Chino KR3 Series Instructions Manual

Pdf chart graphic recorder
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INST.No.INE-930G
Thank you for purchasing the KR series graphic recorder.
Before using your new recorder, please be sure to read this instruction manual that will advise
you on how to use the instrument correctly and safely and how to prevent problems.
－ Request to instrumentation engineers, constructors, and sale agents －
Make sure to deliver this instruction manual to the operator of this instrument.
This instruction manual is necessary for maintenance, too. Keep this manual
with care until the instrument is discarded.
PDF chart
Graphic Recorder
KR2D/KR3D
【General】
Instruction
－ Request to the operator of this instrument －
KR2D/KR3D【General】Instruction Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KR3 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Chino KR3 Series

Summary of Contents for Chino KR3 Series

  • Page 1 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual PDF chart Graphic Recorder KR2D/KR3D 【General】 Instruction Thank you for purchasing the KR series graphic recorder. Before using your new recorder, please be sure to read this instruction manual that will advise you on how to use the instrument correctly and safely and how to prevent problems. －...

  • Page 3: Important Notes For Users

    4. If the cause of the damage is done by other than our product. Furthermore, the term 'warranty' in this sense covers only a CHINO's product itself. Therefore, we are not responsible for compensation for whatever the damage that is triggered by failure of our product.
  • Page 4 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual Disposal  Disposal Separate the box, plastic bags, and cushioning materials the recorder is packaged in according to the garbage collection method of the each community, and please cooperates to recycle. A small amount of hazardous substance below the specified ...
  • Page 5 ● Product category With the reference to the equipment types in WEEE [2002/96/EC] ANNEX I, this recorder is classified as a "Monitoring and control instruments". Do not dispose as general household waste. When disposing discarded recorder, please contact local CHINO sales agent.

  • Page 6: Table Of Contents

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual Table of Contents PREFACE ................................1 Table of Contents ..............................4 For safe use ......................... 8 1-1 Preconditions for use ............................. 8 1-2 Labels on this instrument ..........................8 1-3 Symbols in this manual ..........................8 Before use ........................11 2-1 Exterior check ...............................
  • Page 7 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual Operation (Be sure to read Para. 1 for safety.) ............47 6-1 Language Setting ............................47 6-2 Initial settings ............................... 47 6-2-1 Setting of the language ............................48 6-2-2 Setting of the power frequency .......................... 48 6-2-3 Setting of the usage group count........................49 6-2-4 Clock settings ..............................
  • Page 8 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 9-10 Network settings ............................121 9-10-1 Ethernet settings .............................. 122 9-10-2 DNS settings ..............................123 9-10-3 Web server settings ............................124 9-10-4 FTP client settings ............................125 9-10-5 FTP server settings ............................126 9-10-6 SNTP client settings ............................127 9-10-7 Email settings ..............................
  • Page 9 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 13 Past profile replay (Option) ..................181 13-1 Past profile replay ............................ 181 13-1-1 Creating reference file (for replay) ......................... 181 13-1-2 KR settings ..............................184 13-1-3 Reference file replay operation ........................185 14 Barcode scan function (Option) ................187 14-1 Outline ..............................

  • Page 10: For Safe Use

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual For safe use This section "For safe use" has been compiled to promote the correct use of the instrument in order to prevent human injury or damage to property before they occur. If this instrument is used other than description of this document, protection provided by the instrument may be vitiated.
  • Page 11 Power supply label  Don't repair or modify this instrument Make sure that any persons other than service engineers approved by CHINO CORPORATION do not repair or modify this instrument by replacing parts. Otherwise it may be damaged or will not function normally or an accident such as electric shock and burn may occur by putting your hand and a tool in the internal unit.
  • Page 12  Turn off the power supply if an abnormal symptom occurs Turn off the power supply immediately and contact your local CHINO's sales agent if any abnormal odor, noise or any smoke occurs, or if this recorder becomes high temperature that is too hot to be touched.

  • Page 13: Before Use

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual Before use Check the following items before using the recorder. If something is wrong, contact your local CHINO's sales agent. 2-1 Exterior check Check that the instrument is not broken on the outer side. 2-2 Model check The model number and serial number of this recorder can be confirmed by the label on the upper side of the case.
  • Page 14 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual <KR3D> KR3D□□‐□□□‐□□□ Serial No. KR3D**-***-*** Model (Check with model code.) K*********** MADE IN JAPAN Kind D: PDF chart specification Measurement point/ Measuring period 21: 12 points/1 sec. 41: 24 points/1 sec. 61: 36 points/1 sec. 81: 48 points/1 sec. Communication interface (Option) G: Ethernet + low/high order communications (RS-485) E: Ethernet...

