INSTRUCTION MANUAL
NT935BH ETH
1MN0191 REV. 0
operates with ISO9001 certified quality system
TECSYSTEM S.r.l.
20094 Corsico (MI)
Tel.: +39-024581861
Fax: +39-0248600783
http://www.tecsystem.it
R. 1.3 16/05/23
ENGLISH
"Translations of the original instructions"

Advertisement

loading
Need help?

Need help?

Do you have a question about the NT935BH ETH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TECSYSTEM NT935BH ETH

Summary of Contents for TECSYSTEM NT935BH ETH

  • Page 1 INSTRUCTION MANUAL NT935BH ETH 1MN0191 REV. 0 operates with ISO9001 certified quality system TECSYSTEM S.r.l. 20094 Corsico (MI) Tel.: +39-024581861 Fax: +39-0248600783 http://www.tecsystem.it R. 1.3 16/05/23 ENGLISH “Translations of the original instructions”...
  • Page 2 INTRODUCTION First of all we wish to thank you for choosing to use a TECSYSTEM product and we strongly suggest that you read this instruction manual carefully: You will understand the use of the equipment and therefore be able to take advantage of all its functions.
  • Page 3 ………………………………….. • TELNET SCREEN ………………………………….. • IP PARAMETER PROGRAMMING MENU ………………………………….. 11) Pt100 EXTENSION CABLE TECHNICAL SPECIFICATIONS ………………………………….. 12) FCD FUNCTION — ………………………………….. 13) WARRANTY REGULATIONS ………………………………….. 14) TROUBLESHOOTING ………………………………….. 15) EQUIPMENT DISPOSAL — ………………………………….. 16) USEFUL CONTACTS NT935BH ETH...
  • Page 4 POWER SUPPLY The NT935BH ETH can be supplied by 85 to 260 Vac-Vdc, irrespectively of polarity in Vdc. Before using it, make sure the power cable is not damaged, knotted or pinched. Do not tamper with the power cable.
  • Page 5 1 Terminal 4 pitch poles 3.81 for BLDC output Code: 2PL0368 - Screws tightening torque 0.25Nm ATTENTION: always install the device using the terminals included in the pack. The use of terminals other than those included with the control unit might cause malfunctions. NT935BH ETH...
  • Page 6 NT935BH ETH TECHNICAL SPECIFICATIONS POWER SUPPLY 85-260 Vac-Vdc Supply rated values 50/60HZ ● Vdc with invertible polarities INPUTS ● 4 inputs for three-wire Pt100 RTD sensors (max section 1.5mm²) ● Connections on removable terminal boards ● Input channels protected against electromagnetic interference Thermoresistances cable compensations 500m (1mm²)
  • Page 7 TECHNICAL SPECIFICATIONS NT935BH ETH ● NORYL 94 _V0 housing ● Absorption 7.5VA ● Digital linearity of sensor signal ● Self-diagnostic circuit Protection treatment of the electronic part Optional DISPLAY AND DATA MANAGEMENT ● 2 x 13 mm displays with 3 digits to display temperatures, messages and channels ●...
  • Page 8 T-max mode selection (red) LED FAN 2 TRBH / RELAY (yellow) LED Man mode selection (yellow) LED Display mode selection key Auto mode selection (green) LED Fixing blocks Scan mode selection (yellow) LED UP key Fixing blocks DOWN key NT935BH ETH...
  • Page 9 We suggest carrying out the control unit LED test regularly. For this operation, press the TEST key briefly; all the displays turn on for 2 seconds. If one of the LEDS does not work, please return the control unit to TECSYSTEM for repair. ALARM RELAY TEST This function allows you to carry out a test of the relay operation without having to use further devices.
  • Page 10 Drill a hole in the panel sheet with dimensions of 92 x 92 mm. 1MN0007 REV. 0 Control unit Panel hole dimensions (+0.8 mm tolerance) Identification label Secure the appliance firmly by means of the supplied fixing blocks. 1MN0008 REV. 0 Control unit Locking screws Fixing blocks Cross-head screwdriver #1X100mm NT935BH ETH...
  • Page 11 ELECTRICAL CONNECTIONS NOTE: all the useful information on the TRBH system's electrical connections is available in the TRBH SYSTEM manual. NT935BH ETH 1MN0171 REV.0 1) Pt100 sensors (white-red-red) RJ45 Ethernet output, Link-Activity led, see indication on page 30. 2) Power supply 85-260Vac-cc 50/60Hz.
  • Page 12 POWER SUPPLY The NT935BH ETH can be supplied by 85 to 260 Vac-Vdc, 50/60 Hz irrespectively of polarity in Vdc (terminals 40-42). This particularity is obtained thanks to the use of a tested power supply, of new conception and realisation, which frees the installer from any uncertainty regarding the correct Vac or Vdc power supply.
  • Page 13 PROGRAMMING NT935BH ETH STEP PRESS EFFECT PRESS NOTES Press and hold the PRG button until the display shows SET PRG Select PRG SET to proceed with programming or PRG 1 PRG 1 default data to load the default values The ALARM threshold for (CH 1-2-3) is displayed.
  • Page 14 ERR ALL. = ALARM ≥ TRIP The device automatically prepares itself for the programming step of the error committed NOTE: EVERY TIME THE CONTROL UNIT PROGRAMMING, WITH CONFIRMATION OF DATA SAVING, THE VALUES STORED IN T-MAX ARE RESET AT THE TIME OF STORING. NT935BH ETH...
  • Page 15 Pt100 sensors c) damage to the Pt100 inputs of the control unit. TECSYSTEM S.r.l. has designed its own special cable to transfer the measurement signals, CEI-compliant, with all the protection requirements provided for mod. CT-ES NOTE: the use of cables not complying with the above could cause possible reading anomalies.
