Summary of Contents for pellenc C35
- Page 1 Translation of the original user guide PRUNING SHEARS 26_153033-C Operating instructions 02/2023 READ THE USER GUIDE CAREFULLY BEFORE USE...
-
Page 3: Table Of Contents
................3.4. PRESENTATION OF ACTIV' SECURITY ..................4. COMMISSIONING ......................... 15 4.1. CONTENTS OF THE C35 CASE + ULIB 150 BATTERY ............. 4.2. CONTENTS OF THE C35 CASE + ULIB 250 BATTERY ............. 4.3. FITTING OF THE BATTERY ON THE HARNESS (ULIB 250 BATTERY) ........ - Page 4 PRUNING SHEARS C35 26_153033-C 5.4.2. OPTICAL SENSOR AND HALF-OPENING ..................5.5. SWITCHING TO AND FROM STANDBY ..................5.5.1. AUTOMATIC STANDBY MODE ......................5.5.2. MANUAL STANDBY MODE ......................5.5.3. STANDBY EXIT ..........................5.6. HMI (HUMAN MACHINE INTERFACE) SETTINGS OF THE TOOL ..........
- Page 5 PRUNING SHEARS C35 26_153033-C 11.1. STATEMENT OF COMPLIANCE: C35 ................11.2. UK DECLARATION OF CONFORMITY : C35 ..............
-
Page 6: Introduction
PRUNING SHEARS C35 26_153033-C 1. INTRODUCTION Dear Customer, Thank you for purchasing your Pruning shears C35. Properly used and maintained, this equipment will give you years of satisfaction. Warning Your machine contains numerous recoverable or recyclable materials. Return it to your dealer or, failing this, to an approved servicing centre to be treated. -
Page 7: Safety
• The Pruning shears C35 is designed for vineyard, fruit-tree, olive-growing and landscape maintenance pruning up to a diameter of 35 mm. • The Pruning shears C35 must be operated from the ground or a suitable fully stable and secure platform. • The Pruning shears C35 is only intended for outdoor use. -
Page 8: Personal Safety
PRUNING SHEARS C35 26_153033-C 2.2.3. PERSONAL SAFETY Stay alert, watch what you are doing, and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury. -
Page 9: Servicing
2.2.7. MANAGEMENT OF THE RECYCLING AND RECOVERY OF WASTE FROM YOUR TOOL When the tool reaches the end of its life, PELLENC keeps the end of life sheet of the equipment at disposal. The end of life sheet provides instructions for safely removing components. -
Page 10: Safety Signage
PRUNING SHEARS C35 26_153033-C Never disconnect the power cord from the tool without checking that the red and green LEDs on the left and right of the battery display are off. Never carry the tool by the power cord. 10. Do not disassemble the tool. -
Page 11: Personal Protection Equipment
ICASA at the approved fre- quency. Tool compliant with EC standards. 2.6. PERSONAL PROTECTION EQUIPMENT Equipment Wearing of Safety helmet Protective visor Activ' Security Gloves PELLENC Recommended Safety footwear Mandatory Ear protection Safety goggles Recommended Jacket or over-sleeves Work trousers... -
Page 12: Description And Technical Features
PRUNING SHEARS C35 26_153033-C 3. DESCRIPTION AND TECHNICAL FEATURES 3.1. DESCRIPTION OF THE TOOL Upper pad Guard Blade shaft 10. Drive trigger 11. Activ' Security indicator LED (right side of the tool) Washer 12. Optical sensor Knurled adjustment washer 13. Waste evacuation system Blade 14. -
Page 13: Technical Features Of The Tool
PRUNING SHEARS C35 26_153033-C 3.2. TECHNICAL FEATURES OF THE TOOL 3.2.1. GENERAL CHARACTERISTICS OF THE TOOL Cutting capacity 35 mm Pruning shears power supply voltage 43.2 V Maximum electrical power 800 W Battery life Depending on the use and type of battery... -
Page 14: Presentation Of Activ' Security
3.4. PRESENTATION OF ACTIV' SECURITY The Pruning shears C35 is equipped with a patented an- ti-cutting injuries system, the Activ' Security. This technology allows the blade to stop immediately when it comes into contact with the operator's finger or hand, with or without gloves PELLENC. -
Page 15: Commissioning
4. COMMISSIONING Note For more information on battery start-up instructions, refer to the battery operating instructions. 4.1. CONTENTS OF THE C35 CASE + ULIB 150 BATTERY Check that the tool is delivered with: • 1 C35 pruning shears • 1 sharpening stone •... -
Page 16: Connecting The Tool To The Ulib 150 And 250 Batteries
PRUNING SHEARS C35 26_153033-C 4.5. CONNECTING THE TOOL TO THE ULIB 150 AND 250 BATTERIES Putting the battery into service. See the operating instructions for the battery. Before connecting the tool, make sure the battery is switched off. See the operating instructions for the battery. -
Page 17: Use
See the operating instructions for the battery. 5.2. ACTIV' SECURITY TOOL ACTIVATED The Activ' Security only works when the user is wearing conductive gloves PELLENC or when working without gloves. If the user is wearing other types of gloves, the tool will only start if the Activ' Security has been deactivated be- forehand. -
Page 18: Activ'security Deactivated
PRUNING SHEARS C35 26_153033-C Press the trigger with your index finger to operate the tool. Note For the tool to work, the user of the tool must not touch the cutting head and be in contact with the conductive pad simultaneously. -
Page 19: Starting The Tool With Activ' Security Deactivated
The tool emits three alarm beeps to warn that the Activ' Security is not activated. The blade opens. The tool is ready for use. 5.3.3. ACTIVATION OF ACTIV' SECURITY Warning Activ' Security is based on electrical conduction and is only optimal with the use of PELLENC Activ' Security gloves. - Page 20 Warning The safety system only protects the user holding the tool, any other persons is not protected. Activ' Security and gloves PELLENC reduce the risk of cuts but the risk is still present. Always be careful when using pruning shears.
