CYC Motor X1 STEALTH GEN 3 User Manual

Hide thumbs Also See for X1 STEALTH GEN 3:
Table of Contents

Advertisement

Quick Links

Download this manual
X1 STEALTH GEN 3
User Manual
CYC MOTOR
support@cycmotor.com +952 3690 8938

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X1 STEALTH GEN 3 and is the answer not in the manual?

Questions and answers

Related Manuals for CYC Motor X1 STEALTH GEN 3

Summary of Contents for CYC Motor X1 STEALTH GEN 3

  • Page 1 X1 STEALTH GEN 3 User Manual CYC MOTOR support@cycmotor.com +952 3690 8938...

  • Page 2: Table Of Contents

    X1 STEALTH GEN 3 USER MANUAL TABLE OF CONTENTS SAFETY & PRECAUTION ................ 4 General Safety ............................ 4 Before the Ride ........................... 4 Installation & Use ..........................5 Disclaimer ............................5 TECHNICAL SPECFICIATIONS ............. 7 Description ............................7 General ............................... 7 Motor ..............................
  • Page 3 X1 STEALTH GEN 3 USER MANUAL General ............................30 Modes & Levels ..........................31 Throttle ............................32 Pedal Assist ........................... 33 Peripherals Setup .......................... 34 Wheel Diameter ..........................34 Battery ............................35 SW102 Display User Guide ....................... 37 Product Details ..........................37 Dimensions &...
  • Page 4 X1 STEALTH GEN 3 USER MANUAL Information Collection and Use ......................54 © 2023 CYCMOTOR LTD...

  • Page 5: Safety & Precaution

    X1 STEALTH GEN 3 USER MANUAL SAFETY & PRECAUTION General Safety Kindly read through the entire user manual. This manual contains important information to reduce user risk as well as instructions for this product’s proper use. Do not discard the manual but keep it for reference.

  • Page 6: Installation & Use

    X1 STEALTH GEN 3 USER MANUAL Inspect all electrical wires and plugs for damage regularly. Secure all wires properly. Ensure that the throttle can bet twisted freely without friction and that the throttle can return to its original position without restriction. This is to prevent any uncontrolled response of the system.
  • Page 7 X1 STEALTH GEN 3 USER MANUAL Warning Any issues with this product’s performance or damages sustained to the product as a result of loading unauthorized firmware, will not be supported, or warrantied by CYCMOTOR LTD or any authorised product dealer.

  • Page 8: Technical Specficiations

    X1 STEALTH GEN 3 USER MANUAL TECHNICAL SPECFICIATIONS Description This product is a high-powered electric bike (ebike) drive unit kit which includes a programmed control unit and peripherals. This product is designed to be installed as a conversion system to convert standard bicycles into electric bicycles.

  • Page 9: Gearbox

    X1 STEALTH GEN 3 USER MANUAL Gearbox First Stage Reduction Hardened steel sun & ring gear with brass planetary gears Second Stage Reduction 219H Chain Overall Reduction 1:28.9 (11/53T) 1:34.4 (11/63T) © 2023 CYCMOTOR LTD...

  • Page 10: Parts List

    X1 STEALTH GEN 3 USER MANUAL Parts List X1 Stealth Gen 3 Motor Assembly with Chainring SW102 or DS103 Display Thumb, Half-Twist or Full Throttle Magnetic Bluetooth Speed Sensor Bottom Bracket Spacers (OPTIONAL) Magnetic Brake Sensors (OPTIONAL) Controller Extension Wires...
  • Page 11 X1 STEALTH GEN 3 USER MANUAL Crankarms with crankarm bolts Adapter Plate Left BB Cup Mounting Hanger Retaining Clip Spindle © 2023 CYCMOTOR LTD...

  • Page 12: Dimensions

    X1 STEALTH GEN 3 USER MANUAL Dimensions BSA Threaded 68/73/83mm Version 74mm 201mm 140mm 135.5mm 165mm 81.4mm 52.4mm 83mm 47.5mm 55.6mm 70.59mm 81.9mm 91.6mm 107.1mm © 2023 CYCMOTOR LTD...

  • Page 13: Bb92 Version

    X1 STEALTH GEN 3 USER MANUAL Dimensions BB92 Version 74mm 201mm 165mm 135.5mm 170mm 77.92mm 55.9mm 92mm 53mm 61.1mm 76.1mm 87.4mm 97.1mm 112.6mm © 2023 CYCMOTOR LTD...

