- Page 1 GB . . . . . . . StepOne platform lift User manual – vers . 1 .00...
-
Page 2: Table Of Contents
StepOne platform lift Item number: 565403, 565404, 565405, 565406, 565413, 565414, 565415, 565416 1 .00 . . . . . . . . Intended purpose and use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 1.01 . - Page 3 7 .00 . . . . . . . . . Service and lifetime . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 7.01 .
-
Page 4: Intended Purpose And Use
1 .00 Intended purpose and use 1 .01 Manufacturer V. Guldmann A/S Graham Bells Vej 21-23A DK-8200 Aarhus N Denmark Tel. + 45 8741 3100 1 .02 Purpose StepOne is a platform lift that can transform from stairs to platform to provide access between different levels for people with impaired mobility, e.g. -
Page 5: Use
1 .04 StepOne is designed for permanent installation indoors. It is mounted to the wall for stability while the two front columns move back and forth on wheels to transform between stair mode and platform mode. When StepOne is in motion, an upper safety gate and a roll-off guard rise automatically to prevent users from falling off. -
Page 6: Area Of Use
1 .05 Area of use StepOne may be used in both public and private areas. Public areas are, e.g. institutions and public buildings, where StepOne is subject to a certain amount of supervision. In these environments, StepOne should be locked to protect it against unintentional use or misuse. -
Page 7: Technical Precautions And Warnings
StepOne must not be used as a platform lift in the event of a fire. 1 .07 Technical precautions and warnings Installation, service StepOne must be installed by the Guldmann and maintenance Service Team or a Guldmann approved technician. For installation details, please see the StepOne installation manual. -
Page 8: Description Of Standard Functions
2 .00 Description of standard functions 2 .01 Control panels StepOne can be operated by three different control panels: Upper level control Platform control Lower level control panel panel panel Up button Up button Down button In platform mode: In platform mode: In platform mode: Raises the platform Raises the platform... -
Page 9: Front Columns On Wheels
2 .02 Front columns on wheels Two mobile front columns on wheels move back and forth from the wall when StepOne transforms between stair mode and platform mode. Important Ensure that the area in front of the stairs is clear of any obstacles as illustrated below. -
Page 10: Safety Functions
2 .03 Safety functions Important Individual and specific considerations must be given to the functionality of the emergency safety system. One or more responsible persons should be appointed to ensure the correct use of StepOne. These persons must always be contactable in case of an emergency. All users must be informed about who holds this responsibility and how to contact them if needed. -
Page 11: Upper Safety Gate
This safety function is reset as follows: • Press the Up button until the safety list is no longer activated. • Remove the obstacles which caused the safety list to be activated. • Ensure that the safety list was not damaged during activation. •... -
Page 12: Ramp/Roll-Off Guard
2.03.04 Ramp/roll-off guard A roll-off guard prevents users from falling off when StepOne is in motion. The guard rises automatically when StepOne is used in platform mode. When StepOne reaches the lower landing, the guard lowers automatically and transforms into a ramp (to allow free passage onto the landing). -
Page 13: Key Lock (Optional)
To call for assistance: • Press the yellow alarm bell button at the top. • After 10 seconds, the automatic emergency calling device will dial the preset number to summon assistance. - The yellow pictogram will light up when calling. - The green pictogram will light up when the call is connected. -
Page 14: Operating Stepone
4 .00 Operating StepOne 4 .01 Operating StepOne from lower level to upper level User on lower level: 1. Press and hold the Down button on the lower level control panel. 2. The upper safety gate, the roll-off guard and the optional lower safety arms rise automatically. -
Page 15: Operating Stepone From Upper Level To Lower Level
User exits from the platform onto the upper level: 1. Press and hold the Stair button on the upper level control panel. 2. The upper safety gate rises automatically. 3. StepOne transforms into stair mode. 4. The upper safety gate, the roll-off guard and the optional lower safety arms lower automatically. - Page 16 User enters from upper level onto the platform: 1. Press and hold the Down button on the platform control panel. 2. The upper safety gate rises automatically. 3. StepOne moves to the lower level. 4. When StepOne arrives at the lower level, the roll-off guard and the optional lower safety arms lower automatically.
-
Page 17: Battery Operation
4 .03 Battery operation StepOne has two 12 V, 9 Ah maintenance free batteries as backup to guarantee the platform can always be moved to the nearest landing, even if the mains supply disappear. 5 .00 Dismantling and transport For information about dismantling and transport of StepOne, please see the StepOne installation manual. -
Page 18: Service And Lifetime
The lifetime is based on correct usage, cleaning, and maintenance, as well as annual inspection and maintenance by qualified personnel or the Guldmann Service Team. At the end of its expected lifetime, StepOne must be evaluated by qualified personnel to determine its suitability for continued use. -
Page 19: Troubleshooting
8 .00 Troubleshooting The table below provides help for resolving the most typical issues you may encounter when using StepOne. Issue Possible cause Solution None of the The emergency stop Turn the emergency stop electrical button has been button clockwise until it is functions work pressed/activated. -
Page 20: Technical Specifications
For details, please see section 2.03.05 “Overload protection”. Note If you did not find a solution to your issue in the table above, please contact the Guldmann Service Team or the supplier. 9.00 Technical specifications For technical specifications, please refer to the technical specifications section in the StepOne brochure. -
Page 21: Appendix A Warranty And Service Conditions
(the “Warranty Period”). If a valid claim is made during the Warranty Period for malfunction or equipment defect, Guldmann will repair or replace the equipment at no additional cost to you. Guldmann retains sole discretion as to whether the equipment will be repaired or replaced. - Page 24 V . Guldmann A/S Corporate Office: Tel. +45 8741 3100 E-mail info@guldmann.com www.stepless.com...