  • Page 15: Checking Attachments

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 2-3 Checking attachments Package contains the following attachments. Please confirm. <KR2D> Parts name Quantity Remarks INE-881 □ (General), INE-883 □ (Communication interface), PDF Chart Auto Printing Software, Instruction Recipe Creation Software Sample CD-ROM manual KR3S-02- □ (Wiring/Installation) A4 Booklet RZMC-01- □...
  • Page 16 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual <KR3D> Parts name Quantity Remarks INE-930 □ (General), INE-883 □ (Communication interface), PDF Chart Auto Printing Software, Instruction Recipe Creation Software Sample CD-ROM manual KR3S-02- □ (Wiring/Installation) A4 Booklet RZMC-01- □ (CF card) Mounting bracket For panel mounting Wrench Terminal screw M3.5 for measuring input terminals (Spares for missing)

  • Page 17: Installation

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual Installation Make sure to read and understand this instruction manual to Caution prevent any accident. 3-1 Mounting location In order to avoid unfavorable effects on the measurement accuracy and recording operation, install this recorder at the following locations. 1.

  • Page 18: External Dimensions

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 3-2 External dimensions The following figure shows the dimensions of this recorder with its mounting brackets. <KR2D> Unit: mm <KR3D> Unit: mm -16-...

  • Page 19: Method Of Mounting The Panel

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 3-3 Method of mounting the panel Mount on the panel and use Caution  This instrument has been designed to be mounted on an indoor instrumentation panel.  Use a panel made of a steel plate of 2mm to 6mm in thickness or a panel equivalent in strength.

  • Page 20: Mounting Method

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 2. Mounting method Tightening torque Caution  If tightening more than recommended tightening torque, changing shape of the case and damage of brackets may occur. <KR2D> (1) Insert this recorder into the panel cutout from the front of the panel. (2) Insert the brackets into the holes of front Mounting bracket side on the top and bottom surface (or right...

  • Page 21: Connections

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual Connections 4-1 Terminal board arrangement The following diagram shows the terminal board arrangements in which option (Alarm relay output [4 points 'c' contact], communication interface) are mounted. <KR2D> Power terminal Alarm output (option) Protective conductor terminal ‘c’ contact output: 4points/terminal block Measurement input terminal TC･mV(+) / RTD(A)
  • Page 22 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual [Option terminal block]  Alarm relay output (4 points 'c' contact)  No-voltage contact input (4 points)  Alarm relay output (2 points 'c' contact) + No-voltage contact input (2 points)  Communication terminals Ethernet + low/high order communications (RS-485) Ethernet connector SA SB SG ...
  • Page 23 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual Alert symbol marks （ ） and places Warning The alert mark is pasted at danger places where may causes electric shock. (See the following table). Places marked with the symbol Name of terminals KR2D KR3D Power terminals Lower left of Upper of power terminals...

  • Page 24: Precautions While Connections

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 4-2 Precautions while connections Observe the following cautions during connections for securing safety and reliability. 4-2-1 Power supply Use a single-phase power supply having a stable voltage without any waveform distortion for the purpose of preventing wrong operations. ...

  • Page 25: Unused Terminals

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual Kinds of terminals and termination Screw Tightening Terminal name Termination (Unit: mm) diameter torque Power and t:0.8 protective Type O conductor and 1.2N ・ m More than 4.3 Less than 8.0 communication With an insulation sleeve terminal Type O t:0.8 Less than 8.0...

  • Page 26: Connection Of Power And Protective Conductor Terminals

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 4-3 Connection of power and protective conductor terminals 4-3-1 Power and protective conductor terminals <KR2D> Power terminals Protective conductor terminal 100-240V AC 50/60Hz 35VA MAX Power supply (voltage, frequency, power consumption) <KR3D> Power terminals Protective conductor terminal 100-240V AC 50/60Hz 60VA MAX Power supply (voltage, frequency, power consumption)

  • Page 27: Connection Of Power Terminals

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 4-3-2 Connection of power terminals For connection to the power terminals, use a 600 V PVC insulated cable terminated by the crimp style terminals with insulation sleeve. Note) Use the cords approved by the following standards. (1) IEC 227-3 (2) ANSI/UL817 (3) CSA C22.2 No.21/49 4-3-3...

  • Page 28: Connection Of Measuring Input Terminals

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 4-4 Connection of measuring input terminals 4-4-1 Measuring input terminals Be sure to turn off the power supply to prevent an electric shock. For the connections to the input terminals, use cables terminated by the crimp style terminals with insulation sleeve.

  • Page 29: Connection Of Resistance Thermometer (Rtd) Input

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 4-4-4 Connection of resistance thermometer (RTD) input Use a 3-core cable where each lead wire has an equal resistance value. Don't use one resistance thermometer in parallel with other instruments (controller, etc.). ● Resistance thermometer (RTD) input 1 2 3 4 5 6 3 core cable (Same diameter, same length) Resistance thermometer...

  • Page 30: Connection Of Alarm Output Terminals (Option)

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 4-5 Connection of alarm output terminals (Option) This is for the recorder with alarm output terminals (Option). 4-5-1 Alarm output terminal The terminal arrangement depends upon the type of alarm output. Alarm relay output 4 points ('c' contact) Alarm relay output 2 points ('c' contact) -28-...

  • Page 31: Connections

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 4-5-2 Connections Turn off the power supply and buffer relay power supply before connections to prevent an electric shock. (1) Connect cables to the load via a buffer relay. (2) Use cables with the crimp style terminals with insulation sleeves for the alarm output terminals.

