- Page 1 All manuals and user guides at all-guides.com Vario Vesa Adapter kit INSTRUCTION MANUAL SLA078 SLA079 SLA080 SKU: https://sim-lab.eu/shop/product/vario-vesa-adapter-kit-3-pieces-1143 info@sim-lab.eu Copyright© 2021 - Sim-Lab Products | Revision 0.9...
- Page 2 All manuals and user guides at all-guides.com Required tools: 2/4/5/6 mm Assembly of the Vesa adapter *Base value of the set screws...
- Page 3 All manuals and user guides at all-guides.com Assembly of the Vesa holder *Base value of the set screws 24.00 Attaching the Vesa adapter to the monitor...
- Page 4 All manuals and user guides at all-guides.com Attaching the Vesa holder to the crossbar/sidearm Attaching the monitor assembly to the Vesa holder...
- Page 5 All manuals and user guides at all-guides.com Adding the set-screws to fixate the monitor and to fine tune if needed DETAIL A SCALE 2:1...
- Page 6 All manuals and user guides at all-guides.com Fine tune positioning of the monitors...
- Page 7 All manuals and user guides at all-guides.com VESA 200 mounting BenQ adapter mounting...
-
Page 8: Parts List
All manuals and user guides at all-guides.com Parts list Hardware kit Part name Note VESA Vario pin holder Units VESA Vario guide block 1.95 Units VESA Vario pin 8 mm (Stainless Steel) Units Bolt – DIN 912 (Black steel, 16mm, M8) Units Mounts whole plate to monitor crossbar/sidearm Bolt - DIN 7991 (Black steel, 12mm, M6)