  • Page 14: Installation

    X1 STEALTH GEN 3 USER MANUAL INSTALLATION Required Tools Hex Keys (3mm & 8mm) Adjustable Wrench Crank Puller (for disassembly) PressFit Bottom Bracket Removal Tools (Only for BB92 version) 16 Notch Bottom Bracket Tool © 2023 CYCMOTOR LTD...

  • Page 15: Operating Notice

    X1 STEALTH GEN 3 USER MANUAL Operating Notice RIGHT-HAND and LEFT-HAND sides are determined by the bike handle; Right-hand corresponds to the right handle. Mounting Options for Controller The CYC X6 controller can be mounted below the bottom bracket (pre-assembled by default) or mounted elsewhere on the bicycle frame at the user’s discretion using controller extension wires...
  • Page 16 X1 STEALTH GEN 3 USER MANUAL *68mm bottom brackets require a 7mm and a 5mm spacer on the left (non-drive side) and a 3mm spacer on the right (drive side) as shown. *73mm bottom brackets require a 7mm & 3mm spacer on the left (non-drive side) and no spacer on the right (drive side) as shown.

  • Page 17: Installation Of 68/73/83Mm Version

    X1 STEALTH GEN 3 USER MANUAL Installation of 68/73/83mm version 1. Line up the motor body with your frame at the bottom bracket, place the bottom bracket spacers accordingly (if applicable) and insert the right (drive) side of the motor into the frame’s bottom bracket shell.
  • Page 18 X1 STEALTH GEN 3 USER MANUAL a. For a 68mm bottom bracket shell, place the 5mm & 7mm bottom bracket spacer over the left (non-drive) side bottom bracket cup before inserting it into the frame’s bottom bracket shell. b. For a 73mm bottom bracket shell, place the 3mm & 7mm bottom bracket spacer over the left (non-drive) side bottom bracket cup before inserting it into the frame’s bottom bracket shell.
  • Page 19 X1 STEALTH GEN 3 USER MANUAL before being fully inserted, rotate the spindle a bit and try again. Once the spindle is lined up, a soft tip hammer may also be used to get the spindle all the way through.

  • Page 20: Installation Of Bb92 Version

    X1 STEALTH GEN 3 USER MANUAL Installation of BB92 version 1. Insert the BB92 to BSA adapters provided to the frame’s bottom bracket shell. Use a pressfit installation tool to insert the adapters. 2. Line up the motor body with your frame at the bottom bracket and insert the right (drive) side of the motor into the frame’s bottom bracket shell.
  • Page 21 X1 STEALTH GEN 3 USER MANUAL 3. Add 2 x M5*6 screws into the left (non-drive) side adapter plate and the mounting bracket. 4. Add the 5mm bottom bracket spacer provided outside the adapter bracket plate on the left (non-drive) side of the frame. Thread the left (non-drive) side bottom bracket cup into the frame’s bottom bracket shell through the spacer and the adapter bracket plate.
  • Page 22 X1 STEALTH GEN 3 USER MANUAL 6. On the left (non-drive) side, thread in the lock ring. Use a 3mm hex key to lightly thread in the lock ring further via the small hole. 7. Install the motor hanger (see page 23) and place the rubber padding provided in between the motor and the frame.
  • Page 23 X1 STEALTH GEN 3 USER MANUAL 8. Insert spindle spacers on the spindle on the right (drive) side. Place the 200mm spindle in between the left (non-drive) side crank arm and the lock ring before installing the crank arms. 9. Install the left (non-drive) and right (drive) side crank arm according to the L and R indication on your crank arms.

  • Page 24: Mounting The Hanger

    X1 STEALTH GEN 3 USER MANUAL Mounting the Hanger 1. Place one of the aluminium joints on the inside of the bracket & screw in the bolt to attach it to the motor’s mounting plate. 2. Position the hanger over the bike’s frame & screw in the hanger to the aluminium joint loosely.
  • Page 25 X1 STEALTH GEN 3 USER MANUAL 3. Insert the rubber piece provided between the frame & the bracket. 4. Place the second aluminium joint on the other side of the mounting bracket & connect the hanger fully. Tighten the hanger to ensure that the motor is secured.

  • Page 26: Wiring & Connection

    X1 STEALTH GEN 3 USER MANUAL Wiring & Connection Connect your controller to the following connectors as per below: 1. Connect the peripheral connector (P1) to the 1-2 or 1-4 wiring harness 2. Connect P2 to the speed sensor 3. P3 & P4 will already be connected when the motor is received...

