- Page 1 Translation of the original op- erating instructions manual PRUNING SHEARS 153033 -A Operating instructions 01/2022 READ THE USER GUIDE CAREFULLY BEFORE USE...
-
Page 3: Table Of Contents
..................... 2.2.6. SERVICING ............................2.2.7. MANAGEMENT OF THE RECYCLING AND RECOVERY OF WASTE FROM YOUR TOOL ....2.3. SAFETY MEASURES RELATED TO THE USE OF THE "PELLENC" BATTERY AND THE CHARGER ............................... 2.4. SAFETY WARNINGS FOR BATTERY-POWERED SHEARS ............2.5. SAFETY SIGNAGE .......................... - Page 4 8. TRANSPORT / STORAGE ....................30 8.1. STORAGE ............................9. ACCESSORIES AND CONSUMABLES ................30 9.1. ACCESSORIES INCLUDED ......................9.1.1. ACCESSORIES INCLUDED IN THE C35 + 150 BATTERY CASE ............9.1.2. ACCESSORIES INCLUDED IN THE C35 + 250 BATTERY CASE ............9.2. OPTIONAL ACCESSORIES ......................
-
Page 5: Introduction
PRUNING SHEARS C35 153033 -A 1. INTRODUCTION Dear Customer, Thank you for purchasing your Pruning shears C35. Properly used and maintained, this equipment will give you years of satisfaction. Warning Your machine contains numerous recoverable or recyclable materials. Return it to your dealer or, failing this, to an approved servicing centre to be treated. -
Page 6: Safety
• The Pruning shears C35 is designed for vine and tree pruning, up to a diameter of 35 mm. • The Pruning shears C35 must be operated from standing ground level or from a suitable platform that is completely stable and secure. -
Page 7: Personal Safety
PRUNING SHEARS C35 153033 -A 2.2.3. PERSONAL SAFETY Stay alert, watch what you are doing, and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury. -
Page 8: Servicing
2.2.7. MANAGEMENT OF THE RECYCLING AND RECOVERY OF WASTE FROM YOUR TOOL When the tool reaches the end of its life, PELLENC keeps the end of life sheet of the equipment at disposal. The end of life sheet provides instructions for safely removing components. -
Page 9: Safety Signage
PRUNING SHEARS C35 153033 -A Never carry the pruning shears suspended from the power cord. 10. Do not disassemble the pruning shears. 11. Do not try to cut pieces of wood that are too large or other materials than wood. -
Page 10: Description And Technical Characteristics
PRUNING SHEARS C35 153033 -A 3. DESCRIPTION AND TECHNICAL CHARACTERISTICS 3.1. DESCRIPTION OF THE TOOL Upper pad Mode LED (left side of the tool) Blade shaft Guard 10. Drive trigger Washer 11. ActivSecurity LED (right side of the tool) Knurled adjustment washer 12. -
Page 11: Pruning Shears C35 Technical Features
PRUNING SHEARS C35 153033 -A 3.2. PRUNING SHEARS C35 TECHNICAL FEATURES Cutting capacity 35 mm Pruning shears power supply voltage 43.2 V Average power 180 W Battery life Depending on the use and type of battery Weight of pruning shears... -
Page 12: Commissioning
PRUNING SHEARS C35 153033 -A 4. COMMISSIONING Note For further information on commissioning instructions, please refer to the operating instructions of the battery. 4.1. CONNECTING THE TOOL TO THE BATTERY Align the marker (1) of the tool power cord with the slot (2) of the tool connector. -
Page 13: Tool Safety
PRUNING SHEARS C35 153033 -A 5.2. TOOL SAFETY 5.2.1. ACTIVATION OF ACTIVSECURITY Warning The blocking safety system is based on electrical conduction and is only optimal with the use of Pellenc ActivSecurity gloves. When working in wet conditions, wearing gloves increases safety effectiveness. -
Page 14: Deactivation Of Activsecurity
PRUNING SHEARS C35 153033 -A 5.2.2. DEACTIVATION OF ACTIVSECURITY Warning The user is strongly advised against disabling the safety system. Deactivating the safety system exposes the user to the risk of serious and deep cuts. Warning The user is responsible for any accidents that occur as a result of deactivating the ActivSecurity. -
Page 15: Optical Trigger - Half Opening
