Solplanet ASW008K-SH Quick Installation Manual

Single phase hybrid inverter
Hide thumbs

Advertisement

Quick Links

Download this manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the ASW008K-SH and is the answer not in the manual?

Questions and answers

Related Manuals for Solplanet ASW008K-SH

Summary of Contents for Solplanet ASW008K-SH

  • Page 2: General Information

    The contents of this guide may be updated or revised due to product development. The information in this guide is subject to change without notice. The latest version of this document and the manual for installation, commissioning, configuration and decommissioning are to be found in PDF format at www.solplanet.net. Safety Intended use...
  • Page 3 The product must only be operated in connection with an intrinsically safe lithium-ion battery approved by AISWEI. The entire battery voltage range must be completely within the permissible input voltage range of the product. The product must only be used in countries for which it is approved by AISWEI and the grid operator.
  • Page 4 DANGER Danger to life due to electric shock when touching live components in backup mode！ Even if the AC breaker and the PV switch of the inverter are disconnected, the parts of the system may still be live when the battery is switched on due to backup mode. Do not open the product.
  • Page 5 DANGER Danger to life due to electric shock when touching live system components in case of a ground fault！ If a ground fault occurs, parts of the system may still be live. Touching live parts and cables may result in death or lethal injuries due to electric shock. Disconnect the product from voltage and energy sources and ensure it cannot be ...
  • Page 6 Symbols on the label Beware of a danger zone！ This symbol indicates that the product must be additionally grounded if additional grounding or equipotential bonding is required at the installation site. Beware of high voltage and operating current！ The inverter operates at high voltage and current. Work on the inverter must only be carried out by skilled and authorized electricians.

  • Page 7: System Wiring Diagram

    System Wiring Diagram QG0070_ASW008-010K-SH_EN_540-300618-01_V02_1024...
  • Page 8 QG0070_ASW008-010K-SH_EN_540-300618-01_V02_1024...

  • Page 9: Parallel System

    Parallel System If parallel operation is required, please contact AISWEI or installer to purchase new accessories, specified meters and CT. QG0070_ASW008-010K-SH_EN_540-300618-01_V02_1024...

  • Page 10: Eu Declaration Of Conformity

    AISWEI Technology Co., Ltd. confirms herewith that the products described in this document are in compliance with the fundamental requirements and other relevant provisions of the above mentioned directives. The entire EU Declaration of Conformity can be found at www.solplanet.net. Overview Bottom wiring port...
  • Page 11 Internal wiring terminal Object Description Grid terminal BACKUP terminal Genset terminal Battery input terminal Parallel port Communication terminal (refer to 6.3 Interface Pinout Table) PV input terminal Interface Pinout Table QG0070_ASW008-010K-SH_EN_540-300618-01_V02_1024...

  • Page 12: Scope Of Delivery

    Function PIN definition Num. Designator description CN704 Ethernet COM2 RS485 CN705 COM2 RS485A RS485B GND (reserved) RS485 CN706 COM1 RS485A RS485B GND (reserved) Monitor RS485B RS485 CN707 COM1 RS485BB GND RS485B (RS485) RS485E RS485E CN708 COM2 CANH CANL CAN&RS485 RS485A RS485 RS485B RS485A...
  • Page 13 Please install either smart meter or CT. Solplanet App Brief introduction Solplanet App is an Android and iOS App which can establish communication connection to the inverter via the included communication device for remote and near-end initial setup and maintenance on the inverter.

  • Page 14: Mounting Environment

    Mounting Environment QG0070_ASW008-010K-SH_EN_540-300618-01_V02_1024...
  • Page 15 10 Dimensions Unit:mm Mounting     QG0070_ASW008-010K-SH_EN_540-300618-01_V02_1024...
  • Page 16     12 Second Protective Grounding      QG0070_ASW008-010K-SH_EN_540-300618-01_V02_1024...

  • Page 17: Grid Connection

    13 Grid Connection     ENY16-18 (recommended) XMK8 6-8 (recommended)    QG0070_ASW008-010K-SH_EN_540-300618-01_V02_1024...
  • Page 18    QG0070_ASW008-010K-SH_EN_540-300618-01_V02_1024...
  • Page 19 14 EPS Load Connection    ENY10-12 (recommended) XMK8 6-8 (recommended)      QG0070_ASW008-010K-SH_EN_540-300618-01_V02_1024...

  • Page 20: Generator Connection

      15 Generator Connection    ENY10-12 (recommended) XMK8 6-8 (recommended)  QG0070_ASW008-010K-SH_EN_540-300618-01_V02_1024...
  • Page 21       QG0070_ASW008-010K-SH_EN_540-300618-01_V02_1024...
  • Page 22 16 DC Connection  ENY6012 (recommended) XMK8 6-8 (recommended)      QG0070_ASW008-010K-SH_EN_540-300618-01_V02_1024...

  • Page 23: Battery Connection

       17 Battery Connection Type 1: Lithium battery   XMK25-6 (recommended)  QG0070_ASW008-010K-SH_EN_540-300618-01_V02_1024...
  • Page 24        QG0070_ASW008-010K-SH_EN_540-300618-01_V02_1024...
  • Page 25 Type 2: Lead-acid battery   COM1 shown as an example; all COM ports NTC cable: 3m have the same functionality.  3 4 5     QG0070_ASW008-010K-SH_EN_540-300618-01_V02_1024...
  • Page 26  The wiring configuration with the battery follows the manufacturer's requirements. QG0070_ASW008-010K-SH_EN_540-300618-01_V02_1024...

  • Page 27: Communication Setup

    18 Communication Setup 18.1 Ai-Dongle connection         QG0070_ASW008-010K-SH_EN_540-300618-01_V02_1024...
  • Page 28 18.2 RJ45 connection   Refer to 6.3 Interface Pinout Table     QG0070_ASW008-010K-SH_EN_540-300618-01_V02_1024...
  • Page 29 18.3 Ripple control connection       QG0070_ASW008-010K-SH_EN_540-300618-01_V02_1024...
  • Page 30 18.4 NA protection connection       QG0070_ASW008-010K-SH_EN_540-300618-01_V02_1024...
  • Page 31 18.5 Current Transformer connection      QG0070_ASW008-010K-SH_EN_540-300618-01_V02_1024...
  • Page 32 QG0070_ASW008-010K-SH_EN_540-300618-01_V02_1024...
  • Page 33 18.6 Smart meter connection (optional)      QG0070_ASW008-010K-SH_EN_540-300618-01_V02_1024...
  • Page 34 QG0070_ASW008-010K-SH_EN_540-300618-01_V02_1024...
  • Page 35 18.7 DO connection        QG0070_ASW008-010K-SH_EN_540-300618-01_V02_1024...
  • Page 36 ——Inverter model ——Inverter serial number ——Photovoltaic module model ——Photovoltaic modules number and strings number connected to each MPPT ——Fault code ——Installation location EMEA Service email: service.EMEA@solplanet.net APAC Service email: service.APAC@solplanet.net LATAM Service email: service.LATAM@solplanet.net Aiswei Greater China Service email: service.china@aiswei-tech.com...
  • Page 37 QG0070_ASW008-010K-SH_EN_540-300618-01_V02_1024...

This manual is also suitable for:

Asw010k-sh
