X1 PRO GEN 3
User Manual
CYC MOTOR LTD
support@cycmotor.com +852 3690 8938

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X1 PRO GEN 3 and is the answer not in the manual?

Questions and answers

Summary of Contents for CYC Motor X1 PRO GEN 3

  • Page 1 X1 PRO GEN 3 User Manual CYC MOTOR LTD support@cycmotor.com +852 3690 8938...
  • Page 2: Table Of Contents

    X1 PRO GEN 3 USER MANUAL TABLE OF CONTENTS SAFETY & PRECAUTION ................ 3 General Safety ............................ 3 Before the Ride ........................... 3 Installation & Use ..........................4 Disclaimer ............................4 Warning ............................... 5 TECHNICAL SPECFICIATIONS ............. 6 Description ............................6 General ...............................
  • Page 3 X1 PRO GEN 3 USER MANUAL GENERAL MAINTENANCE ..............33 Torque Requirement for Bolts ......................34 Bolt Specifications ........................... 34 WARRANTY..................... 35 PURCHASES FROM A CYC DEALER ..........35 CONTACT INFORMATION ..............35 PRIVACY POLICY ...................36 INFORMATION COLLECTION AND USE ..........36...
  • Page 4: Safety & Precaution

    All components and accessories may only be replaced with identical components directly supplied by CYC MOTOR LTD or an official product dealer/distributor. CYC MOTOR LTD cannot be held liable for any damages as a result of using unapproved parts.
  • Page 5: Installation & Use

    CYC MOTOR LTD does not make any warranties about the completeness of this information and encourages further inquiries If needed. CYC MOTOR LTD will not be held liable for any losses and/ or damages in connection with the use of this product. The use of this product is at own risk.
  • Page 6: Warning

    X1 PRO GEN 3 USER MANUAL Please contact CYC MOTOR LTD if you are unsure about the assembly instructions or for any further assistance as CYC MOTOR LTD will be held liable for any losses and/ or damages created by the assembly.
  • Page 7: Technical Specficiations

    X1 PRO GEN 3 USER MANUAL TECHNICAL SPECFICIATIONS Description This product is a high-powered electric bike (ebike) drive unit kit which includes a programmed control unit and peripherals. This product is designed to be installed as a conversion system to convert standard bicycles into electric bicycles.
  • Page 8: Gearbox

    X1 PRO GEN 3 USER MANUAL Mounting Position Integrated between bottom bracket / mounted separately Gearbox First Stage Reduction Hardened steel sun & ring gear with brass planetary gears 1:6 Second Stage Reduction 53T:11T = 4.82 63T:11T = 5.73 72T:11T = 6.55 Overall Reduction 1:28.9 (11/53T)
  • Page 9: Parts List

    X1 PRO GEN 3 USER MANUAL Parts List X1 Pro Gen 3 Motor Assembly with Chainring 750c, SW102 or DS103 Display Thumb, Half-Twist or Full Throttle Magnetic Bluetooth Speed Sensor Bottom Bracket Spacers Spindle Spacers BB92 to BSA adapters Crankarms with Crankarm Bolts Left Bottom Bracket Cup ©...
  • Page 10 X1 PRO GEN 3 USER MANUAL Mounting Hanger Retaining Lock Ring Spindle (OPTIONAL) Magnetic Brake Sensors (OPTIONAL) Controller Extension Wires © 2023 CYC MOTOR LTD...
  • Page 11: Dimensions

    X1 PRO GEN 3 USER MANUAL Dimensions BSA Threaded 68/73/83mm Version 94mm 253mm 140mm / 165mm / 190mm 177.9mm 165mm / 175mm 82.9mm 62.5mm 83mm 47.5mm 55.3mm 70.6mm 81.81mm 91.6mm 107.1mm © 2023 CYC MOTOR LTD...
  • Page 12: Bsa Threaded 100Mm Version

    X1 PRO GEN 3 USER MANUAL Dimensions BSA Threaded 100mm Version 94mm 253mm 140mm / 165mm / 190mm 177.9mm 165mm / 175mm 91.4mm 54mm 100mm 56mm 63.8mm 79.1mm 90.3mm 100.1mm 115.6mm © 2023 CYC MOTOR LTD...
  • Page 13: Bsa Threaded 120Mm Version