In the event of any problem, consult an authorized distributor PELLENC. Warning For the proper functioning of the safety system, it is imperative to use Pellenc ActivSecurity gloves or no gloves at all. The use of any other gloves is prohibited. -
Page 16: Usage Modes
PRUNING SHEARS C35 153033 -A For more information on adjusting the sensitivity of the optical sensor, refer to the operating instructions manual of the battery. Note The kind of gloves worn can have an effect on the way the optical trigger works. We recommend not wearing black gloves. -
Page 17: Presentation Of Usage Modes
PRUNING SHEARS C35 153033 -A 5.4.2. PRESENTATION OF USAGE MODES Mode C1: PROGRESSIVE WITH HALF-OPENING • Progressive operation with half-opening. Mode C2: PROGRESSIVE (factory mode) • Progressive operation without half-opening. Mode C3: ON/Off HALF-OPENING • Fast, "On/Off" operation, with half-opening. - Page 18 PRUNING SHEARS C35 153033 -A Mode C4: ON/Off • Fast On/Off operation without half-opening.
-
Page 19: Functional" Settings Modes
PRUNING SHEARS C35 153033 -A 5.5. "FUNCTIONAL" SETTINGS MODES 5.5.1. CHANGING THE "FUNCTIONAL" SETTINGS MODE Turn the battery on, with the tool connected, Press the "mode" button, Select the mode by pressing + or -, Press the "mode" button to validate, Press + or - to adjust the setting from 1 to 9, see Section 5.5.2, “Presentation of "functional"... -
Page 20: Presentation Of "Functional" Settings Modes
PRUNING SHEARS C35 153033 -A 5.5.2. PRESENTATION OF "FUNCTIONAL" SETTINGS MODES Pruning shears mode Description Adjusting the setting F5: Blade crossing setting Adjust the blade crossing. 1 - 9: Low crossing - high crossing F6: Adjusting the half-opening Adjust the blade half-opening. -
Page 21: Compatibility: Battery Mode And Model
F7: Adjusting optical sensor sensitivity F8: Tool standby delay setting 5.7. STANDBY Putting the Pruning shears C35 into standby is possible when the F8 mode is set between 1 and 8, see Section 5.5, “"Functional" settings modes”. Note A beep from the battery indicates that the tool is in standby mode. -
Page 22: Standby Exit
PRUNING SHEARS C35 153033 -A 5.8. STANDBY EXIT Press the trigger (1) in fully. Release the trigger (1). -
Page 23: Service
Caution Always disconnect the tool battery before starting tool maintenance. • Use products recommended by PELLENC. • In the event of any problem, consult an authorized distributor PELLENC. 6.2. MAINTENANCE TABLE Every 400 At each... -
Page 24: Sharpening The Blade
PRUNING SHEARS C35 153033 -A EVERY 200 HOURS to maintain a good quali- Changing the blade kit ty of cut, contact a distributor to change this kit. Battery Please refer to the battery operating instructions. Important Have your machine serviced every 400 hours or at least once a year by an authorised PELLENCdistributor. -
Page 25: Check The Tightening Of The Blade
PRUNING SHEARS C35 153033 -A 6.4. CHECK THE TIGHTENING OF THE BLADE To obtain correct adjustment: Perform these operations with the blade closed and the battery switched off. Tighten the nut (1) with the supplied wrench (2) un- til the knurled adjusting washer (3) turns only with great difficulty. -
Page 26: Greasing The Blade
PRUNING SHEARS C35 153033 -A 6.7. GREASING THE BLADE • Grease the blade pin (1) with the grease gun supplied (2). 6.8. CHANGING BLADE OR PINS 6.8.1. REMOVAL OF THE BLADE AND ITS PIN Open the blade fully. Turn off the battery. -
Page 27: Fitting Of The Blade And Its Pins
PRUNING SHEARS C35 153033 -A Remove the parts in this order: Remove the blade (9) and replace the worn parts. • The blade pin (4), Refit the blade and pins, see Section 6.8.2, “Fitting • The washer (5), of the blade and its pins”. - Page 28 PRUNING SHEARS C35 153033 -A Align the flat on the blade shaft (5) with the blade 10. Position and screw the nut (8) onto the blade shaft marker (2). using the wrench provided (9), see Section 6.4, Fit the blade pin (5).
