TPR1000 and TPR4000

Active Power Rail Probes

User Manual

Click the following link to protect your product.

tek.com/register

*P077154201*

077-1542-01

April 2025

Table of Contents

Need help?

Do you have a question about the TPR1000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Tektronix TPR1000

Page 1 TPR1000 and TPR4000 Active Power Rail Probes User Manual Register now! Click the following link to protect your product. tek.com/register *P077154201* 077-1542-01 April 2025...
Page 2 Copyright © 2025, Tektronix. 2025 All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries or suppliers, and are protected by national copyright laws and international treaty provisions. Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supersedes that in all previously published material. Specifications and price change privileges reserved.
Page 3: Table Of Contents
Optional solder-in flex-paddle tip accessory kit......................26 Specifications....................................27 Warranted characteristics..............................27 Typical characteristics................................28 Nominal characteristics................................30 Accessory characteristics..............................31 Performance verification................................35 Equipment setup.................................. 36 Test record................................... 38 Check the DC gain accuracy............................... 39 TPR1000 and TPR4000 Active Power Rail Probes User Manual...
Page 4 Contents Check the DC input dynamic range............................. 40 Check the input offset range and scale accuracy........................ 41 Check the analog bandwidth..............................42 Maintenance....................................43 Cleaning....................................43 Returning instrument for service............................43...
Page 5: Important Safety Information
Do not connect a current probe to any wire that carries voltages above the current probe voltage rating. Do not operate without covers Do not operate this product with covers or panels removed, or with the case open. Hazardous voltage exposure is possible. TPR1000 and TPR4000 Active Power Rail Probes User Manual...
Page 6 Important safety information Avoid exposed circuitry Do not touch exposed connections and components when power is present. Do not operate with suspected failures If you suspect that there is damage to this product, have it inspected by qualified service personnel. Disable the product if it is damaged.
Page 7: Probes And Test Leads
Therefore the probe wire may not provide adequate protection. WARNING: To avoid electric shock, do not use the probe if the wear indicator on the cable becomes visible. Contact Tektronix at tek.com...
Page 8: Terms In This Manual And On The Product
Service the probe and accessories Go to tek.com/support to find information on contacting Tektronix Service Support. Terms in this manual and on the product These terms may appear in this manual: WARNING: Warning statements identify conditions or practices that could result in injury or loss of life.
Page 9: Compliance Information
To avoid release of such substances into the environment and to reduce the use of TPR1000 and TPR4000 Active Power Rail Probes User Manual...
Page 10 This symbol indicates that this product complies with the applicable European Union requirements according to Directives 2012/19/EU and 2006/66/EC on waste electrical and electronic equipment (WEEE) and batteries. For information about recycling options, check the Tektronix Web site (www.tek.com/productrecycling).
Page 11: Preface
Access this document and other related information from the tek.com. The TPR1000 and TPR4000 probes provide a low noise, large offset range solution for measurement of ripple on DC power rails ranging from –60 to +60 VDC. Tektronix’s power rail probes offer industry leading low noise and high offset range required to measure AC ripple between 200 μV...
Page 12: Operating Information
The block diagram shows the major circuit blocks or modules in the TPR1000 and TPR4000 probes. The TPR1000 and TPR4000 function by extending the oscilloscopes offset capability while maintaining a low noise signal path into the instrument. The linear dynamic range can be moved around the offset voltage operating window using the DC offset control into the LF amplifier.
Page 13: Connecting To The Instrument
Operating information Connecting to the instrument The following steps describe the process for connecting the TPR1000 and TPR4000 probes. Procedure 1. Slide the probe body into the FlexChannel or VPI receptacle. The probe clicks into place when fully engaged. When the probe is connected, the instrument reads information from the probe and identifies the device.
Page 14: Menu Button
Tektronix for repair. Note: The TPR1000 and TPR4000 power rail probes are designed to work with all TekVPI-interface oscilloscopes and adapters. However, there may be some cases where all of the probe features may not work properly.
