Solplanet ASW TH Series User Manual

Three phase hybrid inverter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ASW TH Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Solplanet ASW TH Series

Summary of Contents for Solplanet ASW TH Series

  • Page 2: Table Of Contents

    (optional) ........................................... 50 Commissioning and operation ................................59 Inspection before commissioning ..............................59 Commissioning procedure ................................59 Solplanet APP ......................................60 Download and install..................................60 Revision History ..................................... 60 Decommissioning the product ................................. 61 Disconnecting the inverter from energy sources ........................... 61 Dismantling the inverter ................................
  • Page 3 10.3 Protective device ................................... 66 Troubleshooting ...................................... 67 Maintenance ......................................69 12.1 Cleaning the contacts of the DC switch ............................69 12.2 Cleaning air inlet and outlet ................................69 Recycling and disposal.................................... 70 EU declaration of conformity .................................. 70 Service and warranty ....................................70 Contact ........................................

  • Page 4: General Information

    The latest version of this document, the quick installation guide and further information are to be found in PDF format at www.solplanet.net. It is recommended that this document is stored in an appropriate location and be available at all times.

  • Page 5: Symbols

    1.4 Symbols DANGER Indicates a hazardous situation which, if not avoided, will result in death or serious injury. WARNING Indicates a hazardous situation which, if not avoided, could result in death or serious injury. CAUTION Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. NOTICE Indicates a situation which, if not avoided, can result in property damage.

  • Page 6: Safety

     and directives. Any other application may cause personal injury or damage to property. The product must only be operated in connection with an intrinsically safe lithium-ion battery approved by Solplanet. The entire  battery voltage range must be completely within the permissible input voltage range of the product. The latest version of the Solplanet battery compatibility list can be found in PDF format at www.solplanet.net.
  • Page 7 Do not touch any live components of the product. • Do not open the product. • Observe all safety information provided by the battery manufacturer. • All work on the product must only be carried out by qualified personnel who have read and fully understood all safety information •...

  • Page 8: Symbols On The Label

    WARNING Danger to life due to risk of fatal electric shock from damages to the measuring device caused by overvoltage！ Overvoltage can damage a measuring device and result in voltage being present in the enclosure of the measuring device. Touching the live enclosure of the measuring device results in death or lethal injuries due to electric shock. Only use measuring devices with a measurement span equal to or higher than maximum voltage range of the product.
  • Page 9 Beware of hot surfaces！ The product can become hot during operation. Avoid contact during operation. WEEE Designation Do not dispose of the product together with household waste. Dispose the product in accordance with local disposal regulations for electronic waste applicable in the country of installation. CE marking The product complies with the requirements of the applicable EU directives.

  • Page 10: Unpacking And Storage

    3 Unpacking and storage 3.1 Scope of delivery Check the scope of delivery for completeness and any visible external damage. Contact your distributor if the scope of delivery is incomplete or damaged. Object Description Quantity Inverter Mounting Bracket Mounting Bracket Template AC Connector Diesel Generator Connector (Reserved) EPS Load Connector...

  • Page 11: Product Storage

    Communication Terminal Package Document package 3.2 Product storage Suitable storage is required if the inverter is not installed immediately: Store the inverter in the original packaging.  The storage temperature must be between -30°C to +60°C, and the storage relative humidity must be between 0 and 100%, ...

  • Page 12: Inverter Overview

    4 Inverter overview 4.1 Product description Figure shown here is for reference only. The actual product received may differ. Object Name Description DC switch Used to isolate the inverter from a DC input source. e.g. PV array Recessed grip Used to handle the inverter. Mounting flange Used to hang the inverter onto the mounting bracket.

  • Page 13: Dimensions

    4.2 Dimensions Unit：mm 4.3 LED indicator Function Description Green Solid ON The product operates normally and the PV array is available. SOLAR Green Blinking The product is self-checking automatically, or the firmware is being updated. Power from the PV array is not available. Green Solid ON The product operates normally and the battery energy is available.

