- Page 1 UPER SC811 CHASSIS Series SC811TQ-520 SC811TQ-280 SC811S-520 SC811S-280 SC811i-520 SC811i-280 USER’S MANUAL...
- Page 2 Clara County in the State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
- Page 3 Preface Preface About This Manual This manual is written for professional system integrators and PC technicians. It provides information for the installation and use of the SC811 1U chassis. Installa- tion and maintenance should be performed by experienced technicians only. This document lists compatible parts available when this document was published.
- Page 4 SC811 Chassis Manual Notes...
-
Page 5: Manual Organization
Preface Manual Organization Chapter 1: Introduction The fi rst chapter provides a checklist of the main components included with this chassis and describes the main features of the SC811 chassis. This chapter also includes contact information. Chapter 2: System Safety This chapter lists warnings, precautions, and system safety. - Page 6 SC811 Chassis Manual Notes...
-
Page 7: Table Of Contents
Manual Organization ...................v Chapter 1 Introduction Overview ......................1-1 Shipping List ....................1-1 Part Numbers ..................... 1-1 Contacting SuperMicro ..................1-2 Where to get Replacement Components ............1-3 Chapter 2 System Safety Overview ......................1 Warnings and Precautions ................. 1 Preparing for Setup .................... - Page 8 SC811 Chassis Manual To install an add-on card: ................4-7 Installation Step 4: Installing the Air Shroud ........... 4-8 To install the air shroud ................4-8 To check the server's air fl ow ..............4-8 Installation Complete ..................4-8 System Blowers ....................4-9 To change a system blower ...............
- Page 9 Preface Appendices Appendix A Cables, Screws, and Other Accessories Overview ......................A-1 Cables Included with SC811TQ Chassis (SAS/SATA) ........A-1 Cables Included with SC811S Chassis (SCSI) ..........A-1 Compatible Cables ..................A-2 Alternate SAS/SATA Cables ................A-2 Extending Power Cables .................A-3 Front Panel to the Motherboard ..............A-3 Chassis Screws ....................A-4 Appendix B SC811 Power Supply Specifi...
- Page 10 SC811 Chassis Manual Notes...
-
Page 11: Chapter 1 Introduction
Chapter 1: Introduction Chapter 1 Introduction Overview Supermicro’s SC811 1U chassis features a unique and highly-optimized design. The chassis is equipped with high effi ciency power supply in a 1U form factor. Shipping List Part Numbers Please visit the following link for the latest shipping lists and part numbers for your particular chassis model http://www.supermicro.com/products/chassis/1U/... -
Page 12: Contacting Supermicro
SC811 Chassis Manual Contacting SuperMicro Headquarters Address: SuperMicro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: SuperMicro Computer B.V. -
Page 13: Where To Get Replacement Components
Supermicro Authorized Distributors / System Integrators / Resellers. A list of Supermicro Authorized Distributors / Sys- tem Integrators /Reseller can be found at: http://www.supermicro.com. Click the... - Page 14 SC811 Chassis Manual Notes...
-
Page 15: Chapter 2 System Safety
Chapter 2: System Safety Chapter 2 System Safety Overview This chapter provides a quick setup checklist to get your chassis up and running. Following the steps in order given should enable you to have your chassis setup and operational within a minimal amount of time. This quick set up assumes that you are an experienced technician, familiar with common concepts and terminology. -
Page 16: Electrical Safety Precautions
SC811 Chassis Manual Electrical Safety Precautions Basic electrical safety precautions should be followed to protect yourself from harm and the SC811 from damage: Be aware of the locations of the power on/off switch on the chassis as well as the room’s emergency power-off switch, disconnection switch or electri- cal outlet. -
Page 17: General Safety Precautions
Chapter 2: System Safety DVD-ROM Laser: CAUTION - this server may have come equipped with a DVD-ROM drive. To prevent direct exposure to the laser beam and hazard- ous radiation exposure, do not open the enclosure or use the unit in any unconventional way. - Page 18 SC811 Chassis Manual Touch a grounded metal object before removing any board from its anti- static bag. Do not let components or PCBs come into contact with your clothing, which may retain a charge even if you are wearing a wrist strap. Handle a board by its edges only;...
