ENG
.
Translation of the
original user guide
PRUNING SHEARS AND 250 BATTERY
PRUNION & VINION
32_118367-K
Operating instructions
04/2020
READ THE OPERATING INSTRUCTIONS
MANUAL CAREFULLY BEFORE USE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Prunion and is the answer not in the manual?

Questions and answers

Summary of Contents for pellenc Prunion

  • Page 1 Translation of the original user guide PRUNING SHEARS AND 250 BATTERY PRUNION & VINION 32_118367-K Operating instructions 04/2020 READ THE OPERATING INSTRUCTIONS MANUAL CAREFULLY BEFORE USE...
  • Page 3: Table Of Contents

    PRUNING SHEARS AND 250 BATTERY PRUNION & VINION 32_118367-K TABLE OF CONTENTS 1. INTRODUCTION ........................5 2. SAFETY ........................... 6 2.1. GENERAL POWER TOOL SAFETY WARNINGS ................2.1.1. WORK AREA SAFETY ........................2.1.2. ELECTRICAL SAFETY ........................2.1.3. PERSONAL SAFETY .........................
  • Page 4 PRUNING SHEARS AND 250 BATTERY PRUNION & VINION 32_118367-K 6. MAINTENANCE ........................27 6.1. SHARPENING ..........................6.2. CHECK THE TIGHTNESS OF THE BLADE ................. 6.3. CHANGING BLADE OR SHAFT ....................6.4. BATTERY REPLACEMENT ......................6.5. CHARGER MAINTENANCE ......................6.6. OTHER MAINTENANCE ........................
  • Page 5: Introduction

    32_118367-K 1. INTRODUCTION Dear Customer, Thank you for purchasing your Pruning shears and 250 battery Prunion & Vinion. Correctly used and maintained, this tool will give a satisfactory performance for many years. Warning Your device contains numerous recoverable or recyclable materials. Return it to your dealer or, failing this, to an approved servicing centre to be treated.
  • Page 6: Safety

    PRUNING SHEARS AND 250 BATTERY PRUNION & VINION 32_118367-K 2. SAFETY 2.1. GENERAL POWER TOOL SAFETY WARNINGS Warning Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/ or serious injury.
  • Page 7: Power Tool Use And Care

    PRUNING SHEARS AND 250 BATTERY PRUNION & VINION 32_118367-K Use personal protective equipment. Always wear eye protection. Safety equipment such as dust masks, non-slip safety shoes, helmets, or ear protection used at the appropriate times reduces injuries. Avoid accidental starting of the tool. Make sure the switch is in the off position before you connect the tool to the power source and/or battery pack, pick it up, or carry it.
  • Page 8: Service

    2.1.7. TOOL’S END-OF-LIFE MANAGEMENT When the tool reaches the end of its life, PELLENC keeps the end of life sheet of the equipment at disposal. The end of life sheet provides instructions for safely removing components.
  • Page 9: Safety Measures Associated With Battery Use

    • Battery alone: product that is classified as class 9, UN3480. 14. Use of a battery other than that provided by Pellenc SA is dangerous (risk of serious injury). If a different battery is used, Pellenc SA cannot be held responsible for any consequences.
  • Page 10: Safety Measures When Using The "Pellenc" Charger

    If the output cord is cut or damaged, bring the entire charger back to the authorised distributor where the tool was purchased. Only recharge using the "PELLENC" charger indicated by the manufacturer. A charger adapted to one type of battery unit may present a fire risk if used with a different battery unit.
  • Page 11: Personal Protection Equipment

    PRUNING SHEARS AND 250 BATTERY PRUNION & VINION 32_118367-K 2.6. PERSONAL PROTECTION EQUIPMENT Equipment Wear Safety helmet Protective visor Recommended Protective gloves Recommended Safety footwear Required Ear protection Protective goggles Required Jacket or over-sleeves Recommended Work trousers Recommended 2.7. EMISSIONS The declared total vibration value (s) and the declared noise emission value (s) were measured in accordance with a standard test method and can be used to compare tools.
  • Page 12: Description And Technical Characteristics

    PRUNING SHEARS AND 250 BATTERY PRUNION & VINION 32_118367-K 3. DESCRIPTION AND TECHNICAL CHARACTERISTICS 3.1. DESCRIPTION OF PRUNER + ULIB 250 BATTERY COMBINATION Pruner lead 13. Battery level display Pruner connector plug 14. Right and left LEDS Prunion/Vinion pruners 15. Charge indicator Trigger 16.
  • Page 13: Description Of Cutting Head

    PRUNING SHEARS AND 250 BATTERY PRUNION & VINION 32_118367-K Note The second connector means that a Pellenc Selion M12 chainsaw can be connected at the same time. 3.2. DESCRIPTION OF CUTTING HEAD Trigger Blade shaft Blade Hook Knurled adjustment washer...
  • Page 14: Prunion