  • Page 14: Supported Grid Types

    Ai-Dongle The product is equipped with an Ai-Dongle as standard, which it connects to the user interface of the Solplanet APP for configuring and monitoring the product. The Ai-Dongle can connect to the internet via WLAN or an ethernet cable. Solplanet communication products or a third-party monitoring device can be used if the Ai-Dongle is not connected.
  • Page 15 The product is delivered with current transformers and a smart meter as standard. Either the current transformers or the smart meter (not both simultaneously) can be used to measure the export active power. The smart meter that can be used with this product must be approved by Solplanet. For more information about the smart meter, please contact Solplanet service.
  • Page 16 This product complies with IEC 62109-2 clause 13.9 for earth fault alarm monitoring. If an earth fault alarm occurs, the red color LED indicator will light up. At the same time, the error code 38 will be sent to the Solplanet Cloud.

  • Page 17: Energy Management

    4.6 Energy Management The energy management mode selected should be based on the user’s application and preference. There are four energy management modes that can be chosen. Self-Consumption mode Self-consumption prioritises the supply of the load with PV and battery energy resulting in an increase of the self- consumption and self-sufficiency rates.
  • Page 18 Case 3: PV power generation is larger than the power consumption. Battery charging via PV energy is prioritised. PV energy is exported to the utility grid if it is greater than the load and when the battery is completely charged. Energy management during the night: Case 1: Battery energy is available.
  • Page 19 supplied by the utility grid. Case 2: Battery energy not available. The load power consumption will be supplied by the utility grid. Reserve mode The battery is considered as a back-up energy storage device. PV power prioritises the charging of the battery if it is not completely charged.
  • Page 20 Case 1: The battery is not completely charged. PV power will prioritise the charging of the battery. The balance of load power, if required, is supplied from the utility grid. Case 2: The battery is completely charged, the load power consumption is supplied by excess PV power and the balance, if required, is supplied by the utility grid.
  • Page 21 UM0063_ASW015-030K-TH_EN_V01_1224...
  • Page 22 Off-grid mode The product operates as a stand-alone inverter. Power is only supplied via the EPS port. No loads shall be connected to the normal AC output terminal. Custom mode Users can manage the system according to their own needs, and set daily regular charging and discharging schedules via the app. Outside of the schedules, the system operates in self-consumption mode.

  • Page 23: Basic System Solution

    4.7 Basic system solution The product is a high-quality inverter that converts solar energy to AC power and stores excess energy production in a battery. It optimizes self-consumption, enables energy storage for future use, and supports grid feed-in. The basic application of this product is as follows: Description Object Remark...
  • Page 24 The inverter and battery data is stored on the Solplanet cloud server. Smart Mobile Device The Solplanet app can be installed on a smart mobile device to view the PV plant information. The inverter and battery data can also be viewed via a computer which is logged into the Computer Solplanet cloud desktop web application.
  • Page 25 The system diagram of this product as follow: For Australia and New Zealand, the neutral cable of the On-grid side and EPS side must be connected together according to the wiring rules AS/NZS 3000, otherwise the EPS function will not work. UM0063_ASW015-030K-TH_EN_V01_1224...
  • Page 26 For other countries, the following diagram is an example for grid systems without special requirement on wiring connection. The wiring of smart meter: UM0063_ASW015-030K-TH_EN_V01_1224...
  • Page 27 The wiring of CT(Optional): Breaker No. ASW015K-TH ASW020K-TH ASW025K-TH ASW29.9K-TH ASW030K-TH 63 A/1000 V DC Breaker 63 A/1000 V DC Breaker 63 A/400 V AC 80 A/400 V AC 100 A/400 V AC Breaker Breaker Breaker Dependent on the normal loads which should be checked by an installer UM0063_ASW015-030K-TH_EN_V01_1224...

  • Page 28: Mounting

    5 Mounting 5.1 Requirements for mounting DANGER Danger to life due to fire or explosion！ Despite careful construction, electrical devices can cause fires. This can result in death or serious injury. Do not mount the product in areas containing highly flammable materials or gases. •...

  • Page 29: Taking Out And Moving The Product

    In case of multiple inverters, reserve the specific clearance requirements between the inverters.  Mount the product in a way that allows for easy recognition and reading of the LED signals.  The DC switch of the product must always be readily accessible. ...

  • Page 30: Mounting

    5.3 Mounting CAUTION Danger of personal injury due to falling inverter! If the hole depth and distance are not correct, the inverter may fall off the wall. Before inserting the bolts into the wall, measure the depth of the hole. ...
  • Page 31 Step 4： Lift and place the inverter onto the mounting-bracket and ensure that the mounting flanges perfectly align with the mounting bracket. Step 5： Secure the inverter by inserting screws into the threaded security hole. The inverter has an added anti-theft feature which allows the placement of anti-theft lock if required.

