User's
Manual
Thank you for purchasing the AQ23011A/AQ23012A Modules.
To ensure correct use, please read this manual thoroughly before beginning operation. For details on the
functions and performance, see the user's manual for the AQ23011A/AQ23012A frame (IM AQ23011A-01EN,
IM AQ23011A-02EN, and IM AQ23011A-03EN). The following manuals, including this one, are provided as
manuals for the instruments. Please read all manuals.
Manual Title
Model AQ23811A
Checking the Contents of the Package
and Handling Precautions of the Modules
Modules for AQ23011A, AQ23012A
The "EN" and "Z1" in the manual numbers are the language codes.
The latest editions of manuals and firmware (AQ23011A, or AQ23012A software) are available to registered
customers for download from our website.
Sign in to Customer Portal at the following website.
https://myportal.yokogawa.com/
Contact information of Yokogawa offices worldwide is provided on the following sheet.
Manual No.
PIM 113-01Z2
Safety Precautions
This product is designed to be used by a person with specialized knowledge. The general safety precautions
described herein must be observed during all phases of operation. If the instrument is used in a manner not
specified in this manual, the protection provided by the instrument may be impaired.
This manual is part of the product and contains important information. Store this manual in a safe place close to
the instrument so that you can refer to it immediately. Keep this manual until you dispose of the instrument.
YOKOGAWA assumes no liability for the customer's failure to comply with these requirements.
The following symbols are used on this instrument.
Handle with care. Refer to the user's manual or service manual. This symbol appears on dangerous
locations on the instrument which require special instructions for proper handling or use. The same
symbol appears in the corresponding place in the manual to identify those instructions.
French
À manipuler délicatement. Toujours se reporter aux manuels d'utilisation et d'entretien. Ce symbole a
été apposé aux endroits dangereux de l'instrument pour lesquels des consignes spéciales d'utilisation
ou de manipulation ont été émises. Le même symbole apparaît à l'endroit correspondant du manuel
pour identifier les consignes qui s'y rapportent.
Safty Precautions of the Modules
The following precautions must be observed when handling the modules. YOKOGAWA assumes no liability for
the customer's failure to comply with these requirements. For details on the installation/removal procedure and
the specifications of the modules, see the user's manual for the AQ23011A/AQ23012A frame (IM AQ23011A-
03EN).
Use the Instrument Only for Its Intended Purpose
This instrument functions as a source measure instrument that sources and measures voltage
and current when an SMU is used in the frame. Use this instrument only for this purpose.
Check the Physical Appearance
Do not use the instrument if there is a problem with its physical appearance.
Model AQ23811A
Checking the Contents of the Package and
Handling Precautions of the Modules
Manual No.
IM AQ23811A-01EN This manual. This is included with AQ23011A/AQ23012A
IM AQ23811A-92Z1 A document for China.
Description
List of worldwide contacts
WARNING
1st Edition: October 2024 (YMI)
All Rights Reserved. Copyright © 2024, Yokogawa Test & Measurement Corporation
Printed in Japan
Description
modules. It explains the handling precautions of the module
and lists the package contents.
*IM AQ23811A-01EN/1*
IM AQ23811A-01EN 1/3
1st Edition
