- Page 1 METT 4 IN 1 EXHAUST FAN SKU# 209047 CAUTION READ INSTRUCTIONS CAREFULLY FOR SAFE INSTALLATION AND FAN OPERATION. V 1 . 0 ( 0 9 / 2 0 2 2 )
-
Page 2: Warranty
METT 4 in 1 Exhaust Fan Installation Instructions WARRANTY This product is covered by a 3-year warranty. The warranty is from the date of purchase, not the date of installation. If this product is not installed by a licensed electrician, the warranty will be void. All wiring and installation of this product must adhere to the latest local and national wiring rules. -
Page 3: Performance Notes
METT 4 in 1 Exhaust Fan Installation Instructions PERFORMANCE NOTES 1. For exhaust fan optimum performance, volume of air being extracted should be equal to the amount of air entering the room. Air is drawn mostly from under a door, or an open window. If the bathroom or room is air tight (door and windows shut), the exhaust will not perform well. -
Page 4: Installation Instructions
METT 4 in 1 Exhaust Fan Installation Instructions INSTALLATION INSTRUCTIONS Fig. 2 Clearance requirement HCB-Height clearance to building element 20mm HCI-Height clearance to insulation 10mm SCB-Side clearance to building element 15mm SCI-Side clearance to insulation 20mm The distance between the sides of the heater and the sides and any adjacent ceiling recessed heater shall not be less than four times the minimum distance specified for the distance between the sides of the heater and any building element adjacent to it. - Page 5 METT 4 in 1 Exhaust Fan Installation Instructions 3. Use the cut-out template card as a template. Place in the required location and mark out the hole cutting size:523mm x 343mm. Before commencing cutting ensure that the area behind the intended location is clear of all cables, pipes and joists.
- Page 6 METT 4 in 1 Exhaust Fan Installation Instructions Fig. 6 Prise up the edge of fascia then take off the fascia. Take the LED plug off the METT fan by twisting and pulling apart the connectors. (Fig. 7) Fig. 7 5 | P a g e v 1 .
- Page 7 METT 4 in 1 Exhaust Fan Installation Instructions 8. Insert the METT fan (without the fascia) into the installation hole (step 3) and push up. Ensure the 6 metal clips are push into the body and do stick out, when inserting the METT fan into the installation hole.
-
Page 8: Installing The Grille
METT 4 in 1 Exhaust Fan Installation Instructions INSTALLING THE GRILLE 1. Cut a 150mm round hole in your wall or eave. Fig. 10 2. Feed the ducting tube through the hole and connect to grille. Ensure connection is secure. 3. -
Page 9: Care And Maintenance
5. Do not soak or immerse your fan in the water or other liquids. It could damage the product and create the possibility of an electrical shock. SPECIFICATIONS SKU # 209047 Colour Matte White Insulation class Class I... - Page 10 Every Lucci Air Mett 4 in 1 is thoroughly inspected and tested before being released for sale. In addition to any warranties or conditions implied by applicable Statue or Regulation, Lucci Design warrants all of it’s bathroom heaters against defective workmanship and faulty materials for thirty six (36) months from the original date of purchase.
