X1 STEALTH GEN 3 USER MANUAL TABLE OF CONTENTS SAFETY & PRECAUTION ................ 3 General Safety ............................ 3 Before the Ride ........................... 3 Installation & Use ..........................4 Disclaimer ............................4 Warning ............................... 5 TECHNICAL SPECFICIATIONS ............. 6 Description ............................6 General ...............................
All components and accessories may only be replaced with identical components directly supplied by CYC MOTOR LTD or an official product dealer/distributor. CYC MOTOR LTD cannot be held liable for any damages as a result of using unapproved parts.
CYC MOTOR LTD does not make any warranties about the completeness of this information and encourages further inquiries If needed. CYC MOTOR LTD will not be held liable for any losses and/ or damages in connection with the use of this product. The use of this product is at own risk.
X1 STEALTH GEN 3 USER MANUAL Please contact CYC MOTOR LTD if you are unsure about the assembly instructions or for any further assistance as CYC MOTOR LTD will be held liable for any losses and/ or damages created by the assembly.
X1 STEALTH GEN 3 USER MANUAL TECHNICAL SPECFICIATIONS Description This product is a high-powered electric bike (ebike) drive unit kit which includes a programmed control unit and peripherals. This product is designed to be installed as a conversion system to convert standard bicycles into electric bicycles.
X1 STEALTH GEN 3 USER MANUAL Mounting Position Integrated between bottom bracket / mounted separately Gearbox First Stage Reduction Hardened steel sun & ring gear with brass planetary gears Second Stage Reduction 219H Chain Overall Reduction 1:28.9 (11/53T) 1:34.4 (11/63T)
X1 STEALTH GEN 3 USER MANUAL Parts List X1 Stealth Gen 3 Motor Assembly with Chainring & controller SW102 or DS103 Display Thumb, Half-Twist or Full Throttle Magnetic Bluetooth Speed Sensor Bottom Bracket Spacers Spindle Spacers BB92 to BSA adapters...
X1 STEALTH GEN 3 USER MANUAL Operating Notice RIGHT-HAND and LEFT-HAND sides are determined by the bike handle; Right-hand corresponds to the right handle. Mounting Options for Controller The CYC X6 controller can be mounted below the bottom bracket (pre-assembled by default) or mounted elsewhere on the bicycle frame at the user’s discretion using controller extension wires...
Page 15
X1 STEALTH GEN 3 USER MANUAL *68mm bottom brackets require a 7mm and a 5mm spacer on the left (non-drive side) and a 3mm spacer on the right (drive side) as shown. *73mm bottom brackets require a 7mm & 3mm spacer on the left (non-drive side) and no spacer on the right (drive side) as shown.
X1 STEALTH GEN 3 USER MANUAL Installation of 68/73/83mm version 1. Line up the motor body with your frame at the bottom bracket, place the bottom bracket spacers accordingly (if applicable) and insert the right (drive) side of the motor into the frame’s bottom bracket shell.
Page 17
X1 STEALTH GEN 3 USER MANUAL bottom bracket cup into the frame’s bottom bracket shell through the spacer/s and the adapter bracket plate. Rotate clockwise but do not tighten fully yet. a. For a 68mm bottom bracket shell, place the 5mm & 7mm bottom bracket spacer over the left (non-drive) side bottom bracket cup before inserting it into the frame’s bottom bracket shell.
Page 18
X1 STEALTH GEN 3 USER MANUAL before being fully inserted, rotate the spindle a bit and try again. Once the spindle is lined up, a soft tip hammer may also be used to get the spindle all the way through.
X1 STEALTH GEN 3 USER MANUAL Installation of BB92 version 1. Insert the BB92 to BSA adapters provided to the frame’s bottom bracket shell. Use a pressfit installation tool to insert the adapters. 2. Line up the motor body with your frame at the bottom bracket and insert the right (drive) side of the motor into the frame’s bottom bracket shell.
Page 20
X1 STEALTH GEN 3 USER MANUAL 3. Add 2 x M5*6 screws into the left (non-drive) side adapter plate and the mounting bracket. 4. Add the 5mm bottom bracket spacer provided outside the adapter bracket plate on the left (non-drive) side of the frame. Thread the left (non-drive) side bottom bracket cup into the frame’s bottom bracket shell through the spacer and the adapter bracket plate.
Page 21
X1 STEALTH GEN 3 USER MANUAL 6. On the left (non-drive) side, thread in the lock ring. Use a 3mm hex key to lightly thread in the lock ring further via the small hole. 7. Install the motor hanger (see page 23) and place the rubber padding provided in between the motor and the frame.
Page 22
X1 STEALTH GEN 3 USER MANUAL 8. Insert spindle spacers on the spindle on the right (drive) side. Place the 200mm spindle in between the left (non-drive) side crank arm and the lock ring before installing the crank arms. 9. Install the left (non-drive) and right (drive) side crank arm according to the L and R indication on your crank arms.
X1 STEALTH GEN 3 USER MANUAL Mounting the Hanger 1. Place one of the aluminium joints on the inside of the bracket & screw in the bolt to attach it to the motor’s mounting plate. 2. Position the hanger over the bike’s frame & screw in the hanger to the aluminium joint loosely.
Page 24
X1 STEALTH GEN 3 USER MANUAL 3. Insert the rubber piece provided between the frame & the bracket. 4. Place the second aluminium joint on the other side of the mounting bracket & connect the hanger fully. Tighten the hanger to ensure that the motor is secured.
X1 STEALTH GEN 3 USER MANUAL Wiring & Connection Connect your controller to the following connectors as per below: 1. Connect the peripheral connector (P1) to the 1-2 or 1-4 wiring harness 2. Connect P2 to the speed sensor 3. P3 & P4 will already be connected when the motor is received...
X1 STEALTH GEN 3 USER MANUAL MOBILE APP & DISPLAY Download the display and mobile app user manuals from the link below or by scanning the QR code. All materials listed below are freely available for download on our website.
X1 STEALTH GEN 3 USER MANUAL GENERAL MAINTENANCE You are advised to regularly maintain, clean, and check the status of the bike and motor system as dirt will accumulate throughout the rides and additional strain will be taken by the drivetrain due to the powerful motor system.
X1 STEALTH GEN 3 USER MANUAL Torque Requirement for Bolts X1 Stealth Gen 3 Left View (Non-Drive Side) X1 Stealth Gen 3 Right View (Drive Side) Listing Component Name Torque Requirement Crank Arm Bolts 27 – 32 N.m. Motor Mounting Bolts 4 –...
Page 29
X1 STEALTH GEN 3 USER MANUAL WARRANTY This product has a 2-year warranty period. Man-made failures are excluded from warranty. Terms and conditions apply. Please visit www.cycmotor.com/refund-and-return-policy for more information. For any queries or complaints, please contact us directly at support@cycmotor.com...
Page 30
CYC MOTOR LTD developed the CYC MOTOR LTD apps, including the RISTRETTO 303 FS and CYC Motor (BAC) app, as free services. These services are provided by CYC MOTOR LTD at no cost and are designed for use 'as is.' The RISTRETTO 303 FS and CYC Motor (BAC) apps gather location data to facilitate Bluetooth device searching following the ASI controller’s protocol.
