HYPERION-402
Managed Industrial Ethernet Switch
The software and full instructions needed to properly configure
BitStream's hardware can be downloaded using the QR code
or website link.
Website:
https://bitstream.pl/en/instructions/
Password:
Bitstream2021@
1.
Marking
HYPERION-402(.X)-Y-(L)-(Z)-K-U
Hyperion-402
Standard
Dedicated version for substations
Versions:
32x RJ45 (10M/100M/1G) + 4x SFP/ SFP+ (1G/2.5G/10G)
24x RJ45 (10M/100M/1G) + 8x SFP (100M/1G) + 4x SFP/ SFP+ (1G/2.5G/10G)
16x RJ45 (10M/100M/1G) + 16x SFP (100M/1G) + 4x SFP/ SFP+ (1G/2.5G/10G)
8x RJ45 (10M/100M/1G) + 24x SFP (100M/1G) + 4x SFP/ SFP+ (1G/2.5G/10G)
32x SFP (100M/1G) + 4x SFP/ SFP+ (/1G/2.5G/10G)
8x RJ45 (10M/100M/1G) + 16x SFP(100M/1G) + 4x SFP/ SFP+ (1G/2.5G/10G)
Routing functions (optional)
Standard
Static routing
Optional POE
No PoE
8x HIGH PoE (802.3bt) PSE to 90W per port
16x HIGH PoE (802.3bt) PSE to 90W per port
24x HIGH PoE (802.3bt) PSE to 90W per port
32x HIGH PoE (802.3bt) PSE to 90W per port
Additional functions
Option for version with 32 SFP slots
Standard built-in secondary ITU K.44 surge protection for the transmission path, 4kV
10/700µs on RJ-45 port modules
Power supply
Power supply 36-60VDC, for PoE between 46-57VDC
Power supply 80-350V DC, 75-240VAC
Redundant 36-60VDC, for PoE between 46-57VDC
Redundant 80-350 V DC, 75-240 VAC
Rev.
1.15
Quick Start Guide
www.bitstream.pl
SHORT USER MANUAL HYPERION-402
(.X)
Y
(L)
(Z)
-
2
1
2
3
4
5
2
7
-
L3
S8P2b
S16P2b
S24P2b
S32P2b
28.12.2023
K
U
-
3
-
K
7
1
C
2
77p
1
CCp
2
1/7

Advertisement

loading
Need help?

Need help?

Do you have a question about the HYPERION-402 and is the answer not in the manual?

Questions and answers

Related Manuals for Bitstream HYPERION-402

Summary of Contents for Bitstream HYPERION-402

  • Page 1 Quick Start Guide www.bitstream.pl HYPERION-402 Managed Industrial Ethernet Switch The software and full instructions needed to properly configure BitStream's hardware can be downloaded using the QR code or website link. Website: https://bitstream.pl/en/instructions/ Password: Bitstream2021@ Marking HYPERION-402(.X)-Y-(L)-(Z)-K-U Hyperion-402 (.X) Standard Dedicated version for substations Versions: 32x RJ45 (10M/100M/1G) + 4x SFP/ SFP+ (1G/2.5G/10G)

  • Page 2: Device Front Panel

    2 - Option available only for devices without PoE 3 - Option available only for version 402-4 and 402-7 Device front panel Fig 1. Back panel Hyperion-402 depending on the device version. Fig 2. Front panel Hyperion-402 depending on the device version. Description: –...
  • Page 3 LEDs (depending on the speed of the insert) should light up green to indicate a valid link on the link. • External LEDs - show 1Gbps transmission link (activity - flashing); • Internal LEDs - show 100Mbps transmission link (activity – flashing); Rev. 1.15 SHORT USER MANUAL HYPERION-402 28.12.2023...
  • Page 4 7 or 77p - power supply 36-60V DC, for PoE in the range 46-57V DC;  version C or CCp- supply 80-350V DC or 75-240V AC;  AC power supply does not support PoE function;  Power supply AC+AC or DC+DC only; Rev. 1.15 SHORT USER MANUAL HYPERION-402 28.12.2023...

  • Page 5: First Start-Up

    CLI. If you enter the password incorrectly five times via telnet or CLI or by entering the %bitstream% command in the password field, a temporary code will be generated. Pass the code to the BitStream Support Department available from 8:00 am to 4:00 pm at telnet 817438643 ext. 28 or Rev.

  • Page 6: Electromagnetic Compatibility

    Quick Start Guide www.bitstream.pl email: support@bitstream.pl , to receive a temporary 6-hour password to access the device. If you cannot log into the device (due to incorrectly entered configuration e.g.: vlan etc.), you can restore the default configuration using the "DEF" button. Holding the "DEF" button for 5 seconds will remove the configuration without losing the IP address, and holding the button for more than 10 seconds will restore the configuration to factory settings.
  • Page 7 9.4 Security BITSTREAM devices are designed in terms of safety and operation on the basis of PN-EN-60950 standard. Configuration and installation of the device should be performed by persons with necessary authorizations after reading the operation manual. The manufacturer is not responsible for any events resulting from not following the detailed instructions of use and installation.
