INSTALLATION INSTRUCTIONS
安装说明书
8785T
缸边(台面)式浴缸花洒龙头
安装之前
所有的资料是按最新出版的产品资料编写而成。科
勒公司保留任何时候不经通知即可改变产品特性、
包装或产品可供类型的权利。
说明书包括重要的安装、保养及清洁方面的内容，
请把这些资料交给用户阅读。
注意事项：
1.一定要先彻底冲洗供水管以清除管道中的杂质。
2. 切换器正常工作的最小压力为0.05MPa(0.5bar)。
3.花洒最高工作压力：0.5MPa(5bar)。水压超过
0.5MPa(5bar)须安装减压阀。花洒最高工作温度及
环境温度：60ºC。请特别注意花洒同花洒连接的臂
管须远离浴霸，否则可能损坏花洒及其密封件，甚
至对使用者造成伤害。
使用说明
逆时针旋转右把手为开，顺时针旋转左把手为开。
安装尺寸
A
G1/2˝
60
Ø57
G1/2˝
305
1107943-2-E
Deck-Mount Bath & Shower Faucet
BEFORE YOU BEGIN
All information is based on the latest product
information available at the time of publication.
Kohler Co. reserves the right to make changes in
product characteristics, packaging, or availability at
any time without notice.
Please leave these instructions for the consumer.
They contain important information.
NOTES:
1.Flush the water supply pipes thoroughly to remove
debris.
2.The minimum inlet water pressure for the diverter is
0.05MPa(0.5bar).
3. The highest working pressure for handspray is
0.5MPa(5 bar). If it exceeds 0.5MPa(5 bar), a
pressure reducer is needed. The highest water and
environment temperature is 60ºC. Please keep
handspray, shower head and the shower arm away
from heater, or it may become damaged and cause
injury to the user.
HANDLE OPERATION
Right handle opens with one-quarter turn
counter-clockwise. Left handle opens with
one-quarter turn clockwise.
ROUGH-IN DIMENSIONS
A 向
G1/2˝
G1/2˝
168
G1/2˝
1