    PRUNING SHEARS AND 250 BATTERY PRUNION & VINION 32_118367-K Noise value measured according to standard EN 62841-1 Acoustic power level measured (uncertainty of K=3 dB) =80 dB MAX Level of acoustic pressure measured at the work station (un- =70 dB MAX certainty of K=3 dB) 3.3.2.
  • Page 15: Putting The Pruning Holster On The Belt

    PRUNING SHEARS AND 250 BATTERY PRUNION & VINION 32_118367-K Check that the battery is actually turned off Before using the battery for the first time, it must be fully charged (99% steady). (See Section 5.5.1, “Charging”) Note Considering the machining accuracy of the pruning shear components, to achieve optimal performance, a breaking-in period of 2 to 3 days is useful and will allow you to appreciate the reduction in consumption and noise.
  • Page 16: Putting The Pruning Holster Around The Thigh

    PRUNING SHEARS AND 250 BATTERY PRUNION & VINION 32_118367-K 4.2. PUTTING THE PRUNING HOLSTER AROUND THE THIGH...
  • Page 17 PRUNING SHEARS AND 250 BATTERY PRUNION & VINION 32_118367-K...
  • Page 18: Putting The Lead And Wrist Strap In Place

    PRUNING SHEARS AND 250 BATTERY PRUNION & VINION 32_118367-K 4.3. PUTTING THE LEAD AND WRIST STRAP IN PLACE 5. USE 5.1. USAGE TIPS • You must take all necessary care to prevent catching the lead of the pruning shears in the branches. To do this, attach the lead to your arm using the wrist strap provided.
  • Page 19: Usage Modes

    PRUNING SHEARS AND 250 BATTERY PRUNION & VINION 32_118367-K • The operating time and service life of the pruning shears mainly depend keeping the blade properly sharpened and adjusted. • It is essential to remove the burrs (wire edge) from the cutting edge of the blade, and to file it off within the first 15 minutes of use.
  • Page 20: Optical Trigger

    PRUNING SHEARS AND 250 BATTERY PRUNION & VINION 32_118367-K Mode U3: ALL OR NOTHING • Fast, "on or off" operation, with half-opening. • The pruning shears LED is red when operating. • The pruning shears LED flashes red on standby.
  • Page 21: Changing Mode

    PRUNING SHEARS AND 250 BATTERY PRUNION & VINION 32_118367-K Note The kind of gloves worn can have an effect on the way the optical trigger works. We recommend not wearing black gloves. Important If the optical trigger stops working properly, check that there is nothing obstructing the slot in the trigger or clean the window of the optical sensor with rubbing alcohol.
  • Page 22: Functional" Setting Modes

    PRUNING SHEARS AND 250 BATTERY PRUNION & VINION 32_118367-K 5.4.2. "FUNCTIONAL" SETTING MODES F5 Mode: Blade crossing adjustment Turn the battery on, with the tool connected, Press the "mode" button, Select function F5, by pressing + or -, Press the "mode" button, Press + or - to adjust the blade crossing.
  • Page 23: Parameter Setting Modes

    PRUNING SHEARS AND 250 BATTERY PRUNION & VINION 32_118367-K 5.4.3. PARAMETER SETTING MODES You can set the parameters for the tool's adjustment level to make it easier to use. • L1: "Display" Mode: The tool can only be used in the preset configuration.
  • Page 24: The Battery

    PRUNING SHEARS AND 250 BATTERY PRUNION & VINION 32_118367-K After configuring the usage mode allowed for the user, turn the battery off, then reconnect the tool, If you need to change mode again, the above procedure has to be repeated.
  • Page 25 PRUNING SHEARS AND 250 BATTERY PRUNION & VINION 32_118367-K Connect the charger power connector (1) to the power outlet. The charger LED lights up green. Connect the charging cord (2) to the battery's charging connector (3). The charger indicator (4) lights up green, and the battery indicator (5) flashes orange.
  • Page 26: Usage Method With Both Tools

    Right side: For the Prunion & Vinion pruning shears. • To start your Pellenc pruner, turn on the battery by pressing the ON/OFF button (1) for 1 sec, the red LED (2) will light up, then the battery will beep 4 times. The pruner is ready for use, press the bottom trigger, then release it, the blade opens (the opening and closing of the blade are proportional to the movement of the finger).
  • Page 27: Maintenance

    PRUNING SHEARS AND 250 BATTERY PRUNION & VINION 32_118367-K 6. MAINTENANCE If cutting is no longer sharp and effortless, this means that it is using more energy than necessary. Check the following points: the sharpness of the blade, the tightness of the blade, the general condition of the pruning shears.
  • Page 28: Changing Blade Or Shaft

