MP1900A
Signal Quality Analyzer-R
Release Notes
66th Edition
Thank you for choosing Anritsu products for your business.
This document provides the latest information about version 10.04.03 of the software for the
Anritsu MP1900A and current known bugs.
We look forward to continuing business with you in the future.
Contents
1
Item
Describes information for this release
•••P 2
Shows list of devices that can be controlled by MX190000A
•••P 2
Describes added functions for MX190000A
•••P 3
Describes bug fixes in released software version
•••P 10
Describes known software bugs in this version to be fixed by
future releases
•••P 20
Describes specification changes in released software version
•••P 21
Describes precautions for using this equipment
•••P 23
M3T-1QAMP1900A0068
ANRITSU CORPORATION
5-1-1 Onna, Atsugi, Kanagawa Japan
Content
Release Notes

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MP1900A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Anritsu MP1900A

Summary of Contents for Anritsu MP1900A

  • Page 1: Table Of Contents

    Signal Quality Analyzer-R Release Notes 66th Edition Thank you for choosing Anritsu products for your business. This document provides the latest information about version 10.04.03 of the software for the Anritsu MP1900A and current known bugs. We look forward to continuing business with you in the future.

  • Page 2: Released Version

    28G/32G bit/s 4ch High Sensitivity ED MU196020A PAM4 PPG MU196040A PAM4 ED MU196040B PAM4 ED MU196060A 32G baud NRZ/PAM4 Re-Driver For the installation position in the main unit, refer to the Anritsu website (https://www.anritsu.com). For restrictions on slot installation positions, refer to the selection guide.

  • Page 3: Added Functions

    Release Notes M3T-1QAMP1900A0068 3. Added Functions Version Item Function Ver. 10.04.02 Added USB4 Gen4 CTS 0.98 Added the following features to support support USB4 Gen4 Compliance Test Specification (CTS) 0.98: ・Insertion Loss Compensation function ・Function to support LFPS Calibration #8 Available when MU196020A-z45 USB4 Gen4 Pattern Generation option is installed.
  • Page 4 MU195020A SI PPG screen. This helps those who operate the measuring instrument understand if it is fully warmed up to deliver the guaranteed performance. After turning on the MP1900A series power, it is recommended to warm it up for about 30 minutes. Added support for the...
  • Page 5 To run the generated Python code, download the Python interpreter installer from the Python Software Foundation website (https://www.python.org/downloads/), and install it on the external PC or the MP1900A. Ver. 8.03.00 Added parameters to Added PCIe 6 compatible parameters to PAM4 PPG for PCIe 6.
  • Page 6 MU196040B PAM4 ED. Ver. 4.06.02 Support for Windows 10. Added support for the MP1900A with Windows 10 IoT OS. To use the MP1900A with Windows 10 IoT OS, use the software of this version or later. Ver. 4.03.12 Added PCIe 5.0 Link Added support for the MX183000A PCIe 5.0...
  • Page 7 Support for the following module has been Ver. 4.01.32 module. added: MU196040B PAM4 ED Added the Unit Sync This function synchronizes multiple MP1900A Ver. 3.08.16 function. units to generate the same pattern and is available only when the MU196020A PAM4 PPG (Option x30/x50) is installed.
  • Page 8 Release Notes M3T-1QAMP1900A0068 Version Item Function Added PAM4 Patterns for Pattern files have been added for PAM4 Ver. 2.03.06 use by SI PPG,SI ED and signal generation and BER measurement G0374A using the MU18302xA 32G PPG, MU18304xB 32G High Sensitivity ED and G0374A. The added patterns are listed below: SSPRQ[D3_4];...
  • Page 9 Release Notes M3T-1QAMP1900A0068 Version Item Function Added Delay Calibration This function adds a Global Delay Calibration function button to Menu. When the bit rate is known to have changed, this Calibration function can be used to batch calibrate delays for multiple channels of the SI PPG and SI ED.