  • Page 27: Mobile App & Display

    X1 STEALTH GEN 3 USER MANUAL MOBILE APP & DISPLAY Ride Control App User Guide Monitor & customize your e-bike riding experience for all CYCMOTOR mid-drive systems. Use it as a secondary dashboard, settings set-up, or both. Unleash all the possibilities of e-bike customization at your fingertips.

  • Page 28: Dashboard

    X1 STEALTH GEN 3 USER MANUAL Dashboard Brake sensor indicator Warning icon to check COMING SOON error codes & clear faults Bluetooth icon to connect to your device Instantly change between STREET & RACE mode Change between your DASHBOARD & SETTINGS...

  • Page 29: Connecting A Device

    X1 STEALTH GEN 3 USER MANUAL Connecting a Device Step #1: Open the app and tap the Search button at the bottom of the screen. Kindly ensure your phone’s Bluetooth is enabled. (Please keep close to the motor while connecting)

  • Page 30: Main Settings

    X1 STEALTH GEN 3 USER MANUAL Main Settings The settings page allows you to navigate through different parameter categories. There are six different categories with each providing a set of adjustable parameters or readings from your ebike system. IMPORTANT Save all new changes in parameters to flash or risk losing progress after a restart.

  • Page 31: General

    X1 STEALTH GEN 3 USER MANUAL General Temperature Unit Set your units to display in degree Celsius (°C) or Fahrenheit (°F) Speed Unit Set the speed unit to miles or kilometres Motor Direction This setting is for users who’d want to switch the direction to where the motor is facing.

  • Page 32: Modes & Levels

    X1 STEALTH GEN 3 USER MANUAL Modes & Levels Race & Street Mode You can set the throttle & PAS output independently for both modes. Race Mode Throttle & PAS Race Mode is your “boost” or “full power” mode and has parameters set for reaching closer to the system’s full capabilities.

  • Page 33: Throttle

    X1 STEALTH GEN 3 USER MANUAL Throttle Ramp Up Time This is the time it takes for the motor to achieve the required input. For example, if you open the throttle fully, it will take 250ms (by default) before the motor gives you full power. It will gradually ramp up to full power within the set time.

  • Page 34: Pedal Assist

    X1 STEALTH GEN 3 USER MANUAL Pedal Assist Pedal Assist Sensor Enable or disable pedal assist. Torque Sensor Sensitivity This value pertains to activating pedal assist when it’s completely off. This is the amount of pedal force required to activate the pedal assist.

  • Page 35: Peripherals Setup

    X1 STEALTH GEN 3 USER MANUAL Peripherals Setup Wheel Diameter The wheel diameter can be measured or be calculated. We advise that this number must be calibrated so that vehicle speed within the app matches display speed. Wheel Magnet This is the number of magnets in the wheel that is communicating with the speed sensor.

  • Page 36: Battery

    X1 STEALTH GEN 3 USER MANUAL Battery Battery Type / Series of Cells 10s = 36V, 14s=52V, 20s=72V Minimum Voltage The value the controller will fault when connecting too low a voltage to the system. This setting can be used to protect your battery if too much voltage sag is detected.
  • Page 37 X1 STEALTH GEN 3 USER MANUAL Please note that the Maximum Power Level MUST be changed in the CYC Ride Control App to match your battery’s specifications. Follow the guidelines below: Battery Voltage Motor Power Limit 2500W 2000W 1500W 2400W...

  • Page 38: Sw102 Display User Guide

    X1 STEALTH GEN 3 USER MANUAL SW102 Display User Guide Product Details Product Name Intelligent OLED display, model: SW102 Firmware: CYCMotor Ltd specific firmware Features • Minimalist design and process • High brightness, high contrast 1.3-inch monochromatic OLED screen •...

  • Page 39: Quick Start Guide

    X1 STEALTH GEN 3 USER MANUAL Quick Start Guide After unboxing and installing your CYC motor system, there are two main things you need to set 1. Change your Battery No. setting according to your rated voltage. a. Within 15 seconds of turning on your display, long press the MENU button to enter the settings functions.

