Bitstream HYPERION-105 Short User Manual

Gigabit ethernet industrial switch
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

HYPERION-105
Gigabit Ethernet industrial switch
BitStream hardware using the QR code or website link.
Websites:
https://bitstream.pl/en/instructions/
Password:
Bitstream2021@
Designations
1.
HYPERION-105(.X)-Y-(IO)-(Z)-K-U
Hyperion-105
standard version
version dedicated to power substations
Versions available
8xRJ45(10/100M) + 2xSFP (100M/1G/2.5G)
4xRJ45(10/100M) + 2xSFP (100M/1G/2.5G) + 2xSFP(100M/1G)
4xRJ45(10/100/1000M) + 2xSFP(100M/1G/2.5G) + 2xSFP(100M/1G)
Additional interfaces
standard version
1x digital input, 2x relay outputs
2x 1-wire interface dedicated to the MOD-EXT module or T/H sensors
PoE option
no PoE
4x PoE ++ (802.3at) PSE4x PoE ++ (802.3at) PSE (option for HYPERION-105-5)
4x High PoE (802.3bt) PSE
8x High PoE (802.3bt) PSE
Overvoltage protection
4kV 10/700µs ITU K.44 on RJ 45 ports
Power
Redundant power supply in the range of 20 to 60V DC for versions with PoE , isolated
Operation of the PoE function requires power supply in the range of 45 to 57V DC
PoE + 802.3at (up to 30W) 52 to 57V
PoE ++ 802.3at (up to 60W) 55 to 57V
High PoE 802.3bt (up to 90W) 55 to 57V
Legend
1 – for the PoE version , the maximum power available on all RJ45 ports is 240W
-
2
option not available in Hyperion-105(.x)-1 version
3 -
option available only on Hyperion-105(.x)-5
4 – ITU K.44 protection only in the transmission path
REV.
1.24
HYPERION-105 Quick start manual
https://bitstream.pl/en/
SHORT USER MANUAL HYPERION-105
(.X)
Y
(IO)
(Z)
-
2
1
3
5
-
IO
IO1W
-
S4P2
S4P2b
S8P2b
3/04/2024
K
U
3
2
4
K
1
77p
1/8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HYPERION-105 and is the answer not in the manual?

Questions and answers

Related Manuals for Bitstream HYPERION-105

Summary of Contents for Bitstream HYPERION-105

  • Page 1 2x 1-wire interface dedicated to the MOD-EXT module or T/H sensors IO1W PoE option no PoE 4x PoE ++ (802.3at) PSE4x PoE ++ (802.3at) PSE (option for HYPERION-105-5) S4P2 4x High PoE (802.3bt) PSE S4P2b 8x High PoE (802.3bt) PSE...
  • Page 2 HYPERION-105 Quick start manual https://bitstream.pl/en/ Front panel of the device Fig. 1. Hyperion-105 front panel – Ground clamp, – Power connectors, – Ethernet ports – e.g. 8/4x RJ45 + 2/4x SFP, – DEF – button for restoring the default configuration, –...
  • Page 3 HYPERION-105 Quick start manual https://bitstream.pl/en/ 2.2. D ESCRIPTION OF DEVICE CONNECTORS Description of ETH RJ45 connectors: Fig. 3. Appearance and numbering of RJ45 connector pins. The device protects ITU K.44 only in the transmission path. They do not protect the PoE module in the switch.
  • Page 4 HYPERION-105 Quick start manual https://bitstream.pl/en/ 2.3. I/O INTERFACE CONNECTOR DESCRIPTION OPTION Appearance and numbering of IO connector pins. Fig. 4. The arrangement of individual signals for IO contacts is shown in the table below. interface Destiny Pin description IN – input contact , Potential-free input COM –...
  • Page 5 HYPERION-105 Quick start manual https://bitstream.pl/en/ ATTENTION! In the connector, the first 4 pins are dedicated to connecting the MOD-EXT-IO module, while the next 4 pins are for connecting the T/H sensor 2.5. D ESCRIPTION OF SLOTS The device has two or four slots for SFP modules. The range and type of optical connector depends on the type of SFP insert.

  • Page 6: Safety Of Use

    CLI. If you enter the password incorrectly five times via telnet or CLI, or by typing % bitstream % in the password field , a temporary code will be generated. The code should be submitted to the BitStream Support Department available from 8:00 to 16:00 on tel.

  • Page 7: Data Transmission

    ✓ IEEE 802.3az EEE ✓ IEEE 802.3af/ at type 1/2 - power per port 30W maximum on all ports 240W ✓ IEEE 802.3at PoE ++ - power per port 90W ( Option available only in Hyperion-105.x-5 version), maximum on all ports 240W ✓...
  • Page 8 HYPERION-105 Quick start manual https://bitstream.pl/en/ 10. Completion of the product ready for sale Hyperion-105 1 piece. Quick Start Manual 1 piece. CE Declaration of Conformity 1 piece. Warranty Card 1 piece. REV. 1.24 SHORT USER MANUAL HYPERION-105 3/04/2024...