-
Page 19: Chapter 3 System Interface
Chapter 3: System Interface Chapter 3 System Interface Overview There are several LEDs on the control panel as well as others on the drive carri- ers to keep you constantly informed of the overall status of the system as well as the activity and health of specifi... -
Page 20: Control Panel Buttons
SC811 Chassis Manual Control Panel Buttons There are two push-buttons located on the front of the chassis. These are (in order from left to right) a reset button and a power on/off button. Reset: The reset button is used to reboot the system. Power: The main power switch is used to apply or remove power from the power supply to the server system. -
Page 21: Drive Carrier Leds
Chapter 3: System Interface NIC2: Indicates network activity on GLAN2 when fl ashing. NIC1: Indicates network activity on GLAN1 when fl ashing. HDD: Indicates IDE channel activity. SAS/SATA drive, SCSI drive, and/or DVD-ROM drive activity when fl ashing. Power: Indicates power is being supplied to the system's power supply units. -
Page 22: Scsi Drives
SC811 Chassis Manual connection to the SATA backplane enables this LED to blink on and off when that particular drive is being accessed. Red: The red LED to indicate an SAS/SATA drive failure. If one of the SAS/ SATA drives fail, you should be notifi ed by your system management software. SCSI Drives Each SCSI drive carrier has two LEDs. -
Page 23: Chapter 4 Chassis Setup And Maintenance
Chapter 4: Chassis Setup and Maintenance Chapter 4 Chassis Setup and Maintenance Overview This chapter covers the steps required to install components and perform maintenance on the chassis. The only tool you will need to install components and perform maintenance is a Phillips screwdriver. Print this page to use as a reference while setting up your chassis. -
Page 24: Installation Step 1: Remove The Chassis Cover
SC811 Chassis Manual Installation Step 1: Remove the Chassis Cover Release Button Figure 4-1: Removing the Chassis Cover To remove the chassis cover: 1. Press the Release Buttons to remove the cover from the locked position. Press both buttons at the same time. 2. -
Page 25: Installation Step 2: Install Hard Drives
Chapter 4: Chassis Setup and Maintenance Installation Step 2: Install Hard Drives Figure 4-2: Removing Hard Drive To remove hard drive trays from the chassis 1. Press the release button on the drive tray. This extends the drive bay handle. 2. -
Page 26: To Install A Hard Drive To The Hard Drive Tray
SC811 Chassis Manual SAS/SATA or SCSI Hard Drive Drive Tray Move the handle into the UP position to lock the drive into the chassis Figure 4-3: Removing the Chassis Cover To install a hard drive to the hard drive tray 1. -
Page 27: Installation Step 3: Installing The Motherboard
Chapter 4: Chassis Setup and Maintenance Installation Step 3: Installing the Motherboard Remove this screw Riser Card Bracket Remove this screw Figure 4-4: Remove the riser card bracket To install the motherboard: 1. Review the documentation that came with your motherboard. Become familiar with component placement, requirements, precautions, and cable connections. - Page 28 SC811 Chassis Manual Figure 4-5: Mylar Sheet and Motherboard Installation 5. Locate the mylar sheet in the accessories package and place the sheet into the chassis. 6. Carefully place the motherboard in the chassis. You must align the I/O shield with the motherboard ports.
-
Page 29: Add-On Card/Expansion Slot Setup
Chapter 4: Chassis Setup and Maintenance Add-on Card/Expansion Slot Setup SC811 chassis includes a slot for one full length / full height add-on card slot. Insert the Add-on Card here Riser Card Bracket Figure 4-6: Add-on Card Installation To install an add-on card: 1. -
Page 30: Installation Step 4: Installing The Air Shroud
SC811 Chassis Manual Installation Step 4: Installing the Air Shroud Air shrouds concentrate airfl ow to maximize fan effi ciency. The SC811 chassis air shroud does not require screws to set up. To install the air shroud 1. Remove the mylar air shroud from the accessories box. 2. -
Page 31: System Blowers
Chapter 4: Chassis Setup and Maintenance System Blowers Two heavy duty blowers provide cooling for the chassis. These fans circulate air through the chassis as a means of lowering the chassis internal temperature. Blower Posts Figure 4-7: System Blowers To change a system blower 1. -
Page 32: Power Supply
SC811 Chassis Manual Power Supply Depending on the model the SC811 chassis has high-effi ciency power supply that is auto-switching capable. This enables it to automatically sense and operate at a 100v to 240v input voltage. An amber light will be illuminated on the power supply when the power is off. - Page 33 Chapter 4: Chassis Setup and Maintenance 3. Disconnect all cables connecting the power supply to the motherboard and other components. 4. Remove the three screws securing the power supply. Two screws are ac- cessed from the rear of the chassis. The other is located in the front of the power supply.