-
Page 21: Blade Openings
PRUNING SHEARS C35 26_153033-C 5.4. BLADE OPENINGS 5.4.1. FULL OPENING OF THE BLADE Turn on the battery See the operating instructions for the battery. The battery beeps twice. The Activ' Security LED (1) flashes red. Take the tool into your hand. -
Page 22: Switching To And From Standby
PRUNING SHEARS C35 26_153033-C The blade (3) remains in half-open position as long as the optical sensor (1) detects that the user's finger is in front of the trigger (2). When the finger moves away from the trigger (2), the optical system controls the full opening of the blade (3) (modes C1 + C3). -
Page 23: Standby Exit
PRUNING SHEARS C35 26_153033-C 5.5.3. STANDBY EXIT Press the trigger (1) in fully. Release the trigger (1). 5.6. HMI (HUMAN MACHINE INTERFACE) SETTINGS OF THE TOOL The Human Machine Interface (HMI) is an interface that links the user to the control system of a tool or machine. - Page 24 PRUNING SHEARS C35 26_153033-C Mode C2: PROGRESSIVE (factory mode) • When leaving the factory, the pruning shears are set in "progressive" mode without half-opening. • The user controls the opening of the blades by press- ing the trigger. 5.6.1.1.2. ALL-OR-NOTHING MODES Mode C3: ON/Off HALF-OPENING •...
-
Page 25: Authorisation Modes
PRUNING SHEARS C35 26_153033-C 5.6.1.2. CHANGING USAGE MODE Connect the tool to the battery. See Section 4.5, “Connecting the tool to the ULIB 150 and 250 batteries”. Turn on the battery. See the operating instructions for the battery. Press the "mode" button on the battery. -
Page 26: Functional" Setting Modes
PRUNING SHEARS C35 26_153033-C 5.6.2.2. COMPATIBILITY BETWEEN AUTHORISATION MODES AND TOOL SETTINGS Pruning shears C35 Setting mode Pruning shears mode C1: Progressive half-opening C2: Progressive C3: On/Off half-opening C4: On/Off F5: Blade crossing setting F6: Adjusting the half-opening F7: Adjusting optical sensor sensitivity F8: Tool standby delay setting 5.6.2.3. CHANGE OF AUTHORISATION MODE... - Page 27 PRUNING SHEARS C35 26_153033-C See Section 6.8, “Checking the crossing over of the hook and the blade”. • Half-opening of the blade, • Sensitivity of the optical sensor, • Tool into standby delay. Functional modes Description Adjusting the setting F5: Blade crossing setting Adjust the blade crossing.
- Page 28 PRUNING SHEARS C35 26_153033-C 5.6.3.2. CHANGE OF "FUNCTIONAL" SETTINGS MODE Connect the tool to the battery. See Section 4.5, “Connecting the tool to the ULIB 150 and 250 batteries”. Turn on the battery. See the operating instructions for the battery. On the battery, select the mode by pressing "+" or "-", Press the "mode"...