  • Page 16 Activation of the functions: VOTING (shown below) or FCD (on page 31) in relation to the system conditions. CAL message display: the indication appears when the measurement circuit is damaged. The temperature values displayed might be incorrect. Return the control unit to TECSYSTEM for repairs. VOTING FUNCTION The voting function derives from the redundancy concept that consists in duplicating the components of a system to increase their reliability.
  • Page 17 FAN2 relay. FAN 2 threshold ON, steps 22-23 pages 13-14, (eg. ON at 45°C – fixed switch-off (OFF) at 35°C). Depending on the set threshold, the Fan OFF delta will always be 10°C with respect to the programmed threshold ON NT935BH ETH...
  • Page 18 The ETH module is always in slave mode. The NT935BH ETH control unit is in communication with the network only when it is in temperature reading mode, while it is inactive when in the following modes: display, programming and test relays.
  • Page 19 Trip thresholds and that the Fan-on thresholds must be higher than the Fan-off thresholds. In case you try to set these thresholds incorrectly, the control unit NT935BH ETH will not proceed with the programming and storage of data, therefore in subsequent readings will read the data from the previous schedule.
  • Page 20 UNACCEPTABLE DATA There are some programmings that are not acceptable as they are not foreseen by the NT935BH ETH instrument; such data will be discarded without producing any error message (EXCEPTION CODE). → CH 1-2-3: channels that cannot be disabled →...
  • Page 21 Fan_1 ON TRBH 1°C ÷ 200°C (*) SPEED 2’compl. sign FREE See Notes 1° to÷ 240° 2’compl. sign Fan_2 ON TRBH 1°C ÷ 200°C (*) SPEED 2’compl. sign FREE See Notes (*) for version –40°C ÷ + 200°C NT935BH ETH...
  • Page 22 1°C ÷ 240°C 2’compl. sign (AL) alarm set point 1°C÷200°C (*) 2’compl. Ch4 temper. 1°C ÷ 240°C 2’compl. sign (TRP) trip set point 1°C÷200°C (*) TRBH_1 speed M1-M6 motors See the TRBH TRBH_1 motors status notes on page Bars 1/2 NT935BH ETH...
  • Page 23 Data LO Notes 1 Notes 2 W: write (10) RW: read/write Ch1 story Ch1 status See Notes CHx Ch2 story Ch2 status See Notes CHx Ch3 story Ch3 status See Notes CHx Ch4 story Ch4 status See Notes CHx NT935BH ETH...
  • Page 24 ALARM FAN_2 FAN_1 1=ON 1=ON Relay 1=ON Relay 1=ON Relay 1=ON CPU ERROR BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0 FAULT FAULT PT ERROR FCD Fault TRBH EST TRBH NT935BH ETH...
  • Page 25 • PRG programming. • Test of the relays. The FAIL SAFE function is temporarily disabled and the FAULT relay switches. ATTENTION: accessing at the relay test mode will temporarily disable the failsafe function, the relays with function enabled switch (ALARM-TRIP-FAULT). NT935BH ETH...
  • Page 26 X Windows Vista, 7, 8. ETH0 CONNECTIONS Using an Ethernet cable, connect the ETH0 RJ45 of the NT935BH ETH control unit to the Ethernet card of a PC. TELNET ENABLING Use the Telnet program to set the Ethernet IP parameters.
  • Page 27 13) Type in: OPEN 14) Press ENTER 192.168.10.120 9999 15) Type in: 16) Press ENTER 17) Enter the Password: TECS 18) Press ENTER Note: In this screen we have the MAC address and the software version of the ETH port available. NT935BH ETH...
  • Page 28 IMPORTANT INFORMATION For a correct operation of the device it is advised not to access or modify menus 2-3-4-7. Changing the values contained in the indicated menus could lead to communication anomalies with loss of IP Ethernet communication. NT935BH ETH...
  • Page 29 • At the end of the operation, the system will ask if you wish to modify the Telnet Password: Type in: to modify the Telnet Password. not to modify the Telnet Password and go to the following step. NT935BH ETH...
  • Page 30 4. Standards CEI 20.35 IEC 332.1 5. Maximum operating temperature: 90°C 6. Configuration: 4 triples of three twisted and coloured conductors 7. Screen on Cu/Sn 8. Fireproof PVC sheath 9. Outer diameter 12 mm 10. Standard configuration in 100 m coils NT935BH ETH...
  • Page 31 "Tecsystem s.r.l. General Sales Conditions", which can be consulted on the website www.tecsystem.it and/or in the stipulated purchase contract. The warranty is considered valid only when the product is damaged by causes attributable to TECSYSTEM srl, such as manufacturing or components defects.
  • Page 32 B2 bar, TRBH SYSTEM manual Check the connection between the control unit and the BAR B1 The control unit signals BH ERR RS1 Control box, TRBH SYSTEM manual. Contact the TECSYSTEM Technical Department if the problem persists. NT935BH ETH...
  • Page 33 Returning of used electrical appliances: contact TECSYSTEM or the TECSYSTEM agent to receive information on correct disposal of the appliances. TECSYSTEM is aware of the impact its products have on the environment and asks its customers active support in the correct and environmentally-friendly disposal of its devices.
