Drill Press Table Mounting Instructions
View from bottom of
Drill Press Table
2"
Position the screw-in insert
centered on the metal
table and 2" from the edge
22796
Drill press
collumn
Metal table
1. Position Rockler table on existing metal drill press table, centered side-to-side
and 1/4" from the drill press column.
2. Locate the position of the screw-in inserts on the underside of the Rockler table
2" from the edge of the metal table, and centered front-to-back on the metal drill
press table.
3. On the bottom side of the Rockler table, drill two 1/2" x 5/8" deep holes and
install the screw-in insets using the #5 x 5/8"screws provided.
4. Thread the two 5/16"x3" threaded studs into the inserts, slide on the hold down
clamps, and position as shown. Clamp the Rockler table to the metal drill press
table with the 2" star knob.
1. 28
2. 1/2" thick table insert 4" x 8"
3. Mounting Hardware consisting of:
W O O D W O R K I N G
2"
Packing list
1
⁄
" x 21" melamine coated
2
MDF surface
2- Hold down clamps
2- 5/16" x 3" studs
2- 2" knobs
2- washers
6- #5 x 5/8" screws
2- 5/16"x 18 screw-in insert
A N D H A R D W A R E
© Rockler Companies Inc. 2000
New drill press table
Existing
table
®
Screw
insert
Hold
down