  • Page 10: Bug Fixes

    GUI PAM4 PPG would output a waveform with settings on PAM4 PPG Emphasis weaker than the GUI setting when the MP1900A main unit was turned on, affecting the results of calibration using Emphasis. This phenomenon occurs in V10.02.00 to V10.03.02 of the MX190000A.
  • Page 11 Release Notes M3T-1QAMP1900A0068 Version Item Fault Ver. Clock Recovery lock failure Fixed the issue where a clock recovery lock 10.00.02 occurs at a specific rate when failure occurred at a certain rate when PAM4 signal is input inputting a PAM4 signal in the Clock Recovery function of the MU196060A Re- Driver, making it impossible to perform BER measurements, etc.
  • Page 12 Release Notes M3T-1QAMP1900A0068 Version Item Fault Ver. 9.00.02 PAM4 PPG: An error was Fixed the issue that an error occurred in found in an output signal the output signal when two or four synchronized by Inter MU196020As were synchronized by the module combination.
  • Page 13 The bit position may shift in When two or more PAM4 PPGs are Inter module combination installed in one MP1900A, which is then set mode when two or more to Inter Module Combination mode, the PAM4 PPGs are installed on first bits of the data streams output from one MP1900A.
  • Page 14 If the MX190000A Installer is upgraded, program the module settings as requested. Ver. 4.07.23 The MP1900A mainframe may When Windows OS on the MP1900A is not be recognized. restarted, the MX190000A and MX1830000A may not operate normally because the MP1900A mainframe is not recognized by Windows.
  • Page 15 A version mismatch may When the update is made to the firmware occur between and FPGA on the MU183021A/MU183041A MU183021A/MU183041A’s installed in the MP1900A, restarting the firmware/FPGA and MX190000A may cause "Version MX190000A. Mismatch" to be displayed in the State column of the MU183021A/MU183041A.
  • Page 16 M3T-1QAMP1900A0068 Version Item Fault The USB ports on MP1900A In rare cases, the USB ports on MP1900A occasionally did not work occasionally did not work after powering after powering on. If this phenomenon occurs, shut down MP1900A, unplug the power cable, wait...
  • Page 17 Release Notes M3T-1QAMP1900A0068 Version Item Fault PAM4 ED measurement If in the Gating area of the Measurement Ver. 3.01.10 results may not be displayed tab for PAM4 ED, the Current button is set properly. to OFF, measurement results will not be displayed properly.
  • Page 18 Standard BERT or Expert BERT and then quit, the correct version information is updated when it is next launched. MP1900A unable to recover Sometime, the MP1900A fails to recover from Remote status and from the Remote status and operation freezes.
  • Page 19 Release Notes M3T-1QAMP1900A0068 Version Item Fault Sometimes, SI PPG Delay Busy Sometimes, the MU195020A SI PPG Delay Ver.1.02.04 lamp lights and error inserted Busy lamp lights at any bit rate and an error is inserted in the output pattern. This fault occurs in MX190000A V1.00.02 to V1.01.03.

  • Page 20: Known Issues

    Release Notes M3T-1QAMP1900A0068 5. Known Issues Version Item Fault Using an external clock can When using the MU181000B Synthesizer Ver. degrade the PAM4 PPG 100MHz external clock, the output 10.03.02 output amplitude of the MU196020A PAM4 PPG may decrease. If this issue occurs, change the Operation Bitrate of the PAM4 PPG.

  • Page 21: Specification Changes

    Release Notes M3T-1QAMP1900A0068 6. Specification Changes Item Version Description The preset When on the Emphasis tab of the MU195020A SI PPG values for SI specification and MU196020A PAM4 PPG, Preset 14 is selected for and PAM4 PPG (V10.03.02 and Standard/Preset TBT3, coefficients are set as follows: are changed later) C-1: -0.17, C0: 0.83, C+1: 0.00...
  • Page 22 Release Notes M3T-1QAMP1900A0068 Item Version Description The default On the Pattern tab of the Option-x42 FEC Pattern setting of Pre specifications Generation for MU196020A PAM4 PPG, the default Coder for FEC (V3.08.16 and setting of Pre Coder for RS-FEC pattern has been pattern has later) changed to OFF.

  • Page 23: Usage Notes

    MU181500B panel. If the MU181500B and MU181000A/B installed in the same MP1900A are not a matched calibrated pair, the SJ2 Jitter accuracy cannot be assured; contact our sales representative.
  • Page 24 High-Speed Serial Data Test Software Operation Manual and transfer the license to another PC temporarily. Please note that once disabled, the license key cannot be used anymore. In case you have disabled the license key, contact an Anritsu Service and Sales office.
  • Page 25 MX183000A: Ver. 5.00.30 or later 7.7 Precautions for Using an USB Wi-Fi adapter If a commercially available USB Wi-Fi adapter is installed to the MP1900A WES7, an error may occur in the MX190000A due to memory leak between WES7 and USB Wi-Fi adapter.
  • Page 26 V10.04.02 KB5050008 V10.04.03 V10.04.02 KB5053596 7.9 Precautions When Replacing Modules If the module installed in the MP1900A has the serial number below, it can be operated with the specified version of the software. Performance-Guaranteed Model Name Serial Number Software Version...
  • Page 27 M3T-1QAMP1900A0068 7.10 Precautions for using network monitoring tool When using the MP1900A with a network connection, the operation of the MP1900A may become unstable when using tools that monitor the connection of devices on the connected network. In these cases, discontinue use of the tool.