Page 15: Autozero
MSO, 5 Series MSO, 6 Series MSO SMA cable 1.3 m cable, SMA male-to-SMA male, 50 Ω Cable included in standard accessory kit (TPR4KIT) Sine wave generator Frequency: 10 Mhz Amplitude: 1 Vpp, Offset 1 Vpp TPR1000 and TPR4000 Active Power Rail Probes User Manual...
Page 16: Required Instrument Software Versions
Operating information Procedure 1. Connect the probe to the oscilloscope and a function generator as detailed in the connection diagram. 2. If the function generator allows load impedance scaling, set the load impedance to high-Z. Otherwise, place a 50 Ω feed through terminator between the SMA cable and the probe. 3.
Page 17: Probe Compatibility
2 mV/division. For all other vertical scale settings, the specified accuracy of the probe is maintained. To take accurate measurements when using a TPR1000 or TPR4000 probe with the oscilloscope models below, it is recommended to use vertical scale settings greater than 2 mV/division.
Page 18: Probe Offset
Operating information Figure 1: Dynamic and offset limitations Probe offset Use the following instructions for setting the probe offset. Before you begin See your oscilloscope user manual for specific instructions on using the offset control. About this task The probe offset is adjustable for operation within the linear range of the probe, and to increase the sensitivity of the probe at higher DC measurement voltages.
Page 19: Connect Mmcx Accessories
To attach the solder flex tip, first solder the enameled self-fluxing copper wire (standard accessory) to the test point. Feed the wire through the vias on the end of the flex tip, and then apply a small amount of solder to the vias to attach the wire to the tip. TPR1000 and TPR4000 Active Power Rail Probes User Manual...
Page 20: Using The Solder-Pin Installation Tool
Operating information Using the solder-pin installation tool The following describes how to install the solder pins using the supplied soldering-aide tool. Before you begin The supplied set of solder pins are intended to be installed on DUT circuit boards and used with the supplied MMCX to square-pin adapter. The solder pins are extremely small and can be challenging to handle.
Page 21: Using The Optional Browser
Connecting the Y-lead adapter and micro-SMD clip The browser kit includes a Y-lead adapter and a micro-SMD clip that connect as shown below. The Y-lead adapter can also connect to square pins. TPR1000 and TPR4000 Active Power Rail Probes User Manual...
Page 22: Ground Lead Length
Operating information Replacing browser-tip pins To remove the browser-tip pin, use pliers to grasp the pin and gently pull it out of the tip housing. To install a new browser-tip pin, select between a solid (silver colored) or spring-loaded (gold colored) pin, and then use pliers to gently insert the pin into the browser-tip housing until you feel the pin press against the bottom of the housing.
Page 23: Ground Lead Inductance
Each probe is shipped with one TPR4KIT accessory kit containing the following items. Item Image 1.3 m cable, SMA male-to-MMCX male, 50 Ω 1.3 m cable, SMA male-to-SMA male, 50 Ω Table continued… TPR1000 and TPR4000 Active Power Rail Probes User Manual...
Page 24 Operating information Item Image Y-lead adapter, MMCX female-to-0.8 mm sockets Adapter cable, MMCX female-to-U.FL female, 50 Ω Adapter, MMCX female-to-square pin (0.062 centers) DUT interface solder pins, set of 20 Soldering aide tool, 0.062 solder pins over SMT Solder-in cable adapter, MMCX female-to-solder micro-coax tip, 50 Ω, set of 3 Solder-in cable adapter, MMCX female-to-solder flex-paddle tip, 50 Ω, set of 3 Wire card, solderable enameled self-fluxing copper wire (for use with the solder-in tips) Probe tip tripod support (with living hinge)
Page 25: Optional High-Temperature Accessory Kit
The optional TPRBRWSR1G accessory kit contains the following items. Item Image Browser Ground leads (blade, 0.5 mm spring, 15 cm alligator) Y-lead adapter, browser tip-to-0.8 mm sockets Micro-SMD clip Table continued… TPR1000 and TPR4000 Active Power Rail Probes User Manual...
Page 26: Optional Solder-In Micro-Coax Tip Accessory Kit
Operating information Item Image Replacement 0.5 mm browser tips (2 solid tips, 2 spring tips) Optional solder-in micro-coax tip accessory kit The optional TPR4SIACOAX accessory kit contains the following items. Item Image Solder-in cable adapter, MMCX female-to-solder micro-coax tip, 50 Ω, set of 3 Optional solder-in flex-paddle tip accessory kit The optional TPR4SIAFLEX accessory kit contains the following items.
Page 27: Specifications
Specifications Specifications The specifications apply to both the TPR1000 and TPR4000 probes unless noted otherwise. The specifications are valid under the following conditions: • The probe has been calibrated at an ambient temperature of 23 °C ±5 °C. • The probe is connected to a host instrument with an input impedance of 50 Ω.