  • Page 32: Electrical Connection

    6 Electrical connection 6.1 Connection Interface Description ASW015-020K-TH (left) ASW025-030K-TH (right) Item Description DC-Switch B1/2 Battery Connector Port C1/2 PV Input Ai-Dongle Port Ventilation valve Port Communication Ports Diesel Generator Connector Port (Reserved) EPS Load Connector Port AC Connector Port Additional Grounding Screw 6.2 Connecting additional grounding The inverter is equipped with a residual current monitoring unit (RCMU).

  • Page 33: Grid Ac Connection

    Procedure: Step 1： Strip the grounding cable insulation. Insert the exposed section of the grounding cable into the ring terminal lug and crimp using a crimping tool. 1: Heat shrink tubing 2: OT/DT terminal (M5) Step 2 Remove the screw on the ground terminal, insert the screw through the OT/DT terminal, and tighten the screw onto the ：...
  • Page 34 Item Description Value External diameter 16…35 mm Copper cable conductor cross-section 16~50 mm² Insulation stripping length Meeting OT/DT terminal specification Sheath stripping length 130 mm Requirements for M8 OT/DT Terminal OT/DT terminals (not included in the delivery scope) are required for connecting AC cables to the terminal block. Purchase the OT/DT terminals according to the following requirements.

  • Page 35: Ac Cable Connection

    If you are uncertain about this, contact your grid operator or Solplanet. Safety in accordance with IEC 62109 when the grounding fault monitoring is deactivated.
  • Page 36 Step 3 Remove the cover of the AC connection terminal and select the appropriate sealing ring according to the diameter of the ： cable. Step 4 Feed the AC cable through the cable fittings. ： Step 5 Strip the insulation from the individual wires for L1 / L2 / L3 / N and PE (ground) so that the wire strands and insulation ：...
  • Page 37 Step 8：Loosen the nut marking the grounding point N,PE proceed to lay the round hole of the crimped terminal onto the stud of the corresponding terminal, the grounding point must be secured with the provided nut. Step 9： Gently pull on the cable backwards to ensure the connection is secure. Step 10：Insert the body into the machine end until it “clicks”, then tighten the nut with an open-end wrench.

  • Page 38: Eps Load / Diesel Generator Cable Connection

    NOTICE The AC connector at customer side has to be tightened and sealed properly regardless if there is no grid connection 6.4 EPS Load / Diesel Generator cable connection Step 1 Switch off the circuit breaker protecting the inverter circuit and and switch off and isolator all energy sources up stream ：...
  • Page 39 Step 4：Load/GEN cable requirements are as follows, stripped as shown. Step 5 Feed cable through cable glands, select the appropriate sealing ring according to the wire diameter. ： Step 6：LOAD/GEN cable requirements: strip as shown, crimp conductors to suitable bootlace ferrule (DIN 46228-4, customer- provided).

  • Page 40: Pv Dc Connection

    Complete the installation. NOTICE The EPS/Diesel generator connector has to be tightened and sealed properly regardless if there is no load or diesel generator connected. 6.5 PV DC Connection 6.5.1 Requirements for the DC connection Requirements for the PV modules per input: All PV modules in the same string and MPPT should be aligned and tilted identically.
  • Page 41 Assemble the DC connectors as described below. Be sure to observe the correct polarity. The DC connectors are marked with the symbols “+” and “-”. Cable requirements: Item Description Value Cable type PV cable External diameter 5-8 mm Conductor cross-section 2.5-6 mm²...
  • Page 42 If the stranded wire is not visible in the chamber, the cable is not correctly inserted and the connector must be reassembled. To do this, the cable must be removed from the connector. Release the wire clamp. To do so, insert a screwdriver (blade width: 3.5mm) into the wire clamp and pry the wire clamp open. Remove the cable and go back to step 2.
  • Page 43 Procedure: Step 1 Ensure that the DC switch is switched off and ensure that it cannot be inadvertenly switched on. ： Step 2 Ensure that there is no ground fault in the PV array. ： Step 3 Check whether the DC connectors have been installed with the correct polarities. ：...
  • Page 44 Insert the DC connectors with sealing plugs into the corresponding DC inputs on the inverter.  UM0063_ASW015-030K-TH_EN_V01_1224...

