- Page 1 SF SERIES SFM, SFM-DEF, SFP, SFV, SFVV, SFM-H, SFM-H-DEF, SFP-H, SFV-H, SFVV-H MODELS OPERATION & PARTS MANUAL P/N 111214 R4...
-
Page 2: Eu Declaration Of Conformity
EU Declaration of Conformity Finish Thompson Inc. hereby declares that the following machine(s) fully comply with the applicable health and safety requirements as specified by the EU Directives listed. The product may not be taken into service until it has been established that the drive motor for the centrifugal pump complies with the provisions of all relevant EU Directives. -
Page 3: Declaration Of Conformity
Declaration of Conformity Finish Thompson Inc. hereby declares that the following machine(s) fully comply with the applicable health and safety requirements as specified be the UKCA Directives listed. The product may not be taken into service until it has been established that the drive motor for the Drum and Container Pump complies with the provisions of all relevant UKCA Directives. -
Page 4: Table Of Contents
Technical Service department directly at the following address: Finish Thompson, Inc. 921 Greengarden Rd. Erie, PA 16501 U.S.A. Tel. 1-814-455-4478; Fax 1-814-455-8518 www.finishthompson.com; fti@finishthompson.com Index Introduction ........................4 Warranty, General Terms & Conditions ................5 Safety ..........................6 Important Safety Information for Pumping Flammable or Hazardous Substances ...7... -
Page 5: Warranty, General Terms & Conditions
Warranty, General Terms & Conditions Finish Thompson, Inc (manufacturer) warrants this pump product to be free of defects in materials and workmanship for a period of one year from date of purchase by original purchaser. If a warranted defect, which is determined by manufacturer’s inspection, occurs within this period, it will be repaired or replaced at the manufacturer’s option, provided (1) the product is submitted with proof of purchase date and (2) transportation charges are prepaid to the manufacturer. -
Page 6: For Your Own Safety
Safety Introduction This manual contains all the information needed for the correct installation, use and maintenance of your new Finish Thompson pump and accessories. It should be read and understood by all the personnel involved in installation, operating and servicing of the pump before it is started. -
Page 7: Important Safety Information For Pumping Flammable Or Hazardous Substances
IMPORTANT SAFETY INFORMATION FOR PUMPING FLAMMABLE OR HAZARDOUS SUBSTANCES Read these instructions before operating the pump and motor equipment. The manufacturer will not be responsible for any damage to property or to persons caused by improper use of the equipment. WARNING: It is the responsibility of the user to operate the pump in conformance with OSHA rules for dispensing liquids. -
Page 8: Specifications & Dimensions
PUMP SPECIFICATIONS MODEL SFM MODEL SFM-DEF MODEL SFP MODEL SFV MODEL SFVV Outer Tube Diameter 1-5/8" (41mm) 1-5/8" (41mm) 1-5/8" (41mm) 1-5/8" (41mm) 1-5/8" (41mm) Discharge Spout 1" (25mm) Barb 3/4" (19mm) Barb 1" (25mm) Barb 1" (25mm) Barb 1" (25mm) Barb Discharge Thread 1-1/4"... -
Page 9: Operation
OPERATION 1. Make sure the motor (electric or air) is properly installed on the pump tube and is in the off position. See motor instruction manual for installation instructions. 2. Insert the pump tube into the fluid to be dispensed and the hose into the container to be filled prior to starting the pump. -
Page 10: Disassembly
DISASSEMBLY & REASSEMBLY INSTRUCTIONS Disassembly 1. Cover, Impeller, & Diffuser Removal - Unthread the diffuser cover (item 18 or 19). Turn it clockwise (left-hand thread). See Figure 1 A & B. Unthread the impeller (item 17) turning it counter clockwise (right hand thread) using your hand while holding the coupling insert and coupling half (items 1 &... - Page 11 Disassembly Continued 3. Outer Tube Removal - Unthread the diffuser (item 15) turing it clockwise (left- hand thread). The shaft sleeve (item 13) will drop out of the inner tube by holding it in a vertical position. Remove the outer tube (item 14).
-
Page 12: Reassembly
Reassembly 1. Seal Installation - Take the head (item 6), and install a new seal (item 5). It is recommended to lubricate the seal with a compatible lubricant or water prior to pressing it in. Insert the open part of the seal into the lower bore of the head. - Page 13 Reassembly Continued 5. Shaft Installation - Slide the shaft down through the seal until the bearing engages the bearing bore in the head. Set the half coupling on the floor and push the pump down using the outer tube (item 14) for leveridge. Make sure the bearing (item 3) is flush with the top of the head (item 6).
-
Page 14: Exploded View - Sf Pump Tube
SF SERIES PUMP EXPLODED VIEW UNLESS OTHERWISE SPECIFIED DISTRIBUTION BLOCK DIMENSIONS ARE IN INCHES DEPT REC'D DEPT REC'D 921 GREENGARDEN ROAD PHONE: (814) 455-4478 TOLERANCES ARE: ERIE, PENNSYLVANIA 16501 FAX: (814) 455-8518 .XXX .005 PUMP ASSM INJ MOLD PRODUCT: .010 FRAC. -
Page 15: Pump Tube Spare Parts List
PUMP SPARE PARTS LIST PART NUMBER ITEM DESCRIPTION MODEL MODEL MODEL MODEL MODEL SFM-DEF SFVV COUPLING INSERT J100014 J100014 J100014 J100014 J100014 COUPLING HALF 111530 111530 111530 111530 111530 BEARING 111057 111057 111057 111057 111057 SHAFT (SFM/SFM-DEF = 316SS) (SFP/SFV/SFVV = ALLOY 625) 27”... - Page 16 PUMP SPARE PARTS LIST PART NUMBER ITEM DESCRIPTION MODEL MODEL MODEL MODEL MODEL SFM-DEF SFVV INNER TUBE (SFM/SFM-DEF/SFP/SFV = POLYPROPYLENE) (SFVV = PVDF) 27” 108373-2 108373-2 108373-2 108373-2 108373-7 40” 108373-3 108373-3 108373-3 108373-3 108373-8 48” 108373-4 108373-4 108373-4 108373-4 108373-9 54”...
-
Page 17: Troubleshooting
PUMP SPARE PARTS LIST PART NUMBER ITEM DESCRIPTION MODEL MODEL MODEL MODEL MODEL SFM-DEF SFVV DIFFUSER COVER - HIGH FLOW POLYPROPYLENE 111212-1 111212-1 111212-1 PVDF 111212-2 111212-2 DIFFUSER COVER - HIGH HEAD POLYPROPYLENE 111213-1 111213-1 111213-1 PVDF 111213-2 111213-2 *Recommended spare parts DRUM PUMP TROUBLESHOOTING General Notes: •...
