- Page 1 HD DRIVETRAIN USER MANUAL Heavy-Duty Drivetrain User Manual CYC MOTOR LTD www.cycmotor.com © 2025 CYC MOTOR LTD...
-
Page 2: Table Of Contents
Derailleur Adjustment ......................7 Shifter Calibration ........................7 Chain Tensioning ........................7 Fine-Tuning Tips ........................7 MAINTENANCE AND CARE ..............8 Regular Maintenance Schedule ....................9 Disposal And Environmental Protection ................9 Cleaning and Lubrication ....................... 9 © 2025 CYC MOTOR LTD... - Page 3 TECHNICAL SPECIFICATIONS ............11 Detailed Component Specifications ..................11 Cassette ..........................11 Hub ........................... 11 Shifter ..........................13 Derailleur .......................... 13 Chain ..........................13 Compatibility Chart ......................13 WARRANTY AND SERVICE ..............14 DISCLAIMER ................... 14 © 2025 CYC MOTOR LTD...
-
Page 4: Introduction
The 6-bolt disc brake compatibility ensures seamless integration with most modern braking systems. For further details on compatibility and installation, please refer to the specific installation guidelines provided for each component. © 2025 CYC MOTOR LTD... -
Page 5: Parts List
HD DRIVETRAIN USER MANUAL Parts List Cassette Shifter Derailleur Bike Chain © 2025 CYC MOTOR LTD... -
Page 6: Safety Information
By adhering to these safety guidelines, you can ensure a long-lasting and efficient riding experience with the Heavy-Duty Drivetrain. Always prioritize safety and proper maintenance to get the most out of your e-bike system. © 2025 CYC MOTOR LTD... -
Page 7: Component Overview
KMC e9 Turbo EPT Chain Size: 1/2"x11/128"x136 Links • Coating: EPT (Anti-rust) for corrosion resistance in harsh conditions. • Features: Designed for durability and longevity, ensuring smooth operation and reduced • maintenance. Resources: Product Link • © 2025 CYC MOTOR LTD... -
Page 8: Installation Instructions
Insert the axle into the hub and attach the wheel to the bike frame. • Ensure the wheel is centered and secure. For further specifications for wheel building, please refer to the technical specifications section in this manual (p.9). © 2025 CYC MOTOR LTD... -
Page 9: Shifter Installation
Use a chain breaker tool to adjust the chain length. • Connect the chain using a quick link or rivet. • Verify that the chain length is sufficient to allow rear suspension full travel (bottom out) • without damage to the drivetrain. © 2025 CYC MOTOR LTD... -
Page 10: Setup And Adjustment
2. Adjust length if necessary for optimal performance. Fine-Tuning Tips Test ride the bike to ensure all adjustments are correct. • Make minor adjustments as needed to improve shifting precision. • Gradually increase motor power during testing to confirm drivetrain stability. • © 2025 CYC MOTOR LTD... -
Page 11: Maintenance And Care
Authorized Repairs Only: Do not disassemble or modify drivetrain components. Maintenance and repairs should be performed by qualified professionals using only original CYC MOTOR parts to maintain safety and warranty coverage. Lubrication: Regularly lubricate moving components such as the chain to maintain smooth operation and reduce wear. -
Page 12: Regular Maintenance Schedule
Rinse with water and dry thoroughly to prevent rust. Lubrication: Put the bike on a bike stand. Apply chain lubricant sparingly while turning the crank to distribute evenly. Wipe off excess lubricant to prevent dirt accumulation. © 2025 CYC MOTOR LTD... -
Page 13: Troubleshooting Common Issues
Ensure cassette and chain are not excessively worn. Storage Recommendations • Store the bike in a dry, cool place to prevent rust and corrosion. • If storing for extended periods, clean and lubricate the drivetrain before storage. © 2025 CYC MOTOR LTD... -
Page 14: Technical Specifications
Engagement Points: 24 (15 degrees) for quick power transfer. • Freehub Type: Impel 24T ratchet-type, Steel Shimano HG. • Axle Type: Steel thru-axle for increased strength. • Weight: 417g • Technologies • 6-bolt 5 Sealed Bearing © 2025 CYC MOTOR LTD... - Page 15 HD DRIVETRAIN USER MANUAL 148mm x 12mm 157mm x 12mm © 2025 CYC MOTOR LTD...
-
Page 16: Shifter
Compatible with 12x148mm, 12x157mm frames; convertible to 150mm with axle kit Shifter Compatible with Microshift ADVENT systems Not compatible with Shimano or SRAM Derailleur Compatible with 5-speed to 9-speed systems Compatible with ADVENT shifters only Chain Compatible with 9-speed drivetrains © 2025 CYC MOTOR LTD... -
Page 17: Warranty And Service
The manufacturer of the HD Drivetrain will not be held liable for any direct, indirect, incidental, or consequential damage resulting from the use or misuse of this system. Users are solely responsible for their safety while operating their bicycles and assume all risks associated with the use of this drivetrain. © 2025 CYC MOTOR LTD...