  • Page 32: Precautions For Connection

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 4-5-3 Precautions for connection Be careful with the following cautions for connections. Item Contents Power Resistive Inductive Contact rating of supply load load (Minimum load) Mechanical relay outputs 100V AC 1.5A 100mA 5VDC ('c' contact) 240V AC 1.5A 30V DC 1.5A...

  • Page 33: Connection Of Digital Input Terminals And Function Selection (Option)

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 4-6 Connection of digital input terminals and function selection (Option) This is for the recorder with digital input terminals (Option) 4-6-1 No-voltage contact input terminal No-voltage contact input (4 points) DI1 DI2 DI3 DI4 No-voltage contact input (2 points) DI1 DI2 ...

  • Page 34: Connections

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 4-6-2 Connections Turn off the power supply before connections to prevent an electric shock. Apply a no-voltage contact signal to digital input terminals. Use cables terminated by crimp style terminals with insulation sleeves for the digital input terminals.

  • Page 35: Connection Of Communication I/F Terminal (Option)

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 4-7 Connection of communication I/F terminal (Option) KR can communicate with a master unit via Ethernet and RS-485, and with slave units via RS-485 and RS-232C. *Ethernet, RS-485 and RS-232C communication function are optional. RS-232C is only for barcode hand-held scanner.

  • Page 36: Connections Of High Order Communication Rs-485

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 4-7-1 Connections of High order communication RS-485 PC and multiple devices are connected with RS-485. A line converter is required. RS-485 cables within 1.2km of total extension and up to 31 devices can be connected. Install a resistor of 100Ω to the last edge of the transmission line device side. (General metal film resistors will be fine.

  • Page 37: Connections Of Low Order Communication Rs-485

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 4-7-2 Connections of low order communication RS-485 Connect SA, SB of this recorder and SA, SB of low order connected instrument like the following figure. Refer to instruction manual of each instrument for detail method of low order instrument connection.

  • Page 38: Ethernet Wiring

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 4-7-3 Ethernet wiring (1) Example of connection between PC and Ethernet devices (one-to-one connection) Crossover twist-pair cable PC side with shield (Max.100m) Device side (2) Example of connection between PC and HUB/Ethernet devices (one-to-N connection) Straight twist-pair cable PC side with shield (Max.100m) Straight twist-pair cable...

  • Page 39: Name Of Each Part

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual Name of each part 5-1 Name of the front panel and its major function <KR2D> Display 5.7 inch TFT color LCD Touch panel CF card drive Reset switch For maintenance usually do not use. USB connector Power light Lights on even Display OFF Cover Touch pen...
  • Page 40 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual <KR3D> Display 10.4 inch TFT color LCD Touch panel CF card drive Reset switch Power light For maintenance usually do not use. Lights on even Display OFF USB connector Touch pen Cover Front glass Caution ● The front of display part is made by glass. To avoid injuries due to broken glass, do not give a strong shock to the glass.

  • Page 41: Character Entering Method

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 5-2 Character entering method This screen is used for setting a tag name, a marker text character string and setting/entering a password. When the character input screen is displayed, by pressing the "ABC" or the "abc", keys arranged on the lower column are changed to indications corresponding to the key pressed.

  • Page 42: Touch Panel Operation Method

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 5-3 Touch panel operation method In this paragraph, the basic screen operation method is described. 5-3-1 Tapping on the operation screen Alarm icon When an alarm is activated, the alarm Disk icon is acknowledged by tapping it. Recording starts or stops [Operation] button (Refer to '7-1 Common operations of...

  • Page 43: Auto Switching

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  About the [MARKER] button Displays marker input dialog. It cannot be operated during the recording is stopped. By tapping [MENU settings] - [Marker text settings], register marker text beforehand. [Input marker] list is displayed, tap and write marker on the trend. By selecting the [Input marker], key board display is appeared and texts are able to input.
  • Page 44 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Operate method of 4 separate screens This recorder can divide the screen and display it and the number of divisions is 2 or 4. Select the number of divisions from Display Settings - Common Parameters - Number of split screen.

  • Page 45: Tapping Operation On The Setting Screen

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 5-3-2 Tapping operation on the setting screen On the MENU setting and the HOME setting screens, setting operations can be executed more smoothly by tapping each item. For inputting into each item, tap a button with the ▼ mark. For returning to a previous screen, tap the [Return] button.

  • Page 46: Handwriting Operations On The Trend Screen

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 5-3-3 Handwriting operations on the trend screen On the real time trend screen and the historical trend screen, handwriting operations can be executed with free handwriting feeling by tapping and skimming the display. For executing the handwriting operations, tap once to enable the handwriting.
  • Page 47 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Setting operation When is tapped in the handwriting operations, the thickness and the color of the drawn point can be changed from the dialog box shown below. The thickness can be selected 1 to 10 steps. The color can be selected from 16 colors.

  • Page 48: Recording Separator

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 5-4 Recording separator In this paragraph, recording separator drawn on trend display (real trend, historical trend and dual trend) at recording start is described. On this recorder, recording separator parallel to the time axis is drawn at recording start and old and new recording ranges can be seen at the same time.

  • Page 49: Operation (Be Sure To Read Para. 1 For Safety.)

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual Operation (Be sure to read Para. 1 for safety.) 6-1 Language Setting When at initial power on or turning on the power again in the initial settings screen, the language setting screen is displayed. By tapping the ▼ button of the Language Setting, the pull-down menu is displayed. Tap English or Japanese in the pull-down menu for setting.