-
Page 34: Other Chassis Components
SC811 Chassis Manual Other Chassis Components To change the DVD 1. Power down and unplug the system from the outlet. 2. Remove the chassis cover. 3. Disconnect the power and data cables from the drive to other chassis components including the motherboard and backplane. 4. -
Page 35: Chapter 5 Rack Installation
Chapter 5: Rack Installation Chapter 5 Rack Installation Overview This chapter provides simple instructions for installing this chassis into a rack. Unpacking the System You should inspect the box the chassis was shipped in and note if it was damaged in any way. -
Page 36: Rack Precautions
SC811 Chassis Manual Warnings and Precautions Rack Precautions - Ensure that the leveling jacks on the bottom of the rack are fully extended to the fl oor with the full weight of the rack resting on them. - In single rack installation, stabilizers should be attached to the rack. - In multiple rack installations, the racks should be coupled together. -
Page 37: Reduced Airfl Ow
Chapter 5: Rack Installation Reduced Airfl ow Equipment should be mounted into a rack so that the amount of airfl ow required for safe operation is not compromised. Mechanical Loading Equipment should be mounted into a rack so that a hazardous condition does not arise due to uneven mechanical loading. -
Page 38: Rack Mounting Instructions
SC811 Chassis Manual Rack Mounting Instructions This section provides information on installing the SC812L chassis into a rack unit with the rails provided. There are a variety of rack units on the market, which may mean the assembly procedure will differ slightly. You should also refer to the instal- lation instructions that came with the rack unit you are using. -
Page 39: To Separate The Inner And Outer Rails
Chapter 5: Rack Installation Figure 5-1: Inner and Outer Rails To separate the inner and outer rails: 1. Pull the inner rail (A) from the outer rail (B) as far as possible. 2. Depress the locking tab (C) to pull the inner rail completely out. 3. -
Page 40: To Install The Outer Rails To The Rack
SC811 Chassis Manual Outer Rails Rail Brackets Figure 5-3. Rack Brackets To install the outer rails to the rack: 1. Confi rm that the inner rails have been separated from the outer rails. 2. Locate the rail brackets in the accessories box. The chassis package includes four rail brackets and two chassis mounts. - Page 41 Chapter 5: Rack Installation Rail Bracket Figure 5-4: Mounting the Chassis...
-
Page 42: To Install The Chassis Into A Rack
SC811 Chassis Manual To install the chassis into a rack: 1. Confi rm that the chassis includes the inner rails (A) and that the outer rails (B) are installed on the rack (See Figure 5-3) 2. Align the chassis rails (A) with the front of the rack rails (C). 3. -
Page 43: Telco (Two Post) Racks
Chapter 5: Rack Installation Telco (Two Post) Racks Telco racks utilize two posts instead of four. Because of this, telco racks require a different installation process. Outer Rails Chassis Mounts Rail Brackets Figure 5-5: Installing the Server into a Telco Rack To install the chassis into a Telco rack: This chassis requires both the inner and outer rails for Telco rack installation. - Page 44 SC811 Chassis Manual Figure 5-6: Installing the Server into a Telco Rack 5. Place one outer rail in the Telco rack as illustrated. 6. Slide the brackets until each snugly fi ts against the Telco rack post. 7. Secure the brackets to the Telco rack with two M5 screws for each bracket. 8.
- Page 45 Chapter 5: Rack Installation 12. (Optional) If you installed the front chassis mount, you can insert thumb- screws through the chassis ears and chassis mounts. The chassis cannot be pulled from the rack unless the thumbscrews are removed. 5-11...
- Page 46 SC811 Chassis Manual Notes 5-12...
-
Page 47: Appendices
Appendices Appendices Appendix A: Compatible Cables Appendix B: SC810 Power Supply Specifi cations Appendix C: SAS 810TQ Backplane Manual Appendix D: SCA 810S Backplane Manual... - Page 48 Appendices Notes...
-
Page 49: Appendix A Cables, Screws, And Other Accessories
Cord 6 feet Regional power cord CBL-0157L Cable Various 8-pin to 8-pin cable for SGPIO Note: Items may change without notice. Refer to http://www.supermicro.com for the latest information. A-3 Cables Included with SC811S Chassis (SCSI) SC811S Part # Type Length... -
Page 50: A-4 Compatible Cables
Chassis Manual A-4 Compatible Cables These cables are compatible with the SC811 chassis. Alternate SAS/SATA Cables Some compatible motherboards have different connectors. If your motherboard has only one SAS connector that the SAS/SATA cables must share, use one of the following cables. -
Page 51: Extending Power Cables
Appendix A: Chassis Cables Extending Power Cables Although Super Micro chassis are designed with to be effi cient and cost-effective, some compatible motherboards have power connectors located in different areas. To use these motherboards you may have to extend the power cables to the mother boards. -
Page 52: A-5 Chassis Screws
Chassis Manual A-5 Chassis Screws The chassis and accessory box include all the screws needed to setup your chassis. This section include descriptions of the most common screws used. Your chassis may not require all the parts listed. HARD DRIVE Flat head Pan head 6-32 x 5 mm... -
Page 53: Appendix B Sc811 Power Supply Specifi Cations
Appendix B: Power Supply Specifi cations Appendix B SC811 Power Supply Specifi cations This appendix lists power supply specifi cations for your chassis system. 520W 280W MFR Part # PWS-521-1H PWS-281-1H Rated AC Volt- 100 - 240V, 50 - 60Hz, 100 - 240V, 50 - 60Hz, 5Amp 7 - 3 Amp +5V standby 3 Amp... - Page 54 Chassis Manual Notes...