  • Page 40: Functionalities

    X1 STEALTH GEN 3 USER MANUAL Functionalities Power On/Off Press and hold the POWER button for 2 seconds to turn the display on/off. The display will automatically shut down when there is no operation for a period of time. Navigation 1.
  • Page 41 X1 STEALTH GEN 3 USER MANUAL Switch Dashboard Switch the main dashboard to display different information by pressing the MENU button. Assist Level Operating Press the UP/DOWN button to change the assist level between level 1, 2, and 3. Please note that “OFF”...
  • Page 42 X1 STEALTH GEN 3 USER MANUAL Walk Assist Long press the DOWN button to activate walk assist. Note that it takes 3 seconds to activate & will deactivate immediately when the button is released. Walk assist can only be activated if you are in assist level 1, 2, or 3.
  • Page 43 X1 STEALTH GEN 3 USER MANUAL Clean Trip Data Wait 15 seconds after starting up the motor system to be able to enter the “Clean Data” menu. Long press the MENU button to clear previous trip data. Please note that the trip data does not automatically clear once you restart the motor system.

  • Page 44: Installation

    X1 STEALTH GEN 3 USER MANUAL Installation Open the display lock clip, set the display in the left handlebar (standard handlebar size Φ22.2). Adjust it in place and tighten the screw accordingly. Note: Damage caused by excessive torque is not covered by warranty.

  • Page 45: Ds103 Display User Guide

    X1 STEALTH GEN 3 USER MANUAL DS103 Display User Guide Product Details Intelligent LCD display, model: DS103 Firmware: CYCMotor Ltd specific firmware Features • Simple and lightweight, separate installation bracket design • High brightness, high contrast 3.5 coloured TFT screen •...

  • Page 46: Quick Start Guide

    Waterproof level: IP65 Quick Start Guide After unboxing and installing your CYC motor system, there are two main things you need to set 1. Change your Battery No. settings according to your rated voltage. Within 15 seconds of turning on your display, long press the MENU button to enter the settings functions.

  • Page 47: Functionalities

    X1 STEALTH GEN 3 USER MANUAL 2. Change your Wheel settings according to your bike’s wheel size. 3. You can now set up parameters like temperature and the speed unit as well as the brightness level! Functionalities Press and hold the POWER button for 3 seconds to turn the display on/ off.
  • Page 48 X1 STEALTH GEN 3 USER MANUAL Switch Dashboard Switch the main dashboard to display different information by pressing the MODE button. Assist Level Operating Press the UP/DOWN button to change the assist level between level 1, 2, and 3. Note that “OFF”...
  • Page 49 X1 STEALTH GEN 3 USER MANUAL Walk Assist Hold in the DOWN button to activate walk assist. Please note it takes 3 seconds to activate & will deactivate immediately when the button is released. Settings Long press the MODE button within 15 seconds of switching on the display to enter the “Settings”...

  • Page 50: Error Codes

    X1 STEALTH GEN 3 USER MANUAL Error Codes In certain circumstances, an error code may appear on your display. Contact us for assistance. Error Code on App & DS103 Display Controller Over Voltage Controller Under Voltage Controller Over Temperature Hall Sensor Error...

  • Page 51: Pin Layout

    X1 STEALTH GEN 3 USER MANUAL Compatibility The clamps are suitable for 3x different handlebar sizes: 31.8mm, 25.4mm & 22.2mm. Pin Layout Male 5-Pin Connector Red Wire: Anode (36V to 72V) Black Wire: GND Yellow Wire: TxD (display -> controller) Green Wire: RxD (controller ->...

  • Page 52: General Maintenance

    X1 STEALTH GEN 3 USER MANUAL GENERAL MAINTENANCE You are advised to regularly maintain, clean, and check the status of the bike and motor system as dirt will accumulate throughout the rides and additional strain will be taken by the drivetrain due to the powerful motor system.

  • Page 53: Torque Requirement For Bolts

    X1 STEALTH GEN 3 USER MANUAL Torque Requirement for Bolts X1 Stealth Gen 3 Left View (Non-Drive Side) X1 Stealth Gen 3 Right View (Drive Side) Listing Component Name Torque Requirement Crank Arm Bolts 27 – 32 N.m. Motor Mounting Bolts 4 –...

  • Page 54: Warranty

    X1 STEALTH GEN 3 USER MANUAL WARRANTY This product has a 2-year warranty period. Man-made failures are excluded from warranty. Terms and conditions apply. Please visit www.cycmotor.com/refund-and-return-policy for more information. For any queries or complaints, please contact us directly at support@cycmotor.com...

  • Page 55: Disclaimer

    X1 STEALTH GEN 3 USER MANUAL DISCLAIMER The electric bicycle system described in this user manual is designed for use only with compatible electric bicycles. It is important to read and understand this manual before using the system. The manufacturer of this electric bicycle system shall not be liable for any direct, indirect, incidental, or consequential damages arising from the use or misuse of this system.