  • Page 50: Setting Of The Language

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 6-2-1 Setting of the language By tapping the ▼ button of the Language, the pull-down menu is displayed. Tap English or Japanese in the pull-down menu for setting. 6-2-2 Setting of the power frequency By tapping the ▼ button of the 50Hz/60Hz, the pull-down menu is displayed. Tap 50Hz or 60Hz in the pull-down menu for setting.

  • Page 51: Setting Of The Usage Group Count

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 6-2-3 Setting of the usage group count By tapping the ▼ button of the item of the usage group count, the pull-down menu is displayed. Select usage group count in the pull-down menu. (<KR2D>1 to 5, <KR3D>1 to 6 group) Less the usage group count, longer the time to record in the internal memory.

  • Page 52: Input Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 6-2-5 Input settings By tapping the [Set] button of the input settings, the following input settings screen is displayed. *For detailed settings, refer to [9-1 Input operation settings]. 6-2-6 Display settings By tapping the [Set] button of the display settings, the following display settings screen is displayed.

  • Page 53: File Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 6-2-7 File settings By tapping the [Set] button of the file settings, the following file settings screen is displayed. *For detailed settings, refer to '9-5File settings'. 6-3 Start/Stop operations of recording 6-3-1 START Tap icon on the top of the screen, or tap [Operation] - [START]. The data of the groups, of which recording conditions are established, are stored into the internal memory.

  • Page 54: Names And Functions Of The Operation Screen

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual Names and functions of the operation screen 7-1 Common operations of the operation screen The status bar is displayed on the top of the screen and displays the status, etc. of this recorder. Normally the back color of the status bar is navy blue but, when the schedule is set, the back color becomes gray for the period other than the scheduled period.
  • Page 55 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual [Operation] menu  Menu item Operation START The recording starts. STOP The recording stops. Recording status Used to display recording status of each group and START/ STOP recording. HOME settings The HOME settings open. MENU settings The MENU settings open. ...
  • Page 56 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Display format is "standard" Numeric value that excludes decimal point is within ±30000 (Example: -30.000 to +30.000)  Display format is "index" 1.00E-15 to 9.99E+15 Excluding the historical data displayed part of the historical trends and the dual trends, the current data (with 0.5 second interval) irrespective of the recording interval, etc.
  • Page 57 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Disk icon 'CF card' or 'USB memory' can be selected on [Select external memory] for data saving destination (Refer to '9-11-9 Other settings'). Icon changes by selected external memory. 'REC' display and an arrow indicate the status of recording. Icon Arrow Status...

  • Page 58: Real Time Trend Screen

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 7-2 Real time trend screen The measuring values and trend at current state can be seen as an analog recorder. The pens are displayed on the scale plates corresponding to the values of 'Position' parameters of each channel. When the same 'Position' is set to multiple channels, the scale plates, trends and pens are displayed in the contents of the display scale of the smallest channel number in the group.

  • Page 59: Historical Trend Screen

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 7-3 Historical trend screen Display recorded data that is saved in the internal memory. Tapping the trend displays a cursor and shows measuring values at the current state.  Display method Tap [DISPLAY] - [Historical trend]. Displayed data is the latest recording data. If real trend is displayed, screen can be switched by tapping on [Hist] button on the bottom of the screen .

  • Page 60: Dual Trend Screen

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 7-4 Dual trend screen The real time trends and the historical trends are displayed by dividing the screen up and down, and the current data and the past data can be compared. Also the data display displays the current values and values at the cursor position of the historical trends by dividing the screen up and down.

  • Page 61: Data Screen

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 7-5 Data screen Displays the 'measured data of channels'. Displays 'data display frames' or the frame data that is registered at channel settings. Number of the frames <KR2D>1, 2, 3, 4, 6, 8, 9, 10, 12, 24, 44 <KR3D>1, 2, 3, 4, 6, 8, 9, 10, 12, 24, 36, 48, 56 ...

  • Page 62: Bar Graph Screen

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 7-6 Bar graph screen The measured values of the channels are displayed with the bar graphs in real time and can be seen visually. The scale plate is displayed in the contents of the display scale with the smallest channel number in the group.

  • Page 63: Alarm Display Screen

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 7-7 Alarm display screen The alarms being activated are displayed as a list. Activation date/time, cancel date/time (cancelled alarms only), channels (tag names) and alarm types are displayed in the reverse chronological order (latest on the top). Irrespective of the groups, all alarms being activated in this recorder are displayed.

  • Page 64: Internal Memory Screen

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 7-8 Internal memory screen The list of files recorded in the internal memory is displayed. The start date and time, the end date and time (the latest data time for a file being recorded) and the data count are displayed. The files are displayed in the reverse chronological order (latest on the top).

  • Page 65: Internal Memory

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Internal memory This recorder records all recorded data into the internal memory as a file. The data are copied to the CF card at a certain storing interval when the recording to this file is completed. <Limitations of internal memory>...

