Related Manuals for Jetson Ora Pro
Summary of Contents for Jetson Ora Pro
- Page 1 Ora Pro Folding Electric Scooter. A guide for your ride. IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY. MODEL: JORAPR-BLK | JORAPR-OS-BLK Designed in Brooklyn | Made in China...
- Page 3 Remember to be safe and, most importantly, have fun!
-
Page 5: Table Of Contents
Table of Contents Safety Warnings ................................. 4 What’s in the Box ................................ 6 Specs & Features ............................... 9 Unfolding / Folding the Ora Pro ..........................10 Stem Retightening ..............................14 Handlebar Assembly ............................... 16 Operating the Ora Pro .............................. 17 Charging The Battery .............................. -
Page 6: Safety Warnings
Safety Warnings • Before use, please read the user manual and safety warnings carefully, and make sure you understand and accept all the safety instructions. The user will be responsible for any loss or damage caused by improper use. • Before each cycle of operation, the operator shall perform the preoperation checks specified by the manufacturer: That all guards and pads originally supplied by the manufacturer are in proper place and in serviceable condition;... -
Page 7: Additional Operation Cautions
For more information go to www.p65warnings.ca.gov/product MODIFICATIONS Do not attempt to disassemble, modify, repair, or replace the unit or any components of the unit without instruction from Jetson Customer Care. This will void any warranty, and can lead to malfunctions which may cause injury. -
Page 8: What's In The Box
What’s in the Box 1. HANDLEBAR 6. DECK 2. HEADLIGHT 7. REAR FOOT BRAKE 3. RELEASE LEVER 8. REAR TIRE 4. FRONT TIRE 9. CHARGER 5. KICKSTAND 10. CHARGING CABLE HARDWARE / TOOLS INCLUDED: ALLEN KEY WRENCH SCREWS (4X) *PLEASE FULLY CHARGE THE BATTERY PRIOR TO USE. *ADULTS MUST ASSIST CHILDREN IN THE INITIAL ADJUSTMENT PROCEDURES OF THE PRODUCT. - Page 9 PLEASE NOTE: IMAGES MAY NOT REFLECT EXACT APPEARANCE OF ACTUAL PRODUCT.
-
Page 11: Specs & Features
Specs & Features • PRODUCT DIMENSIONS: 38.6” (L) × 17” (W) × 42” (H) • PRODUCT FOLDED DIMENSIONS: 38.6” (L) × 17” (W) × 16” (H) • WEIGHT LIMIT: 220 LB • PRODUCT WEIGHT: 27 LB • RECOMMENDED AGE: 12+ •... -
Page 12: Get Started
1. Get Started Unfolding / Folding the Ora Pro UNCLIP THE HOOK FROM THE REAR FOOT BRAKE. - Page 13 LIFT HANDLEBARS AWAY FROM DECK.
- Page 14 RELEASE LEVER • LOCK THE RELEASE LEVER BY LIFTING IT UP UNTIL IT CLICKS.
- Page 15 RELEASE BUTTON • MAKE SURE THE RELEASE LEVER AND HANDLEBARS ARE SECURE. • PRESS THE RELEASE BUTTON AND UNLOCK THE RELEASE LEVER TO FOLD THE ORA PRO.
-
Page 16: Stem Retightening
Stem Retightening IF THE RELEASE LEVER AND STEM BECOME LOOSE, TIGHTEN THE SMALL SCREW WITH A 2 MM ALLEN KEY... - Page 17 FOLD THE RELEASE LEVER DOWN AND USE THE WRENCH TO TIGHTEN THE BOLT • RAISE THE HANDLEBAR STEM AND LOCK THE RELEASE LEVER. • GAUGE TIGHTNESS OF RELEASE LEVER AND START OVER TO TIGHTEN MORE IF NEEDED OR REVERSE STEPS TO LOOSEN.
-
Page 18: Handlebar Assembly
• CONNECT THE WIRE FROM THE HANDLEBARS WITH THE WIRE IN THE HANDLEBAR STEM. MAKE SURE THE PLUGS CLIP IN CORRECTLY. IF YOU HAVE ANY ISSUES WITH THE WIRES, PLEASE CONTACT JETSON CUSTOMER SUPPORT. • TUCK ANY EXCESS WIRE INTO THE STEM TUBE AND SLIDE THE HANDLEBAR INTO THE STEM TUBE. -
Page 19: Operating The Ora Pro
Operating the Ora Pro SPEED MODE SPEEDOMETER POWER BUTTON SPEED DISPLAY BATTERY INDICATOR CRUISE HEADLIGHT CONTROL... - Page 20 • POWERING ON - HOLD THE POWER BUTTON FOR 3 SECONDS TO TURN ON. • POWERING OFF - HOLD THE POWER BUTTON FOR 3 SECONDS TO TURN OFF. • SPEED MODES - PRESS THE POWER BUTTON ONCE TO SWITCH THE SPEED MODES. •...
-
Page 21: Charging The Battery
• ONLY USE THE INCLUDED CHARGER. • PLUG THE CHARGER INTO THE WALL OUTLET BEFORE THE CHARGING PORT. • DON’T TURN ON THE ORA PRO WHILE IT’S CHARGING. • CHARGE THE BATTERY UNTIL IT IS FULLY CHARGED - UP TO 3 HOURS. -
Page 22: Using The Thumb Throttle / Handbrake
THUMB THROTTLE 2. Make Moves Using the Thumb Throttle NOTE: USE THE THROTTLE GENTLY UNTIL YOU GET USED TO IT. - Page 23 E-BRAKE Using the E-Brake • RELEASE THE ACCELERATOR AND GENTLY PRESS THE E-BRAKE TO SLOW DOWN THE ORA PRO. NOTE: PRESS DOWN ON THE E-BRAKE SLOWLY TO AVOID STOPPING ABRUPTLY OR LOSING CONTROL.
-
Page 24: Riding The Ora Pro
• PLACE ONE FOOT IN FRONT. • PLACE THE OTHER FOOT IN BACK, AT A 70-90° ANGLE. • WHEN THE ORA PRO STARTS TO COAST, GENTLY PRESS THE ACCELERATOR. • TURN THE HANDLEBAR TO THE LEFT OR RIGHT TO MAKE TURNS. -
Page 25: Helmet Safety
Helmet Safety THE FOREHEAD IS COVERED THE FOREHEAD IS EXPOSED. BY THE HELMET. COULD CAUSE SERIOUS INJURY. -
Page 26: Care & Maintenance
CLEANING THE ORA PRO TO CLEAN THE ORA PRO, CAREFULLY WIPE WITH A DAMP CLOTH, THEN DRY WITH A DRY CLOTH. DO NOT USE WATER TO CLEAN THE ORA PRO, AS THE ELECTRICAL AND ELECTRONIC SYSTEMS MAY GET WET, RESULTING IN PERSONAL INJURY OR MALFUNCTION OF THE ORA PRO. - Page 27 Enjoying the ride? Leave a review on ridejetson.com/reviews or share your photos with us online using the #RideJetson hashtag! Follow us @ridejetson #MakeMoves...
- Page 28 Questions? Let us know. support.ridejetson.com Hours of Operation: 7 Days a Week, 10am-6pm Manufactured in Shenzhen, China Imported by Jetson Electric Bikes LLC. 86 34th Street 4th Floor, Brooklyn, New York 11232 www.ridejetson.com Made in China Date Code: 07/2021...
