Bitstream HYPERION-402 Quick Start Manual

HYPERION-402
Managed Industrial Ethernet Switch
1 D
5
8
9
5
Description:
1 – Ethernet ports connectors (SFP or RJ45) depending on version
2 – Management port connector (ETH with RJ-45 10/100M)
3 – Power connectors
4 – GND clamp with screw
5 – Signalling LEDs
6 – Ethernet port connectors
7 – DEF – button for restoring the default configuration
8 – Console RS-232, 115 200bps
9 – Mechanical components for mounting in a 19" rack (Included) - front or rear mount version
REV. 1.08
Quick start manual for
EVICE PANEL
4
3
Fig 1. Back panel Hyperion-402 depending on the device version
Fig 2. Front panel Hyperion-402 depending on the device version
1G/2,5G/10G (SFP/SFP+)
SHORT USER MANUAL HYPERION-402
H-402 - www.bitstream.pl/ en/
6
7
1
–
module Central Unit
2
2021.03.31 1/6