  • Page 66: Cf Card/Usb Memory Screen

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 7-9 CF card/USB memory screen The list of files stored in the CF card or the USB memory is displayed. The start date and time, the end date and time (the latest data time for a file being recorded) and the data count are displayed. The files are displayed in the reverse chronological order (latest on the top).

  • Page 67: Marker List Screen

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 7-10 Marker list screen The list of markers recorded on the trends is displayed. The date and time and the marker text are displayed in the reverse chronological order (latest on the top). The markers recorded in the selected group are displayed.

  • Page 68: Controller Display Screen

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 7-11 Controller display screen When controllers are connected with low order communications for compatibility (read) and channels are registered, the controllers can be displayed. By dividing the channel registered in the group selected into a frame for each controller, PV, SV, and MV are displayed.

  • Page 69: Controller Bar Graph Screen

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 7-12 Controller bar graph screen When controllers are connected with low order communications for compatibility (read) and channels are registered, the controller bar graph screens can be displayed. By dividing the channel registered in the group selected into a frame for each controller, PV, SV, MV1, and MV2 are displayed with bar graphs.

  • Page 70: Circular Trend Screen

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 7-14 Circular trend screen The data can be displayed as circular trend.  Display method Tap the [Operation] button and then tap [MENU settings] - [Display settings] - [Common parameters]. At the [Common parameters] set [Trend direction] 'Circle'. (Refer to '9-3-5Common Parameters'.) The detailed setting method refer to '9-3-7Circular settings'.

  • Page 71: Graphic Screen (Option)

    (.icon, .bmp file). *inside of the ( ) indicate the words of the KR Screen Designer. Up to 5 graphic screens are able to register. Low order communications with controller (CHINO's product) provide part of setting change in the low order instruments on the KR screen (compatible instrument: LT series, DB series).

  • Page 72: Display Method

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual (2)During the operation When reading the information of the graphic screen during the operation, operate from setting menu. Set CF card (which the graphic screen configured file is stored) into the KR. On the operation screen, tap [operation] button and then tap [MENU settings]-[Memory operation]-[Read graphic file]. Confirmation dialog is appeared, selecting [Yes] allows start reading the information of the graphic screen.

  • Page 73: Graphic Screen Switching Method

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 7-15-3 Graphic screen switching method By tapping the [▼] on the bottom of the screen, screen list is displayed and switching of graphic screen is enabled. 7-15-4 Operation on the graphic screen Following functions are available to the parts of which channel registration and the low order instrument number are registered.

  • Page 74: Home Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual HOME settings 8-1 Setting in HOME settings When the [HOME settings] is used, the inputs and recordings of all channels together can be set for the confirmation of input/recording simply. Tap the [Operation] button and then tap [HOME settings]. -72-...
  • Page 75 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Setting the range type DC voltage 13.8mV, 27.6mV, 69mV, 200mV, 500mV, 2V, 5V, 10V, 20V, 50V K, E, J, T, R, S, B, N, W-WRe26, WRe5-WRe26, PR40-20, NiMo-Ni, Thermocouple CR-AuFe, Platinel2, U, L Resistance thermometer Pt100, JPt100, Pt50, Pt-Co ...

  • Page 76: Confirming The Specifications In Home Settings Screen

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 8-2 Confirming the specifications in HOME settings screen The information of specifications of this recorder can be confirmed. When you have any question on this recorder, contact your nearest distributor after confirming specifications by this screen. Tap the [Operation] button and then tap [HOME settings]. Tap [Specifications].
  • Page 77 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual In the specifications confirmation screen, the followings can be confirmed.  Model  Serial number  Software version  MAC address -75-...

  • Page 78: Menu Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual MENU settings Tap the [Operation] button and then tap [MENU settings], the screen is switched to the parameter settings screen. Setting menu is displayed, tap an item to set. -76-...

  • Page 79: Input Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 9-1 Input settings Tap the [Operation] button and then tap [MENU settings] - [Input operation settings] - [Input setting]. On this screen, range, channel tag, etc. of the each channel can be set. *When Low order communication (read) option is effective, the item for the low order communication registration is added.
  • Page 80 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Setting the range type (Analog input) KR2D6* : CH1 to 6 KR2D2* : CH1 to 12 KR3D2*: CH1 to 12 KR3D4*: CH1 to 24 KR3D6*: CH1 to 36 KR3D8*: CH1 to 48 13.8mV, 27.6mV, 69mV, 200mV, 500mV, 2V, 5V, 10V, 20V, 50V DC voltage K, E, J, T, R, S, B, N, W-WRe26, WRe5-WRe26, PR40-20, NiMo-Ni, Thermocouple...
  • Page 81 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Copying the parameters with the copy function The above shows the setting for copying Channel 01 from Channel 01 to Channel 05. By tapping the [Go], the parameters of Channel 01 are copied from Channel 01 to Channel 05. ...

  • Page 82: Operation Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 9-2 Operation settings Tap the [Operation] button and then tap [MENU settings] - [Input operation settings] - [Operation setting], the following screen is displayed. On this screen, calculation of each channel can be set.  Setting the usage of calculation The input data are displayed and recorded as the measured date of its channel.
  • Page 83 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Comparison calculation The comparison calculation is performed and the result is returned as 1(established) or 0(not established). Symbol Example Remarks Equal value X == Y X != Y Unequal value More than >> X >> Y Less than <<...
  • Page 84 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Channel data calculation functions The function calculation is performed. When an error data (OVER, UNDER, etc.) is included in the measured data, it becomes 'CAL ER'. Symbol Example Remarks Refers to the value of specified CH(X) channel previous to its Measured data calculation*1...