-
Page 29: Incidents And Troubleshooting
PRUNING SHEARS C35 153033 -A 7. INCIDENTS AND TROUBLESHOOTING 7.1. SUMMARY OF ACTIVSECURITY LED CODES AND BEEPS Normal operation Codes Start-up Flashing RED • Waiting for initialization Red and (light) blue fixed • ActivSecurity initialized: user detected on pad and... -
Page 30: Transport / Storage
In the OFF-SEASON, you may have your pruning shears serviced by an authorised repairer. For more infor- mation, consult an authorised distributor or contact PELLENC. 9. ACCESSORIES AND CONSUMABLES 9.1. ACCESSORIES INCLUDED 9.1.1. ACCESSORIES INCLUDED IN THE C35 + 150 BATTERY CASE Name Reference 150 battery 163689 Charger CB5004HV2 (0.4 A) -
Page 31: Accessories Included In The C35 + 250 Battery Case
Arm band 120989 Adjustable belt 154772 Holster to be fitted on the adjustable belt 152336 Grinding stone 34467 13 mm angled wrench 9.1.2. ACCESSORIES INCLUDED IN THE C35 + 250 BATTERY CASE Name Reference 250 battery mounted on adjustable harness 154701... - Page 32 PRUNING SHEARS C35 153033 -A Name Reference Charger CB5010HV (1A) 132649 3m pruning shears power cord 130735 Tube of grease 140615 Grease nipple 158783 Arm band 120989 Holster to be fitted to the harness 152336 Grinding stone 34467...
-
Page 33: Optional Accessories
NOTE: Only for 250 batteries 9.3. CONSUMABLES Name Reference C35 blade kit 159025 C35 maintenance kit 159022 C35 feather blade kit 159029 Grinding stone 34467 Tube of grease 140615 3m pruning shears power cord 130735 4m pruning shears power cord... -
Page 34: Warranties
The warranty is fully integral to the product sold by PELLENC. 10.1.2.1.2. SPARE PARTS The commercial warranty also covers original PELLENCspare parts, excluding labour and to the exclusion of certain... -
Page 35: Paid After-Sales Service
PELLENC Products are guaranteed under the commercial warranty as from delivery to the customer for a period of two (2) years for products connected to a PELLENC battery, and for a period of one (1) year for other PELLENC products. -
Page 36: Specific Warranties
Paid after-sales service also covers original PELLENC spare parts, excluding labour and outside the legal and commercial warranty period. In case of replacement of original PELLENC spare parts in the context of after-sales service, said latter are covered by a warranty of one year as from the installation date. -
Page 37: Statements Of Compliance
PRUNING SHEARS C35 153033 -A 11. STATEMENTS OF COMPLIANCE 11.1. STATEMENT OF COMPLIANCE: C35 MANUFACTURER / ENTITY AUTHORIZED TO COMPILE THE PELLENC TECHNICAL FILE ADDRESS Quartier Notre-Dame 84120 Pertuis (France) We hereby declare that the machine referred to below as:... -
Page 38: Declaration Of Conformity : C35
PRUNING SHEARS C35 153033 -A 11.2. UK DECLARATION OF CONFORMITY : C35 MANUFACTURER / ENTITY AUTHORIZED TO COMPILE THE PELLENC TECHNICAL FILE ADDRESS Quartier Notre-Dame - 84120 Pertuis (France) We hereby declare that the machine referred to below as: GENERIC DENOMINATION... - Page 40 PELLENC Quartier Notre Dame - 84120 Pertuis (France)
