperature for high- efficiency pumps with 95 °C universal thermal insulation Opening pressure f 20 mbar k vs value Connections Nominal size (DN) Fig. 5: Dimensions Regumat S Heating G 1 G 1 ½ G 2 circuit Nominal size external external external G 2 G 2... -
Page 8: Accessories And Spare Parts
Regumat S Accessories and spare parts 4. Accessories and spare parts Risk of scalding due to hot media! If the system was in operation, there is a risk of You will find the current accessories and spare part list on scalding due to unintentional escape of hot water our website. - Page 9 Regumat S Mounting Mounting steps Always mount the station upright, never inclined or lying down. Remove the upper shell (position in Fig. 1 on page Pull off the insertion block (position in Fig. 1 on page Remove the product assembly (position in Fig.
-
Page 10: Optional: Swapping The Supply And Return Pipe
Regumat S Mounting Carry out piping of the station. • All connections are designed with external threads and are flat sealing. • Observe the torques specified in the technical data for the union nuts. • Use the seals included in the scope of delivery. -
Page 11: Protective Equipotential Bonding/Earthing
Regumat S Commissioning Swap the supply and return pipe. Connect the pump to the heating circuit control of your system. Screw the connections tight. Commissioning Protective equipotential bonding/Earthing Filling and venting the station WARNING CAUTION Danger to life due to electric current ! -
Page 12: Maintenance
Regumat S Maintenance 8. Maintenance maintenance work! Carry out a visual inspection at least once a month. Pay CAUTION attention to whether moisture is escaping. If water is leaking, inform the responsible specialist tradespeople. Risk of scalding due to hot media! -
Page 13: Disposal
Regumat S Dismantling and disposal 10.3 Disposal NOTICE Risk of environmental pollution! Incorrect disposal can lead to environmental damage. Dispose of packaging materials in an environmentally friendly manner. If possible, recycle the components. Dispose of non-recyclable components according to local regulations. - Page 14 Oventrop GmbH & Co. KG · Paul-Oventrop-Str. 1 · 59939 Olsberg Tel. +49 2962 820 · Fax +49 2962 82400 · mail@oventrop.com · www.oventrop.com...
