Release date: 22.02.2025
COMPOSIZIONE KIT - KIT COMPOSITION
A
A
MEDIADAB HD
B
CABLAGGIO - CABLE
F
MANUALE - MANUAL
CARATTERISTICHE
Ricevitore DAB/DAB+.
Menu utente visualizzato sul display della radio tramite RDS.
Ges!one tramite comandi a volante canbus resis!vi GMLAN o teleco-
mando (opzionale) .
Modulazione stereo FM su 8 frequenze selezionabili.
Sintesi vocale.
INSTALLAZIONE
L'installazione si ar!cola in una serie di sessioni.
Rimozione dell'autoradio.
Collegamen! cavi modulo.
Collegare i cavi di alimentazione e se il veicolo è provvisto di
comandi a volante collegare in serie i fili dei comandi a volante
secondo la compa!bilità di protocollo (QR CODE).
QR Code
MEDIADAB
SESSIONE 1
SESSIONE 2
CANBUS
RESISTIVO
GMLAN
B
Receiver DAB / DAB +.
User menu displayed on the radio display via RDS.
Management by remote control (op!onal) or steering wheel com-
mands.
FM stereo modula!on on 8 selectable frequencies.
Speech synthesis.
The installa!on consists in a series of sessions.
Car radio removal.
Module wire connec!ons.
Connect the power cables and if the vehicle is equipped with
steering wheel controls, connect the steering wheel control
wires in series according to protocol compa!bility (QR CODE).
1 / 8
CODICE - CODE:
1 H
CF0059UNDBXX
C
FEATURES
INSTALLATION
SESSION 1
SESSION 2
GND
12/24 VDC
SOTTOCHIAVE
POWER
ANTENNA OUTPUT
rev. 1.0 25

Advertisement

loading
Need help?

Need help?

Do you have a question about the MEDIADAB and is the answer not in the manual?

Questions and answers

Related Manuals for Paser MEDIADAB

Summary of Contents for Paser MEDIADAB

  • Page 1 Release date: 22.02.2025 rev. 1.0 25 CODICE - CODE: MEDIADAB CF0059UNDBXX COMPOSIZIONE KIT - KIT COMPOSITION MEDIADAB HD CABLAGGIO - CABLE MANUALE - MANUAL CARATTERISTICHE FEATURES Ricevitore DAB/DAB+. Receiver DAB / DAB +. Menu utente visualizzato sul display della radio tramite RDS.
  • Page 2 Release date: 22.02.2025 rev. 1.0 25 CODICE - CODE: MEDIADAB CF0059UNDBXX INSTALLAZIONE INSTALLATION SESSIONE 2a SESSION 2a Connessione cavi comandi a volante. Steering wheel control cable connec!on. In base al protocollo, collegare i cavi in serie. According to the protocol, connect the cables in series.
  • Page 3 Release date: 22.02.2025 rev. 1.0 25 CODICE - CODE: MEDIADAB CF0059UNDBXX INSTALLAZIONE INSTALLATION SESSIONE 3 SESSION 3 Connessione adaBatori FAKRA. FAKRA adapters connec!on. COLLEGARE A CONNETTORE ANTENNA VETTURA RADIO PLEASE CONNECT TO THE CAR ANTENNA CONNECTOR COLLEGARE A CONNETTORE ANTENNA RADIO...
  • Page 4 In case of malfunc@on of the steering wheel controls or if In caso di anomalia di funzionamento dei comandi al volante you move to a new vehicle, reset MediaDAB HD by pressing o di spostamento su una nuova ve<ura, eseguire un reset di the bu<on on the module un@l the LED turns off.
  • Page 5 MEDIADAB CF0059UNDBXX CONTROLLO COMANDI A VOLANTE STEERING WHEEL COMMANDS CONTROL MediaDAB HD può essere controllato dai comandi al volante MediaDAB HD can be controlled by steering wheel controls (secondo le compa!bilità). (depending on compa!bility). La presenza di più o meno tas! sul volante determina due The presence of more or less buBons on the steering wheel differen! modalità...
  • Page 6 Release date: 22.02.2025 rev. 1.0 25 CODICE - CODE: MEDIADAB CF0059UNDBXX CONFIGURAZIONE 2 CONFIGURATION 2 Pressione Breve Short Pressure Pressione Prolungata Long Pressure FUNZIONE FUNCTION TASTI CON PRESSIONE BUTTONS WITH SHORT TASTI CON PRESSIONE BUTTONS WITH LONG BREVE PRESSURE PROLUNGATA...
  • Page 7 Release date: 22.02.2025 rev. 1.0 25 CODICE - CODE: MEDIADAB CF0059UNDBXX MAIN MENU SUB-MENU 1 SUB-MENU 2 SUB-MENU 3 (OFF) CHANNELS LIST CHANNEL LIST BACK EXIT FAVORITES LIST FAVOURITE LIST BACK EXIT ADD/REM FAV CLEAR FAVOURITES MANAGEMENT SCAN BACK EXIT...

  • Page 8: Troubleshooting

    The informa!on in this guide are purely for informa!on purposes, therefore, are subject to change without no!ce. At the !me of publica!on the informa!on is correct and reliable. However Paser can not be held responsible for any consequences resul!ng from errors or omissions in this manual.