  • Page 85: Relative Humidity

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Other function Symbol Example Remarks AZI(A) Refer to 11) Wind display Wind display 2. Totalizing operation For the totalizer, the ITG function is used. Do not use the totalizing function more than two times in one formula. The results are not calculated correctly.

  • Page 86: Dew-Point Temperature

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 5. Dew-point temperature Entering method of the formula DEW(T#H) T: Temperature data channel, H: Relative humidity channel The following formula is used for the dew-point temperature. t: Temperature data h: Relative humidity data D: Dew-point temperature 1. K=t+273.15 2.
  • Page 87 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 8. First-order leg filter Entering method of the formula IIR(X#T) X: Data channel number, T: Time constant (second) First-order calculation is performed in the data of channel X. Contents of calculation {dt÷(dt+t)} × (x-d) + d dt: Sampling cycle (0.1 seconds fixed), t: time constant, x: current value of channel X, d: previous calculation result 9.
  • Page 88 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual ··· ··· In addition, scale plate which is registered channel that is used this calculation is displayed wind scale. Display coordinate on the trend is same as normal numeric data. 12. Example of formula combining calculations ・(CH(1)*3-20)/6 ('Raw data of Channel 1'×3-20)÷6 ・(CH(1)+CH(2))<<...

  • Page 89: Display Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 9-3 Display settings 9-3-1 Channel parameters Tap the [Operation] button and then tap [MENU settings] - [Display settings] - [Channel parameters], the following screen is displayed. On this screen, types of display, display scale of the each channel can be set. Color of the waveform graph and display position can also be set.
  • Page 90 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Setting the scale position The position (1, 2, 3 and 4) indicates the position of the scale plate. For the vertical trend graph For the horizontal trend graph  Copying the parameters with the copy function The above shows the setting for copying Channel 1 from Channel 1 to Channel 5.

  • Page 91: Channel Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 9-3-2 Channel settings Tap the [Operation] button and then tap [MENU settings] - [Display settings] - [Group parameters] - [Channel settings], the following screen is displayed. The setting items on this screen are managed by each group. By select a group number, registering channels to be displayed on the group's graph is available.

  • Page 92: Trip Line Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 9-3-3 Trip line settings Tap the [Operation] button and then tap [MENU settings] - [Display settings] - [Group parameters] - [Trip Line settings], the following screen is displayed. The setting items on this screen are managed by each group. By select a group number, setting trip line to be displayed on the group's graph is available.

  • Page 93: Time Ruler Setting

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 9-3-4 Time Ruler setting Tap the [Operation] button and then tap [MENU settings] - [Display settings] - [Group parameters] - [Time Ruler setting], the following screen is displayed. The setting items on this screen are managed by each group. By select a group number, setting ruler interval of the group's graph is available.

  • Page 94: Common Parameters

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 9-3-5 Common parameters Tap the [Operation] button and then tap [MENU settings] - [Display settings] - [Common parameters], the following screen is displayed. On this screen, settings related to the graph such as direction of the graph to display and zone usage can be set.
  • Page 95 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Setting the bar graph direction Set the bar graph direction on the bar graph screen to be vertical or horizontal.  Setting the base position of the bar graph Set the base position of the bar graph from 0 to 100 on the bar graph screen. When the base position is 0, the bar is displayed based on leftmost (or bottommost).
  • Page 96 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Setting the separator line of data Select [ON] or [OFF]. When select [ON], display the separator line of data on the trends. (Refer to '5-4 Recording separator) *1 Zone The display range of the measured/calculated data is called zone. Since the data can be displayed by setting the zone for each channel, the data can be easily read by displaying the waveforms in separate zones.
  • Page 97 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Setting the division * Only KR3D Select from [OFF], [2], or [4]. Set division of the operation screen. If setting other than [OFF] is selected, division button is displayed on the bottom right. (e.g.: bisection button) When this button is tapped, a screen is divided.

  • Page 98: Lcd Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 9-3-6 LCD settings Tap the [Operation] button and then tap [MENU settings] - [Display settings] - [LCD settings], the following screen is displayed. On this screen, display off timer and saturation, etc. can be set.  Setting the display off timer (minute) The display-off timer for the LCD can be set from 1 to 60 minutes.

  • Page 99: Circular Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 9-3-7 Circular settings Tap the [Operation] button and then tap [MENU settings] - [Display settings] - [Common parameters]. At the [Common parameters] set [Trend direction] [Circle] the item is displayed. The setting items on this screen are managed by each group. Set group number.

  • Page 100: Partial Erase

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Setting the erase mode Item Contents After one full circle of the waveform is recorded, erase all the All data erase waveform on the chart and start drawing the next waveform. When there is one division left to record the waveform on the scale, Partial erase erase one old division and continue drawing the waveform.

