ASSEMBLY GUIDE
This guide is for users who have wall sockets closer to right side of the desk and wish to swap the Integrated Power Supply Column
(IPSC) from the left leg to the right. This allows for neater cabling and stops the power supply cable from trailing below your desk.
Please note that the switch power socket will face front when installed on the right.
Preparing for Assembly
TEAM LIFT
With at least two people, lift the
Metal Desk Top and place it upside
down onto a debris-free area to
protect the Metal Desk Top surface.
Remove the Service Hatch using the
Screwdriver Handle and small end
of the Double-End Bit provided.
Preparing for Power Supply Column Swap
Remove the Red Cable Connector
from the Control Box and push it
into the Desk Frame as shown in
the diagram. Plug the Blue Cable
Connector into the Control Box
as shown in the diagram.
Desk Frame
Unplug Red from Control Box
Push Red into Frame
Plug Blue into Control Box
TOOLS
PROVIDED
