ITEM# xxxx
MODEL# 7260015HD
ASSEMBLY INSTRUCTIONS GUIDE
12in Stacker - 6 Shelf
Questions, problems, missing parts?
Before returning to the store, call Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
Phone Number: 1-800-527-0313
HOMEDEPOT.COM
THANK YOU
We appreciate the trust and confidence you have placed in StyleWell through the purchase of this closet tower kit. We strive to continually
create quality products designed to enhance your home.Visit us online to see our full line of products available for your home improvement
needs. Thank you for choosing StyleWell!
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for StyleWell 7260015HD
Summary of Contents for StyleWell 7260015HD
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in StyleWell through the purchase of this closet tower kit. We strive to continually create quality products designed to enhance your home.Visit us online to see our full line of products available for your home improvement...
- Page 2 Pre-assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to assemble this product. TOOLS REQUIRED Phillips Drill &...
- Page 3 Pre-assembly (continued) PACKAGE CONTENTS ITEM # xxxx / MODEL #7260015HD Part Description Quantity Part Number Code 38167015010 LEFT PANEL 38167015020 RIGHT PANEL 37260015030 37260015040 BOTTOM 37260015050 ADJUSTABLE SHELF 37260015060 BACK HOMEDEPOT.COM : # 1-877-527-0313 Please contact for further assistance.
- Page 4 Assembly Arrange the Left Panel (A) and Right Panel (B) as shown. In the unfinished drilled edge, insert the nuts into the LARGER holes with a hammer. Thread adjustable leveling feet into the nuts. A - x1 B - x1 Insert the connectors as shown.
- Page 5 Assembly Install the safety strap to the Back (F). Do not fully tighten the screw in this step. Insert the connectors as shown. Be sure all connectors are fully seated and placed correctly. 1 - x7 F - x1 You may need to lightly tap connectors with a hammer to fully insert.
- Page 6 Assembly Install connectors into the Bottom (D). Be sure all connectors are fully seated and placed correctly. You may need to tap connector with a hammer to fully insert. Insert wood dowels (2). 1 - x4 D - x1 2 - x4 must be fully seated HOMEDEPOT.COM...
- Page 7 Assembly Assemble the Left Panel (A) and Back (F) by inserting the connectors as shown. Turn three connectors clockwise to lock in place. finished edge Lock Assemble the Bottom (D) to the Left Panel (A) by inserting the connectors and wood dowels as shown.
- Page 8 Assembly Assemble the Right Panel (B) by inserting the connectors as shown. Turn five connectors clockwise to lock in place. finished edge finished edge Lock HOMEDEPOT.COM : # 1-800-527-0313 Please contact for further assistance.
- Page 9 Assembly If you purchased an additional 12in Stacker - 6 Shelf unit, skip to step 11. If you only have one 12in Stacker - 6 Shelf unit continue to step 8. With the help of another person, carefully assemble the next step as shown. Assemble the Left Panel (A), Right Panel (B) and Back (F) to the Top (C) by inserting the connectors as shown.
- Page 10 Assembly Warning unit MUST be fastened to the wall. Use a level and adjust adjustable leveling feet to be sure it is square. OPTION 1: Attachment into a wall stud (preferred method) Using a stud finder, locate a stud in the wall. Place your unit against the wall, with the safety strap aligned in this location.
- Page 11 Assembly Insert the shelf supports (6) into the Left & Right Panels (A & B) in the desired locations. Insert the four Adjustable Shelves (E). 6 - x16 E - x4 HOMEDEPOT.COM : # 1-800-527-0313 Please contact for further assistance.
- Page 12 Assembly This step is for purchasing a second 12in Stacker - 6 Shelf unit and stacking it on top of the one that was just assembled. You will want to assemble the second unit the same, EXCEPT without placing the nut insert (4) and adjustable leveling feet (3).
- Page 13 Assembly Assemble the "first" unit assembly to its Top (C) by inserting the connectors as shown. Turn five connectors clockwise to lock in place. With the help of another person, you will need to turn the unit 90 degrees in order to lock the connector on the Back (F). Carefully stand the unit upright with the help of another person.
- Page 14 Assembly Warning unit MUST be fastened to the wall. Use a level and adjust adjustable leveling feet to be sure it is square. OPTION 1: Attachment into a wall stud (preferred method) Using a stud finder, locate a stud in the wall. Place your unit against the wall, with the safety strap aligned in this location.
- Page 15 Assembly Insert the shelf supports (6) into both of the Left & Right Panels (A & B) in the desired locations. Insert the eight Adjustable Shelves (E). E - x8 6 - x32 HOMEDEPOT.COM : # 1-800-527-0313 Please contact for further assistance.
- Page 16 Questions, problems, missing parts? Before returning to the store, call StyleWell Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday PHONE NUMBER - 1-800-527-0313 HOMEDEPOT.COM Retain this manual for future use.