    PRUNING SHEARS AND 250 BATTERY PRUNION & VINION 32_118367-K Check tightening of the blade: • The knurled washer (4) must be able to rotate with the blade open. • The knurled washer (4) must not turn with the blade closed.
  • Page 29 PRUNING SHEARS AND 250 BATTERY PRUNION & VINION 32_118367-K Remove the locking plate. Remove the shoulder pin and replace the worn Remove the adjustment washer parts...
  • Page 30: Battery Replacement

    PRUNING SHEARS AND 250 BATTERY PRUNION & VINION 32_118367-K 10. Replace the blade on the hook after greasing the seating, then replace the blade shaft and the clevis pin. 11. Replace the adjustment washer and locking blade. 12. Tighten the wheel on the blade shaft.
  • Page 31: Incidents And Troubleshooting

    PRUNING SHEARS AND 250 BATTERY PRUNION & VINION 32_118367-K 7. INCIDENTS AND TROUBLESHOOTING 7.1. RECAP OF BATTERY DISPLAY MESSAGES AND AUDIBLE SIGNALS Normal messages • Battery during operation fixed • Battery charge level between 0% and 99%. • Charge level very low, with 1 beep per minute •...
  • Page 32: Transport / Storage

    • PRUNION blade kit (ref. 122991) • PRUNION blade shaft kit (ref. 123762) • PRUNION maintenance kit (ref. 122688): Refer to your dealer before changing this kit. • VINION blade kit 4 mm (ref. 153490) • VINION blade shaft kit (ref. 122671) •...
  • Page 33: Commercial Warrantypellenc

    PELLENC Products are guaranteed under the commercial warranty as from delivery to the customer for a period of two (2) years for products connected to a PELLENC battery, and for a period of one (1) year for other PELLENC products.
  • Page 34: Paid After-Sales Service

    The DISTRIBUTOR undertakes to complete the computer commissioning declaration form, no later than eight days after the delivery of the property to the user customer, in order to activate the latter on the www.pellenc.com website under "warranties and training" in the "extranet" menu, using the identifier previously provided to them by PELLENC.
  • Page 35 PRUNING SHEARS AND 250 BATTERY PRUNION & VINION 32_118367-K • The battery has not gone into deep discharge; • Average consumption does not exceed 450 mA. Avertissement Never open the pruning shears or battery pack, as this may void the warranty. Contact your...
  • Page 36: Compliance Statements

    PRUNING SHEARS AND 250 BATTERY PRUNION & VINION 32_118367-K 11. COMPLIANCE STATEMENTS 11.1. "EC" DECLARATION OF CONFORMITY: VINION MANUFACTURER PELLENC ADDRESS Quartier Notre-Dame - 84120 Pertuis (France) ENTITY AUTHORIZED TO COMPILE THE TECHNICAL FILE PELLENC ADDRESS Quartier Notre-Dame - 84120 Pertuis...
  • Page 37: Ec" Declaration Of Conformity: Prunion

    PRUNING SHEARS AND 250 BATTERY PRUNION & VINION 32_118367-K 11.2. "EC" DECLARATION OF CONFORMITY: PRUNION MANUFACTURER PELLENC ADDRESS Quartier Notre-Dame - 84120 Pertuis (France) ENTITY AUTHORIZED TO COMPILE THE TECHNICAL FILE PELLENC ADDRESS Quartier Notre-Dame - 84120 Pertuis (France) We hereby declare that the machine referred to below as:...
  • Page 38: Ec" Declaration Of Conformity: Battery 250

    PRUNING SHEARS AND 250 BATTERY PRUNION & VINION 32_118367-K 11.3. "EC" DECLARATION OF CONFORMITY: BATTERY 250 MANUFACTURER PELLENC ADDRESS Quartier Notre-Dame 84120 Pertuis (France) ENTITY AUTHORIZED TO COMPILE THE TECHNICAL FILE PELLENC ADDRESS Quartier Notre-Dame - 84120 Pertuis (France) We hereby declare that the machine referred to below as:...
  • Page 39: Eu" Declaration Of Conformity: Cb5010Hv Charger

    PRUNING SHEARS AND 250 BATTERY PRUNION & VINION 32_118367-K 11.4. "EU" DECLARATION OF CONFORMITY: CB5010HV CHARGER MANUFACTURER PELLENC ADDRESS Quartier Notre-Dame 84120 Pertuis (France) ENTITY AUTHORIZED TO COMPILE THE TECHNICAL FILE PELLENC ADDRESS Quartier Notre-Dame - 84120 Pertuis (France) We hereby declare that the machine referred to below as:...
  • Page 44 PELLENC Quartier Notre Dame - 84120 Pertuis (France)
