Summary of Contents for Rockler 57896
- Page 1 Small Piece Holder Instructions Effective July 2019 Review full manual instructions prior to use for important safety information. Always check Rockler.com to confirm that you are using the most recent manual version for your product.
-
Page 2: General Safety Warnings
• Keep children and bystanders away from the tool operating area; Instructions link on the product page at Rockler.com). • Do NOT use power tools in explosive environments, or in the presence of > Before using another tool with this product, flammable liquids, fumes or dust;... - Page 3 SAFETY WARNING KEY Danger indicates a hazardous situation that, if not avoided, will result in death or serious injury. Warning indicates a hazardous situation that, if not avoided, could result in death or serious injury. Caution indicates a hazardous situation that, if not avoided, may result in minor or moderate injury or property damage.
- Page 4 Assembly 1. Screw the Handles into the Left Handle Fence and the Right Handle Base. THESE WARNINGS PERTAIN 2. Install the two Hold-Down Pins diagonally TO ALL REMAINING STEPS: across from each other – one in the Adjustable Fence and the other in the Left Handle Fence.
- Page 5 Failure to extend the workpiece beyond the front of the jig could result in damage to the jig and the workpiece. Do NOT allow the Small Piece Holder to contact the bit. 2. Place workpiece between the Left Hand Fence and the Adjustable Fence. Workpiece must be placed against the abrasive face of the Left Handle Fence, with the piece extending beyond the front of the jig, far...
- Page 6 4. Loosen the Hold Down Pins and lower them until they’re snug against the top of your workpiece. Use the included hex wrench to tighten them in place. Fig. 3. Failure to fully tighten the adjustable fence may cause the material to come loose, leading to the risk of personal injury or material damage.
- Page 7 7. If you need to rout thicker stock, a wooden outrigger block can be attached to the Right Handle Base to provide additional stability. Fig. 5. Check Rockler.com for updates. If you have further questions, please contact our Technical Support Department at 1-800-260-9663 or support@rockler.com...
- Page 8 57896 Distributed by Rockler Companies, Inc. 1-800-279-4441 Rev 07/19 4365 Willow Dr. Medina, MN 55340 www.rockler.com...