-
Page 29: Maintenance
• All maintenance operations must be carried out with the battery switched off and the tool power cord disconnected from the battery, unless otherwise specified in the procedure. • Use products recommended by PELLENC. • In the event of any problem, consult an authorized distributor PELLENC. -
Page 30: Frequency Of Operations
Check the battery charge level. Important Have your machine serviced every 400 hours Have the tool checked by an authorised PELLENC or at least once a year by an authorised PEL- dealer PELLENC. LENCdistributor. Always store the tool clean and in a dry place, with the battery charged. -
Page 31: Verification
LENC or no gloves. Warning In the event of any problem, consult an authorized distributor PELLENC. At the beginning of each day or change of user, it is necessary to ensure that the Activ' Security is working properly. Two methods of verification are possible: Method No. -
Page 32: Visual Check Of The General Condition Of The Tool
PRUNING SHEARS C35 26_153033-C Check the correct operation of the blade according to the position of the trigger (3). Note When the blade is held in the open position and the battery emits a beep in the event of simultaneous contact with the two conductive surfaces, the Activ' Security is working. -
Page 33: Check The Tightening Of The Blade
PRUNING SHEARS C35 26_153033-C Open the tool blade fully See Section 5.4, “Blade openings”. Turn the battery off. See the operating instructions for the battery. Disconnect the tool from the battery. See Section 4.6, “Disconnecting the tool from the ULIB 150 and 250 batteries”. -
Page 34: Greasing The Blade
PRUNING SHEARS C35 26_153033-C Turn the battery off. See the operating instructions for the battery. Disconnect the tool from the battery. See Section 4.6, “Disconnecting the tool from the ULIB 150 and 250 batteries”. Tighten the nut (1) with the supplied spanner (2) until the knurled lock washer (3) turns with difficulty. -
Page 35: Checking The Crossing Over Of The Hook And The Blade
PRUNING SHEARS C35 26_153033-C 6.8. CHECKING THE CROSSING OVER OF THE HOOK AND THE BLADE Ensure that in the closed position the tip of the blade is in the lower third of the hook. Adjust the crossing if necessary, see Section 5.6.3,... -
Page 36: Changing Blade Or Pins
PRUNING SHEARS C35 26_153033-C 6.9. CHANGING BLADE OR PINS 6.9.1. REMOVAL OF THE BLADE AND ITS PIN Open the blade fully. See Section 5.4, “Blade openings”. Turn the battery off. See the operating instructions for the battery. Disconnect the tool from the battery. - Page 37 PRUNING SHEARS C35 26_153033-C Before fitting the blade and tool pins: Ensure that the battery is switched off. See the operating instructions for the battery. Make sure the tool is disconnected from the battery. See Section 4.6, “Disconnecting the tool from the ULIB 150 and 250 batteries”.
- Page 38 PRUNING SHEARS C35 26_153033-C 14. Grease the blade shaft (5). 15. Clip the guard (11) back in place by pressing in the See Section 6.6, “Greasing the blade”. centre.
-
Page 39: Incidents And Troubleshooting
PRUNING SHEARS C35 26_153033-C 7. INCIDENTS AND TROUBLESHOOTING 7.1. TABLE OF INCIDENTS AND BREAKDOWNS - TROUBLESHOOTING Caution Never attempt to open or repair the battery pack or the charger. Problem Probable cause Verification Possible action The tool does not start... -
Page 40: Activ' Security Led Codes Summary
Trigger problem Check the trigger See Section 6.3.3, “Check- ing the operating trigger”. If the tool does not work, return the set in its original packaging to an authorised repairer PELLENC. 7.2. ACTIV' SECURITY LED CODES SUMMARY Normal operation Codes Start-up Flashing RED •... -
Page 41: Storage And Transport
9. ACCESSORIES AND CONSUMABLES 9.1. ACCESSORIES INCLUDED For a list of accessories included with the tool, see Section 4.1, “Contents of the C35 case + ULIB 150 battery” and Section 4.2, “Contents of the C35 case + ULIB 250 battery”. -
Page 42: Warranties
The warranty is fully integral to the product sold by PELLENC. 10.1.2.1.2. SPARE PARTS The commercial warranty also covers original PELLENCspare parts, excluding labour and to the exclusion of certain... -
Page 43: Paid After-Sales Service
PELLENC Products are guaranteed under the commercial warranty as from delivery to the customer for a period of two (2) years for products connected to a PELLENC battery, and for a period of one (1) year for other PELLENC products. -
Page 44: Specific Warranties
Paid after-sales service also covers original PELLENC spare parts, excluding labour and outside the legal and commercial warranty period. In case of replacement of original PELLENC spare parts in the context of after-sales service, said latter are covered by a warranty of one year as from the installation date. -
Page 45: Statements Of Compliance
PRUNING SHEARS C35 26_153033-C 11. STATEMENTS OF COMPLIANCE 11.1. STATEMENT OF COMPLIANCE: C35 MANUFACTURER / ENTITY AUTHORIZED TO COMPILE PELLENC THE TECHNICAL FILE ADDRESS Quartier Notre-Dame - 84120 Pertuis (France) We hereby declare that the machine referred to below as:... - Page 46 PRUNING SHEARS C35 26_153033-C 11.2. UK DECLARATION OF CONFORMITY : C35 MANUFACTURER / ENTITY AUTHORIZED TO COMPILE THE PELLENC TECHNICAL FILE ADDRESS Quartier Notre-Dame - 84120 Pertuis (France) We hereby declare that the machine referred to below as: GENERIC DENOMINATION...
- Page 48 PELLENC Quartier Notre Dame - 84120 Pertuis (France)
