- Page 1 Rock-Steady Folding Band Saw Outfeed Kit Instructions Effective June 2024 Review full instructions prior to use for important safety information. Always check Rockler.com to confirm that you are using the most recent version of instructions for your product.
-
Page 2: General Safety Warnings
• Keep children and bystanders away from the tool the instructions and safety warnings for your product (see the instructions link on the product page at Rockler.com). operating area; • Do NOT use power tools in explosive environments, or in the presence of flammable liquids, fumes or dust;... - Page 3 PRODUCT SPECIFIC SAFETY WARNINGS > Ensure table feet are positioned flat; do not use on sloped > Any table created with the Rock-Steady Folding Band Saw or uneven ground. Outfeed Kit is NOT intended to serve as a workbench – only as a table to support material being cut on the band saw.
-
Page 4: Parts List
PARTS LIST Quantity Quantity Saw Bracket 3/8"-24 Jam Nut Height-Adjustment Bracket 10 1/4"-20 x 3/4" Carriage Bolt Tabletop Bracket 11 5/16"-18 x 1" Hex Bolt Safety Locking Pin (with Lanyard) 12 5/16" Washer 1/4"-20 x 2" Flathead Bolt 13 5/16"-18 Nylon Insert Locknut 1/4"... - Page 5 Fig. 1 The Rock-Steady Folding Band Saw Outfeed Kit is compatible ONLY with 14" or larger band saws. You will need to drill holes in the back edge of your band saw’s table to mount the Rock-Steady Folding Band Saw Outfeed Kit. Fig.
- Page 6 Fig. 4 Drill Holes for Pins Here are some additional things to keep in mind as you design your tabletop: > The surface of the outfeed table must always be flush • The tabletop must be at least 36" long to allow the Adjustable with or slightly below the surface of the saw’s table to Leg (15) to retract and fold up within the area of the top.
- Page 7 Fig. 5 Attach Leg to Tabletop 1. Attach the Leg Base (16) to the Adjustable Leg (15) with that the heads of the 1/4"-20 x 2" Flathead Bolts (5) used the two 5/16"-18 x 1 ⁄ " Hex Bolts (14) and two 5/16"-18 to mount the Adjustable Leg (15) to the tabletop will sit Nylon Insert Locknuts (13).
- Page 8 3. Carefully lift your outfeed tabletop, with Adjustable Leg (15) 8. Check to make sure the table is still positioned correctly. deployed, and position it at the back of the saw, resting Align the saw end of your outfeed tabletop with the back edge of the Tabletop Brackets (3).
- Page 9 12. Use the carpenter’s level to check the outfeed tabletop and saw table front to back and left to right. Make any necessary adjustments to the Height-Adjustment Brackets (6), using the fine-adjustment Hex Bolts (8), and/or to the leveler feet on the Adjustable Leg (15) to fine-tune the outfeed table alignment.
- Page 10 3. On the Adjustable Leg (15), press the blue paddle nearest Fig. 9. the leveler feet and carefully retract the Leg as far as it will go, until it locks. Check Rockler.com for updates. If you have further questions, please contact our Technical Support Department at 1-800-260-9663 or support@rockler.com...
- Page 11 Shop Drawing Adjustable Leg Mounting Hole Template Scale: 1" = 1"...
- Page 12 78625 Rockler Companies, Inc. 1-800-279-4441 Rev 0624 4365 Willow Dr. Medina, MN 55340 www.rockler.com...