  • Page 101: Alarm Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 9-4 Alarm settings Tap the [Operation] button and then tap [MENU settings] - [Alarm settings], the following screen is displayed. On this screen, alarm activation condition can be set by each channel.  Setting the type and the setting value Set the alarm type and the setting value for judgment.
  • Page 102 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Setting the relay *The alarm output terminal (Option) is necessary for outputting alarms actually. The relays can be set regardless of whether the alarm output terminal is used. Set the relays with the alarm output terminal number 0 to 24(for KR3S/3D/3H), 0 to 4(for KR2S/2D/2H).
  • Page 103 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual *1 Differential alarm Setting CH - Reference CH (Absolute value) Setting CH – Reference CH (Absolute value) Alarm activated Alarm activated Differential high limit Differential low limit At (Data of setting CH - data of reference CH)≧Alarm value : Differential high limit alarm activated At (Data of setting CH - data of reference CH)≦Alarm value : Differential low limit alarm activated *2 Alarm deadband Deadband...

  • Page 104: File Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 9-5 File settings 9-5-1 File settings Tap the [Operation] button and then tap [MENU settings] - [File settings], the following screen is displayed.  Setting the ON/OFF Record when checked and does not record when un-checked. Tap the [Set] button, file detail settings screen of the group is displayed. On this screen, recording cycle, start trigger and end trigger and recording data storing folder name can be set.
  • Page 105 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Setting the recording cycle Seconds 1 sec, 2 sec, 3 sec, 5 sec, 10 sec, 15 sec, 20 sec, 30 sec 1 min, 2 min, 3 min, 5 min, 10 min, 15 min, 20 min, 30 min, 60 min Minutes ...
  • Page 106 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Setting the pretrigger (0 to 950) When the recording starts, the past data retroactive to the count set here are recorded. Example: When the recording starts at 13:00:00 with the pretrigger [10] and the recording cycle [2 seconds], the data from 12:59:40 to 12:59:58 are added to the beginning of the file.
  • Page 107 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  If the alarm activation/recovery is set in 1sec., recording that is triggered by alarm may not start.  If the [period (seconds)] is set in the end trigger, recording data file is created at every set period until the trigger condition is cancelled. However, if the start trigger is [normal], recording data file is created at every set period until tapping on the [STOP].

  • Page 108: Pdf Chart Function

    9-5-2 PDF chart function By using PDF chart function, data can saved as PDF file into CF card as equivalent of data on CHINO's analog recorder or hybrid recorder chart paper.  How to output as PDF  Output types There are following three methods for PDF chart output.
  • Page 109 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Output contents Item Description File information Information regarding the file is printed on a head of the file. (Refer (List print) to 'List print items') Line on the chart ･ Displays data in graph format based on the display scale set in the channel parameter.

  • Page 110: File Information

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual (Example of chart paper) File information Data value  Settings To output PDF chart, set following items.  PDF chart setting Tap [File settings] - [Set PDF chart] of subject group. -108-...
  • Page 111 25mm/min. 50mm/min. 100mm/min. 200mm/min. (16 types) Chart width Selection of chart width: 100mm, 180mm, 250mm For KR2D, the width is fixed at 100mm. PDF file just as CHINO's chart paper is output. Scale Settings of minimum/ maximum values of the scale.
  • Page 112 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual Remarks If the characters on the scale overlap, they will not be printed.  List print items Select list print items to print on the head of the chart paper. (Printing example)  Data interval print Item Description Data Interval Print If it is [ON], printing is done at set time.
  • Page 113 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual (Print example)  Auto range settings About auto range There are two types of auto range; 'Normal' which ranges of maximum/ minimum does not overlap, and 'Overlap' which ranges overlap. Chart recording range is switched by measured value, for 'Normal' it can be switched up to 5 levels, and for 'Overlap' up to 3 levels can be switched.
  • Page 114 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual Setting example of auto range switch (normal) Recording range (0-1200°C) 1st range 4th range range range All recording ranges 1200 1st range recording range Reference 2nd range recording (400) range 3rd range recording (600) range 4th range recording (800) 1200...
  • Page 115 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual Auto range (overlap) settings It moves to the setting screen of each channel when number of [CH.] column is tapped. It shifts to higher range when a PV goes over maximum value of the range, and if a PV goes below minimum value, it shift to lower range.
  • Page 116 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  PDF output from file list  Supported file list PDF chart can be output from file lists on the screens mentioned below. Operation method is same to all. (A) Internal memory (B) CF card (C) USB memory ...
  • Page 117 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual ・ PDF chart file can not be output from CSV file. ・ At PDF chart file output, handwriting contents are not output.  Precaution on printing To print out as actual size, it is necessary to select [Actual size] on [Page Sizing &...

  • Page 118: Totalizer Reset Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 9-6 Totalizer reset settings Tap the [Operation] button and then tap [MENU settings] - [Totalizer reset settings], the following screen is displayed. On this screen, if the set formula set by the [Input operation settings] were totalizer, the procedure for resetting the totalized data to 0 can be set (Refer to '9-2-1Setting method of formula').

  • Page 119: Schedule Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 9-7 Schedule settings Tap the [Operation] button and then tap [MENU settings] - [Schedule settings], the following screen is displayed. On this screen, the recording period can be set. Even though the conditions specified with the file settings are established, the recording cannot be executed if it is not in the scheduled period.