  • Page 45: Battery Connection

    Before connecting the battery, it is important to make sure that the battery is officially listed in the hybrid-battery compatibility list, please download the list from the website: https://solplanet.net. Assemble the battery connectors as described below. Be sure to observe the correct polarity. The Battery connectors are marked with the symbols “+”...
  • Page 46 Step 3 Insert the cable through cable gland, and insert into the housing until it snaps into place. Gently pull the cable ： backwards to ensure firm connection. Tighten the cable gland and the housing (Torque 4Nm). Step 4 Ensure that the cable is correctly positioned. ：...

  • Page 47: Ai-Dongle Connection With Lan Cable

    Complete the installation. 6.7 Ai-Dongle connection with LAN cable Procedure: Step 1 Rotate the sealing nut, remove the sealing ring, Press the clips on both sides of the Ai-dongle to open the casing (Note:try ： not to touch the PCBA component). Step 2 Connect the communication cable to the wiring terminal according to the sequence shown in the following figure.
  • Page 48 Step 4 Remove the cover of the Ai-Dongle port on the inverter and retain it . ： Step 5 Connect the Ai-Dongle to the Ai-Dongle port and secure it by tightening the locking nut. Ensure the Ai-Dongle is securely ： connected with the label clearly visible.

  • Page 49: Communication Equipment Connection

    NOTICE Rotating the body of the Ai-dongle will damage it! The Ai-dongle body is protected by a locking nut to protect the ensure a secure connection. If it is rotated, the Ai-dongle may become damaged. It can only be locked with the supplied nut. ...

  • Page 50: (Optional)

    Ripple Control Receiver Device DRMS Device CN405/CN408 DI*4/DRM0 6pin Com LOAD/0or DI_4 DI_3 DI_2 DI_1 REF GEN/0 North_485 CN414 4pin RS485A RS485B (Reserved) Current Transformer L1 Current Transformer L2 Current Transformer L3 CN406 6pin (Optional) Black Black Black CN411 ON/OFF 2pin CN413 Meter...

  • Page 51: Communication Cable Connection

    Device This product is equipped with external output function. This function can be connected Terminal-H/I External output to terminal block H/I. When the inverter is in “ON” status, it will provide 12 Vdc. Terminal-J AI-HUB_DI(Reserved) The terminal block J is a DI signal interface sent from the AI-HUB to the inverter. Terminal-L Multifunction Relay (Reserved) The product is equipped with two multifunction relays which are reserved.
  • Page 52 Step 3 Connect the communication cable to the corresponding communication port. ： Step 4 Install the communication cover on the inverter. ： Step 5 Tighten the cable gland nuts. ： UM0063_ASW015-030K-TH_EN_V01_1224...
  • Page 53 Complete the installation. 6.8.3 Ripple control receiver connection The product is equipped with two interfaces (terminal block A/E) to connect a Ripple Control Receiver device. Choose either one of the two interfaces. The Ripple control receiver device can be connected to terminal block A/E (pin1~pin4， pin6).
  • Page 54 information. Installation completed. 6.8.4 NS protection connection The product is equipped with two connections (terminal block G/K) for connection to an external central grid protection device. Choose either one of the two interfaces. Step 1 Remove the cable jacket and strip the wire insulation. ：...
  • Page 55 Installation completed. The Figure above is as reference and the manual of the third party device should be consulted, as also the manuals of other brands. 6.8.5 Smart meter connection The product is equipped with a RS485 interface (terminal block F, pin 1 and 2) which can be used to connect the supplied smart meter.
  • Page 56 Step 4 Strip the insulation of the other end of the cable and terminate the wire into the terminal according to the smart meter ： requirements. The specific smart meter connections are shown below: Installation completed. UM0063_ASW015-030K-TH_EN_V01_1224...

  • Page 57: Bms Connection

    6.8.6 BMS Connection Ensure that RJ45-  and RJ45- are connected correctly. If they are reversed, communication will not be possible. The inverter provides two CAN ports for connecting to the BMS of the battery: RJ45-  for connecting to the BMS of battery 1 and •...
  • Page 58 Step 1 Remove the cable jacket and strip the wire insulation. ： Step 2 Remove the terminals from the accessory pack, loosen the screws, and insert the wires. ： Step 3 Insert the push-in connector into the connection pane. ： The specific current transformers connections are shown below: Complete the installation.