    X1 PRO GEN 3 USER MANUAL Dimensions BSA Threaded 120mm Version 94mm 253mm 140mm / 165mm / 190mm 177.9mm 165mm / 175mm 101.4mm 44mm 120mm 66mm 73.8mm 89.1mm 100.3mm 110.1mm 125.6mm © 2023 CYC MOTOR LTD...
  • Page 14: Bb92 Version

    X1 PRO GEN 3 USER MANUAL Dimensions BB92 Version 94mm 253mm 190mm 177.9mm 165mm / 175mm 79.4mm 66mm 92mm 44mm 52.3mm 67.1mm 78.6mm 97.1mm 112.6mm © 2023 CYC MOTOR LTD...
  • Page 15: Installation

    X1 PRO GEN 3 USER MANUAL INSTALLATION Required Tools Hex Keys (3mm & 8mm) Adjustable Wrench PressFit Bottom Bracket Removal Tools (Only for BB92 version) 16 Notch Bottom Bracket Tool Crank Puller (for disassembly) © 2023 CYC MOTOR LTD...
  • Page 16: Operating Notice

    X1 PRO GEN 3 USER MANUAL Operating Notice RIGHT-HAND and LEFT-HAND sides are determined by the bike handle; Right-hand corresponds to the right handle. Mounting Options for Controller The CYC X6 controller can be mounted below the bottom bracket (pre-assembled by default) or mounted elsewhere on the bicycle frame at the user’s discretion using controller extension wires...
  • Page 17 X1 PRO GEN 3 USER MANUAL *68mm bottom brackets require a 7mm and a 5mm spacer on the left (non-drive side) and a 3mm spacer on the right (drive side) as shown. *73mm bottom brackets require a 7mm & 3mm spacer on the left (non-drive side) and no spacer on the right (drive side) as shown.
  • Page 18: Installation Of 68/73/83Mm Version

    X1 PRO GEN 3 USER MANUAL Installation of 68/73/83mm version a. Remove the bolts as indicated within the circles in order to loosen the left (non- drive) side mounting bracket. b. Loosen the bolt as indicated within the square Do not remove completely.
  • Page 19 X1 PRO GEN 3 USER MANUAL iv. For 100mm and 120mm version, no spacers are needed. *Kindly note that the bottom bracket spacer placement mentioned above are provided as guidelines only for most general frames. You may place a spacer/s on either side of the bottom bracket cups according to your desired chainline.
  • Page 20 X1 PRO GEN 3 USER MANUAL c. Lightly tighten the lock ring. The spindle should not be tensioned too much by the lock ring and should still be able to rotate freely by hand. 5. Install the motor hanger and place the rubber padding provided in between the motor and the frame.
  • Page 21 X1 PRO GEN 3 USER MANUAL a. Insert the spindle spacers on the spindle on the right (drive) side. b. Insert spindle spacers over the spindle on the left (non-drive) side. Place spacers accordingly up to the indicated line. a. Install the left (non-drive) and right (drive) side crank arm according to the L and R indication on your crank arms.
  • Page 22: Installation Of 100Mm & 120Mm Version

    X1 PRO GEN 3 USER MANUAL Installation of 100mm & 120mm version 1. Remove the bolts as indicated within the circles in order to loosen the left (non-drive) side mounting bracket, also slightly the remaining bolt holding the side plate so that the plate is able to pivot.
  • Page 23 X1 PRO GEN 3 USER MANUAL 3. Insert the spindle from the right (drive) side. Note that you will need to line up the splines with the chainring assembly. If your spindle does not go through or comes to a hard stop before being fully inserted, rotate the spindle slightly and try again.
  • Page 24 X1 PRO GEN 3 USER MANUAL 4. On the left (non-drive) side, thread in the lock ring. Use a 3mm hex key to lightly thread in the lock ring further via the small hole. Lightly tighten the lock ring. 5. Install the motor hanger (see page 29) and place the rubber padding provided in between the motor and the frame.
  • Page 25 X1 PRO GEN 3 USER MANUAL 6. Insert spindle spacers on the spindle on the right (drive) side. Place the 120mm spindle spacer in between the left (non-drive) side crank arm and the lock ring before installing the crank arms.
  • Page 26: Installation Of Bb92 Version

