- Page 1 User Guide 8GE (PoE) +2SFP Web Smart PoE Switch This document applies to the 8GE (PoE)+2SFP Web Smart PoE Switch. The 8GE (PoE)+2SFP is used as an example in the product figure unless otherwise specified...
-
Page 2: Packing List
Packing List When using the Switch for the first time, carefully open the packing box. The packing box should contain the following items: Switch *1 User manual *1 Power cord *1 Rack Mount Kit *2 Screw *8 ... -
Page 3: Chapter 2 Product Appearance Description
Chapter 2 Product Appearance Description 2.1 Front Panel The front panel consists of 8*10/100/1000Mbps adaptive RJ45 ports and 2*1000Mbps SFP slots and related indicators, as shown in the following figure: Figure 2-1 Front panel diagram Port description: 10/100/1000Mbps RJ45 Ports Supports 10Mbps, 100Mbps, or 1000Mbps rate adaptation, auto- Ｍ... -
Page 4: Rear Panel
Function Color Off: No Power supply. Green Light: Indicates the switch has power. Off: No device is connected to the corresponding port. Light: Indicates the link through that port is successfully DATA Green established at 10/100/1000Mbps. Blink: Indicates that the Switch is actively sending or receiving data over that port. -
Page 5: Chapter ３ Installation Guide
Chapter ３ Installation Guide This chapter helps users correctly install and safely use Switches. 3.1 Installation Precautions Precautions: To avoid equipment damage and personal injury, observe the following precautions: The Switch room should be dry and ventilated, free from corrosive gases and strong electromagnetic ... -
Page 6: Installation
installation type, such as screws, nuts, and tools, to ensure reliable installation. Environment requirements: The operating temperature ranges from 0°C to 40°C and the relative humidity ranges from 5% to 90%. ３.3 Installation Desktop installation Place the bottom of the Switch face up on a large enough stable desktop; ... -
Page 7: Enabling The Switch
Figure 3-2 Diagram 1 of rack installation Figure 3-3 Diagram 2 of rack installation 3.4 Enabling the Switch Connect the power cord, plug in, and turn on the power. After the Switch is started, the Switch automatically initializes. If all port indicators are on and off, the system is successfully reset. The power LED indicator is steady on. -
Page 8: Appendix: Technical Specifications
Appendix: Technical Specifications Model 8GE(PoE)+2SFP Web Smart PoE Switch IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, Standard IEEE 802.1x, IEEE 802.1q, IEEE 802.1p, IEEE802.3af, IEEE802.3at 10BASE-T: UTP category 3,4,5 cable（≤100m） Network Media(Cable) 100BASE-TX: UTP category 5, 5e cable（≤100m） 1000BASE-T: UTP category 5e, 5 cable（≤100m）...