  • Page 59: Commissioning And Operation

    Connect to the inverter via the Soplanet APP, For details, please refer to 8.4. Then set grid code, operation mode (refer to ： 4.7), meter or CT type, battery model and SOC limit refer to the latest Solplanet app manual. Step 3 Turn the breakers on EPS (if used) and grid port to "ON"...

  • Page 60: Solplanet App

    8.1 Download and install The corresponding, free Solplanet app can be downloaded from the relevant app store and installed on a mobile device (smartphone or tablet) with an Android operating system (version 9.0 or newer) or iOS operating system (version 11.0 or newer).

  • Page 61: Decommissioning The Product

    9 Decommissioning the product 9.1 Disconnecting the inverter from energy sources Prior to performing any work on the product, always disconnect it from all energy sources as described in this section. Always adhere to the prescribed sequence. WARNING Danger to life due to electric shock from destruction of the measuring device due to overvoltage！ Overvoltage can damage a measuring device and result in voltage being present in the enclo- sure of the measuring device.
  • Page 62 Step 6 Ensure that no voltage is present between the positive terminal and negative terminal at the DC inputs on the inverter side ： using a suitable measuring device. Step 7 Loosen and remove the AC connector. ： Unlock instructions 1.

  • Page 63: Dismantling The Inverter

    Step 10 Remove the communication cover. Remove the communication cable in reverse order by referring to 6.8 Communication ： equipment connection. Step 11 Hold down the buckle on the side of the Ai-Dongle and pull out the Ai-Dongle terminal. ： 9.2 Dismantling the inverter After disconnecting all electrical connections as described in Section 9.1, the inverter can be removed as follows: Procedure:...

  • Page 64: Technical Data

    10 Technical data 10.1 ASW015/020/025/29.9/030K-TH Type ASW015K-TH ASW020K-TH ASW025K-TH ASW29.9K-TH ASW030K-TH PV Port 50000 Wp 59800 Wp 60000 Wp Maximum power of PV array 30000 Wp 40000 Wp 1000 V Maximum input voltage Minimum input voltage 95 V Start voltage 180 V Rated input voltage 630 V...

  • Page 65: General Data

    Max. input power from grid 30000 W 40000 W 50000 W 50000 W 50000 W Max. input current from grid 43.5 A 58.0 A 72.5 A 72.5 A 72.5 A Contribution to peak short-circuit current Ip 130 A 130 A 150 A 150 A 150 A...

  • Page 66: Protective Device

    Operating temperature range -30 °C … +60 °C Allowable relative humidity range (non- 0 ... 100% condensing) Maximum operating altitude above mean sea 4000 m level Typical noise emission < 35 dB(A)@1 m < 55 dB(A)@1 m Self-consumption (night) < 10 W Topology Non-isolated Cooling method...

  • Page 67: Troubleshooting

    PE wire connection Ensure the grounding connection of the inverter is connected and reliable.  fault If this fault occurs often, contact Solplanet service. • External input signal If NS protection function is not needed, this function maybe enabled by mistake, disable ...
  • Page 68 G/K's PIN1&PIN2, if connection is right, use multimeter measure Terminal block G/K's PIN1&PIN2 power voltage should lie in range of 10-24Vd.c.. If this fault occurs often, contact Solplanet service.  Contact the service if you meet other problems or error codes not described in the table.

  • Page 69: Maintenance

    12 Maintenance 12.1 Cleaning the contacts of the DC switch DANGER High voltage of PV string may cause life danger！ If the DC connector is disconnected while the PV inverter is working, electric arc may occur, causing electric shock and burns.

  • Page 70: Recycling And Disposal

    When the customer needs warranty service during the warranty period, the customer must pro- vide a copy of the invoice, factory warranty card, and ensure the electrical label of the inverter is legible. If these conditions are not met, Solplanet has the right to refuse to provide with the relevant warranty service.

  • Page 71: Contact

    16 Contact EMEA Service email: service.EMEA@solplanet.net APAC Service email: service.APAC@solplanet.net LATAM Service email: service.LATAM@solplanet.net AISWEI Technology Co., Ltd. Hotline: +86 400 801 9996 Add.: No. 18, Alley 600, Nanchezhan Road, Huangpu District, Shanghai, China https://solplanet.net/contact-us/ UM0063_ASW015-030K-TH_EN_V01_1224...
  • Page 72 UM0063_ASW015-030K-TH_EN_V01_1224...

This manual is also suitable for:

Asw015k-thAsw020k-thAsw025k-thAsw29.9k-thAsw030k-th
