Summary of Contents for Guldmann Stepless LP5
- Page 1 GB/US . . . . LP5 & LP5+ Lifting platform Vers . 7 .00...
-
Page 2: Table Of Contents
LP5 & LP5+ Item numbers: LP5: 13050-xxx LP5+: 13056-xxx 1 .00 . . . . . . . . Purpose and use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 1.01 . -
Page 3: Purpose And Use
1 .00 Purpose and use 1 .01 Manufaturer V. Guldmann A/S Graham Bells Vej 21-23A DK-8200 Aarhus N Denmark Tel. + 45 8741 3100 Fax + 45 8741 3131 1 .02 Purpose and use Purpose of the manual The manual describes the standard model with a maximum lifting height of between 500 mm and 830 mm (20”... -
Page 4: Important/Warnings
• All of the operating instructions must be read before the product is used. • The LP5 & LP5+ must be assembled by the Guldmann Service Team, or by an engineer approved by Guldmann. • The LP5 & LP5+ are controlled by a microprocessor print which can be damaged by static electricity if touched without the necessary precautions. -
Page 5: Safety Rules
1 .06 Assembly The LP5 & LP5+ must be assembled by the Guldmann Service Team or an engineer approved by Guldmann according to Guldmann’s instructions. As the noise level of the lifting platform is minimal, no steps should be taken to reduce the noise level further during the installation. -
Page 6: Platform Installation
1 .07 Platform installation Proper drainage must be provided for any outdoor installation of the platform ramp. Never allow the platform to sit in a puddle of water. The platform’s contact surface must be 100% perpendicular to the vertical wall, or the mounted gate. The base must be firm and stable, e.g. -
Page 7: Recessing The Platform
A: Adjusting the lifting height Loosen the screws and adjust to desired height. Check the new lifting height before remounting the curtain. B: Adjusting the lowering height Recessing Loosen the screws and adjust to desired height. Check the new lifting height before remounting the curtain. -
Page 8: Electrical Connection
Labels (positioned on the lifting platform). LP5 / LP5+ max 300 kg / 660 lbs LP5+ Lifting Platform LP5 Lifting Platform LP5+ V. Guldmann A/S Part no. 13050-xxx V. Guldmann A/S Part no. 13056-xxx Graham Bells Vej 21-23A Serial no. xxxxxxxxxx Graham Bells Vej 21-23A Serial no. -
Page 9: The Operating Panel
2 .02 The operating panel The lifting platform is operated by means of the operating panel. The lifting platform is logical and unproblematic to operate and use, even with no prior knowledge. 1. Raise 2. Lower 3. Emergency stop 4. Overload signal LP5+ To raise the lifting platform from its lowest level 1. -
Page 10: Safety Functions
To lower the lifting platform from its highest level 1. The wheelchair user drives onto the lifting platform. 2. When using the safety gate, it must be closed before the platform can be operated. 3. Activate the operating panel by pressing button (2) to lower the lifting plat- form. - Page 11 Description of mechanical emergency lowering – lifting platform The emergency lowering must be used in emergencies only. The emergency lowering must be reset after use. This requires qualified assistance. You must contact the dealer before using the LP5 & the LP5+ again. Great attention and the required mobility is needed to use the emer- gency lowering, which is why the...
- Page 12 Fitting of safety curtain 1. The surfaces of the safety curtain are pre-fitted with the Velcro side of Velcro tape. 2. Place a broomstick or similar through the scissors on the narrow side of the lifting platform. 3. Put the safety curtain over the upper plate and place it on the broomstick, freely suspended.
-
Page 13: Accessories
2 .04 Accessories Extra operating panel Extra operating panel with function buttons »é« »« for mounting on walls and similar. The operating panel is available with a lock. Wireless operation Use this when there are one or more independent users. This allows users to control the lifting platform without being dependent on a helper. -
Page 14: Maintenance And Storage
The life span is based on correct usage, cleaning, and maintenance, as well as annual inspection and maintenance by qualified personnel or the Guldmann Service Team. After this period, the LP5 & LP5+ must be assessed by qualified personnel before future use. -
Page 15: General Inspection
Parts that are worn out or defective must be replaced with new spare parts from Guldmann 1. Visually checking the product • Check the product for signs of wear and tear. -
Page 16: Troubleshooting
Observe the maximum load indication of the platform. 6. Does the ramp go up and down but the platform does not go up or down? • See point 2. If the points above do not solve the problem, please contact the Guldmann Service Team or your distributor. -
Page 17: Technical Specifications
6.00 Technical specifications Dimensions LP5 exterior dimensions (LxWxH) ....1602 x 1076 x 728 mm 64” x 43” x 29” LP5 interior dimensions (LxW) 1602 x 900 mm 64”... -
Page 18: Ec-Declaration Of Conformity
7 .00 EC-declaration of conformity The product is manufactured in compliance with the Council Directive 2006/42/EC of May 17th 2006 on machinery and amending Directive 95/16/EC. -
Page 19: Usa And Countries Outside The Eu
(the “Warranty Period”). If a valid claim is made during the Warranty Period for malfunction or equipment defect, Guldmann will repair or replace the equipment at no additional cost to you. Guldmann retains sole discretion as to whether the equipment will be repaired or replaced. - Page 20 V . Guldmann A/S Corporate Office: Graham Bells Vej 21-23A DK-8200 Aarhus N Tel. +45 8741 3100 +45 8741 3131 E-mail info@guldmann.com www.guldmann.com Guldmann Inc . 14401 McCormick Drive, Unit A Tampa, FL 33626 Tel. 800 664 8834 Tel. 813 880 0619 813 880 9558 info@guldmann.net...