    X1 PRO GEN 3 USER MANUAL Installation of BB92 version a. Install the BB92 to BSA adapters provided to the frame’s bottom bracket shell. Use a press fit installation tool to insert the adapters, ensure to add grease on the adapters before pressing in.
  • Page 27 X1 PRO GEN 3 USER MANUAL 3. Add 2 X M5*6 screws into the left (non-drive) side adapter plate and the mounting bracket. a. Add the 5mm bottom bracket spacer provided outside the adapter bracket plate on the left (non-drive) side of the frame.
  • Page 28 X1 PRO GEN 3 USER MANUAL 5. Insert the spindle from the right (drive). Note that you will need to line up the splines with the chainring assembly. If your spindle does not go through or comes to a hard stop before being fully inserted, rotate the spindle a bit and try again.
  • Page 29 X1 PRO GEN 3 USER MANUAL a. Insert spindle spacers on the spindle on the right (drive) side. b. Insert spindle over the spindle on the left (non-drive) side. Place spacers accordingly up to the indicated line. a. Install the left (non-drive) and right (drive) side crank arm according to the L and R indication on your crank arms.
  • Page 30: Mounting The Hanger

    X1 PRO GEN 3 USER MANUAL Mounting the Hanger 1. Place one of the aluminium joints on the inside of the bracket & screw in the bolt to attach it to the motor’s mounting plate. 2. Position the hanger over the bike’s frame & screw in the hanger to the aluminium joint loosely.
  • Page 31 X1 PRO GEN 3 USER MANUAL 3. Insert the rubber piece provided between the frame & the bracket. 4. Place the second aluminium joint on the other side of the mounting bracket & connect the hanger fully. Tighten the hanger to ensure that the motor is secured.
  • Page 32: Wiring & Connection

    X1 PRO GEN 3 USER MANUAL Wiring & Connection Connect your controller to the following connectors as per below: 1. Connect the peripheral connector (P1) to the 1-2 or 1-4 wiring harness 2. Connect P2 to the speed sensor 3. P3 & P4 will already be connected when the motor is received...
  • Page 33: Mobile App & Display

    X1 PRO GEN 3 USER MANUAL MOBILE APP & DISPLAY Download the display and mobile app user manuals from the link below or by scanning the QR code. All materials listed below are freely available for download on our website.
  • Page 34: General Maintenance

    X1 PRO GEN 3 USER MANUAL GENERAL MAINTENANCE You are advised to regularly maintain, clean, and check the status of the bike and motor system as dirt will accumulate throughout the rides and additional strain will be taken by the drivetrain due to the powerful motor system.
  • Page 35: Torque Requirement For Bolts

    X1 PRO GEN 3 USER MANUAL Torque Requirement for Bolts X1 Pro Gen 3 Right View (Drive Side) X1 Pro Gen 3 Left View (Non-Drive Side) Listing Component Name Torque Requirement Crank Arm Bolts 27 – 32 N.m. Motor Mounting Bolts 4 –...
  • Page 36: Warranty

    X1 PRO GEN 3 USER MANUAL WARRANTY This product has a 2-year warranty period. Man-made failures are excluded from warranty. Terms and conditions apply. Please visit www.cycmotor.com/refund-and-return-policy for more information. For any queries or complaints, please contact us directly at support@cycmotor.com...
  • Page 37: Privacy Policy

    CYC MOTOR LTD developed the CYC MOTOR LTD apps, including the RISTRETTO 303 FS and CYC Motor (BAC) app, as free services. These services are provided by CYC MOTOR LTD at no cost and are designed for use 'as is.' The RISTRETTO 303 FS and CYC Motor (BAC) apps gather location data to facilitate Bluetooth device searching following the ASI controller’s protocol.
  • Page 38 X1 PRO GEN 3 USER MANUAL in this privacy policy. Please be aware that our app uses third-party services that may collect information used to identify you. Please visit www.cycmotor.com/privacy-policy for more detailed information. © 2023 CYC MOTOR LTD...
