Motif Medical Roam Quick Manual

Motif Roam™ Quick Guide
1. Buttons & Features
A Massage Mode
B Expression Mode
C Cluster Feeding Mode
D General Pumping Mode
E Level Display
F Time Display
G Power Display
H Power Button
I Mode Button
J Level Up Button
K Level Down Button
2. Assembling the Motif Collection Cups
1. Push the silicone duckbill valve into
the breast shield.
2. Put diaphragm into the breast shield.
Make sure it is sealed around the
edge.
3. Insert the spout on collection cup
into the hole at the top of the breast
shield. Push the collection cup into
the breast shield. There should be
an audible 'click'.
4. Insert the tubing into the tubing
connector and attach to the
collection cup.
5. For single pumping, insert one tube
into one breast pump port and block
the other. To pump on both sides,
insert both tubes into the two breast
pump ports.
E
A
B
C
D
H
Tubing
Breast Shield
(28 mm)
Flange Inserts
16 mm / 19 mm
21 mm / 24 mm
I J K
Diaphragm
Collection Cup
Duckbill
Valve
Pump
Motor
F
G
Tubing
Connector
Tubing