Page 28: Typical Characteristics
Description DC input resistance 50 kΩ Return loss (50 Ω reference impedance) Maximum: -12 dB between 10 MHz and 1 GHz (TPR1000) Maximum: -12 dB between 10 MHz and 4 GHz (TPR4000) DC to AC impedance crossover frequency 300 Hz DC to AC gain matching ±1%...
Page 29 Specifications Figure 2: TPR1000 frequency response Figure 3: TPR4000 frequency response Figure 4: TPR1000 and TPR4000 input impedance versus frequency Table 3: Mechanical characteristics Characteristic Description Dimensions (compensation box) 85.1 mm × 40.6 mm × 30.5 mm (3.4 in × 1.6 in × 1.2 in) Table continued…...
Page 30: Nominal Characteristics
Specifications Characteristic Description Packaged weight 1.24 kg (2.7 lbs) Nominal characteristics Nominal characteristics describe guaranteed traits, but the traits do not have tolerance limits. Characteristic Description Compatibility Oscilloscopes equipped with the TekVPI interface Instrument coupling DC, LF-Reject Input offset requestable range ±60 V Non-destructive input voltage range (AC 2.5 VRMS, with peaks ≤±20 V (DF 6.25%)
Page 31: Accessory Characteristics
Specifications Accessory characteristics Specifications for the TPR1000 and TPR4000 accessories are either warranted and typical characteristics. Table 4: Electrical characteristics Characteristic Description TPR4SIAFLEX and TPRSIACOAX (typical) 1 GHz (TPR1000) >3.5 GHz (TPR4000) SMA to SMA cable (warranted) 1 GHz (TPR1000) 4 GHz (TPR4000) MMCX to U.FL adapter (typical)
Page 32 Specifications Item number Dimensions Browser Spring Ground Browser Blade Ground Browser Alligator Ground TPRSIACOAX TPRSIAFLEX MMCX to U.FL adapter Table continued…...
Page 33 Specifications Item number Dimensions 1.3 m SMA to MMCX Cable 1.3 m SMA to SMA Cable 2 m SMA to MMCX Cable Browser to Square-pin adapter Table continued… TPR1000 and TPR4000 Active Power Rail Probes User Manual...
Page 34 Specifications Item number Dimensions MMCX to Square-pin adapter SMT Component Clip...
Page 35: Performance Verification
The procedures that follow verify the warranted specifications of the probe. The recommended calibration interval is one year. Perform the verification procedures in the order listed. The following equipment is required for the performance verification procedures. The nine-digit part numbers (xxx-xxxx-xx) are Tektronix part numbers.
Page 36: Equipment Setup
Performance verification Equipment setup Use the following procedures to set up and warm up the equipment to test the probe. Use the DC setup diagram for the following performance checks. • DC gain accuracy • DC input dynamic range • Input offset range and scale accuracy Figure 5: DC setup connection diagram Use the analyzer setup diagram for the analog bandwidth performance check.
Page 37 3. Connect the probe to the TekVPI Calibration Verification adapter and verify that the Status LED on the probe turns green. 4. Turn on the remaining test equipment. 5. Allow 20 minutes for the equipment to warm up. 6. Use the test record template to record the test results. TPR1000 and TPR4000 Active Power Rail Probes User Manual...
Page 38: Test Record
Input offset range and scale +12 V offset -194 mV 194 mV accuracy +1 V offset -18 mV 18 mV –1 V offset -194 mV 194 mV –12 V offset -18 mV 18 mV Analog bandwidth TPR1000 -3 dB TPR4000 -3 dB...
Page 39: Check The Dc Gain Accuracy
Vout (linear fit) –2 –640 mV –513 mV –512 mV –1 –320 mV –256 mV –256 mV 0 mV 0.0009 mV 0 mV 320 mV 258 mV 256 mV Table continued… TPR1000 and TPR4000 Active Power Rail Probes User Manual...
Page 40: Check The Dc Input Dynamic Range
Performance verification Index DC source voltage Vout (measured) Vout (linear fit) 640 mV 515 mV 512 mV Figure 7: Example plot of measured values The gain slope can either be obtained by using a spreadsheet to calculate the linear regression of the points, or graphically by hand. To obtain the gain slope graphically, carefully plot each measurement point on a rectangular coordinate system, the X axis is the DC source voltage and the Y axis is the measured DC output value.
Page 41: Check The Input Offset Range And Scale Accuracy
Probe vertical offset setting +12 V +12 V +1 V +1 V –1 V –1 V –12 V –12 V 8. Record the result of each setting in the test record. TPR1000 and TPR4000 Active Power Rail Probes User Manual...
Page 42: Check The Analog Bandwidth
4. Place a marker on the S21 trace at the start frequency (300 kHz). 5. Place a marker on the S21 trace at the probe bandwidth (1 GHz for TPR1000 or 4 GHz for TPR4000). 6. Verify that the amplitude is greater than -3.97 dB (subtracting the 0.97 dB of probe attenuation range from the 3.97 dB target value yields the 3 dB limit).
Page 43: Maintenance
If you want to see the warranty or service agreements on your products, or if you want to create your own service price estimate, visit our quick service quote site at tek.com/service-quote. TPR1000 and TPR4000 Active Power Rail Probes User Manual...
