- Page 1 PARSEC SMALL DC EXHAUST FAN WITH LED LIGHT SKU# 200082 INSTALLATION ⚫ ⚫ OPERATION ⚫ MAINTENANCE ⚫ WARRANTY INFORMATION CAUTION READ INSTRUCTIONS CAREFULLY FOR SAFE INSTALLATION AND FAN OPERATION. V1.0 (12/2024)
-
Page 2: Warranty
PARSEC Exhaust Fan Installation Instructions To ensure correct function and safety, please read and follow all instructions carefully before assembly, installation and use of this exhaust fan. Please keep instructions for future reference. WARRANTY • This exhaust fan is covered by a 3 year warranty. The warranty is from date of purchase, not the date of installation. -
Page 3: Parts List
Small Outlet nozzle (100mm) x 1 Large Outlet nozzle (150mm) x 1 Fig. 1 • Complete your exhaust fan installation by purchasing from our range of compatible Lucci Air flexible aluminium ducting and ducting accessories, which are sold separately: Chosen Flexible Alum Ducting Clamps &... -
Page 4: Clearance Requirements
PARSEC Exhaust Fan Installation Instructions CLEARANCE REQUIREMENTS Before installation, please plan and check the ceiling space to make sure that there are no obstructions such as ceiling joists and there is sufficient height clearance for the motor housing. Refer to the below Figure 2 for the clearance requirements. - Page 5 PARSEC Exhaust Fan Installation Instructions unit in the ceiling. Screw holes are provided in the flange for this purpose. 7. From within the ceiling cavity, slide the chosen outlet nozzle onto the exhaust fan body until it clicks into place.
- Page 6 PARSEC Exhaust Fan Installation Instructions INSTALLATION METHOD 2: Attaching ducting to the exhaust fan prior to installing into the ceiling 1. Using the larger 255mm Cut-out Template, mark and cut an installation hole into the ceiling (Picture A) NOTE: Ensure clearance requirements listed in Fig. 2 above are met prior to cutting into the ceiling.
-
Page 7: Circuit Diagram
PARSEC Exhaust Fan Installation Instructions Installation Complete CIRCUIT DIAGRAM NOTE: The appliance is provided with flex cord and plug. Check the installation location in the ceiling has access to 2x socket outlets which are connected to wall switch(es). If it does not, please contact a licensed electrician to arrange installation of the socket outlets and wall switch(es). -
Page 8: Care And Cleaning
PARSEC Exhaust Fan Installation Instructions CARE & CLEANING NOTE: Always turn OFF the power at the mains switch before performing any maintenance or attempting to clean your fan. • Clean the fascia and blades regularly. To clean, wipe with a damp clean cloth with NO organic solvents or cleaners. - Page 9 Every Lucci Air Exhaust fan is thoroughly inspected and tested before being released for sale. In addition to any warranties or conditions implied by applicable Statue or Regulation, Lucci Design warrants all of it’s bathroom heaters against defective workmanship and faulty materials for thirty...