  • Page 120: Marker Text Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 9-8 Marker text settings Tap the [Operation] button and then tap [MENU settings] - [Marker text settings], the following screen is displayed. Displayed screen differs from 'with or without' DI (Option). On this screen, marker text (maximum of 50 characters) to be written on the trends can be registered.

  • Page 121: Memory Operation

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 9-9 Memory operation Tap the [Operation] button and then tap [MENU settings] - [Memory operation], the following screen is displayed. On this screen, saving and reading of the setting files and copying recorded data to the USB memory are available.
  • Page 122 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Reading the setting from the eternal memory The setting file saved in the external memory (CF card or USB memory) is read and the current settings are overwritten. List of the saved setting files in alphabetical order is displayed. Settings are read when tapping the file desired to be read.

  • Page 123: Network Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 9-10 Network settings Tap the [Operation] button and then tap [MENU settings] - [Network settings], the following screen is displayed. On this screen, network settings of this recorder can be set. A list of network settings Ethernet settings Refer to '9-10-1 Ethernet settings'.

  • Page 124: Ethernet Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 9-10-1 Ethernet settings Tap the [Operation] button and then tap [MENU settings] - [Network settings] - [Ethernet settings], the following screen is displayed. On this screen, set address settings to use this recorder on the Ethernet.  Automatic IP addressing Set automatic IP addressing acquisition of this recorder.

  • Page 125: Dns Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  IP address Set IP address of this recorder. Ask the IP address to the administrator for the network to connect.  Subnet mask Set the subnet mask of this recorder.  Default gateway If there is a gateway like a router, etc. on the network, set the default gateway address. ...

  • Page 126: Web Server Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  DNS ON/OFF Select the DNS from ON (enabled) or OFF (disabled).  Primary server IP, Secondary server IP Enter the address of the DNS server. If the primary server is not found, use the address of the secondary server.

  • Page 127: Ftp Client Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 9-10-4 FTP client settings Tap the [Operation] button and then tap [MENU settings] - [Network settings] - [FTP client settings], the following screen is displayed. On this screen, FTP settings of this recorder can be set.  Server address Specify the address of the server for transferring the file.

  • Page 128: Ftp Server Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  'FTP transfer error' message is displayed every 30sec. after displaying of the first message, during the error condition is established.  If high load settings such as many calculations are set or below 1sec is set for recording intervals in multiple groups, and times of writing to the CF card is comparatively high, FTP transmission and/or sending a mail may not be Remarks...

  • Page 129: Sntp Client Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Login password Set the password for logging into the FTP server.  Using method of FTP server By using the function of the FTP server, the file in the CF card of this recorder can be read from a PC on the network. The followings are the connection method for using the Windows explorer.

  • Page 130: Email Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  SNTP server Specify the address of the SNTP server. When the address is set with a name ( .co.jp, .com, etc.), not the IP address, make sure to set the DNS (9-10-2).  SNTP base time/ SNTP interval The time synchronization is executed at the following time.
  • Page 131 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Forwarding address By selecting, the following screen is displayed. On this screen, up to 8 forwarding address can be set.  Forwarding condition By selecting, the following screen is displayed. On this screen, up to 8 forwarding conditions can be set.

  • Page 132: Condition Number

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Beginning CH, Last CH These settings are effective then the [Alarm activated time] is selected in the forwarding condition. The e-mail is forwarded when the alarm is activated in the channels specified by the starting channel and the ending channel. ...
  • Page 133 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Copying the parameters with the copy function The above shows the setting for copying Channel 1 from Channel 1 to Channel 5. By tapping the [Go], the parameters of Channel 1 are copied from Channel 1 to Channel 5. ...
  • Page 134 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  POP before SMTP Turn this ON if authentication done by POP before SMTP is preferred.  SSL connection method Select SSL connection method from below. Item Content None Do not perform SSL connection SSL/TLS Use SMTP over SSL or POP3 over SSL STARTTLS Use STARTTLS (Setting example)

  • Page 135: System Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 9-11 System settings Tap the [Operation] button and then tap [MENU settings] - [System settings], the following screen is displayed. On this screen, clock, communication, adjustment (calibration) and user registration of this recorder can be set. A list of System settings Clock settings Refer to '9-11-1 Clock settings'.

  • Page 136: Clock Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 9-11-1 Clock settings Tap the [Operation] button and then tap [MENU settings] - [System settings] - [Clock settings], the following screen is displayed. On this screen, internal clock settings of this recorder can be set.  Date / Time Enter the date in the same way as the character entering.

  • Page 137: Key Lock

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 9-11-2 Key lock Tap the [Operation] button and then tap [MENU settings] - [System settings] - [Key lock], the following screen is displayed. On this screen, key lock operation can be carried out. If the key lock is 'ON' and lock item 'Settings' is checked then selecting the MENU settings, entering the password is necessary to be in the settings screen.

  • Page 138: Password Setting

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 9-11-3 Password setting Tap the [Operation] button and then tap [MENU settings] - [System settings] - [Password setting], the following screen is displayed. This password is used for the followings.  For releasing the key lock  Setting the password (For entering the password, refer to '5-2 Character entering method'.) Set the password for the key lock.

  • Page 139: High Order Communication Settings (Option)

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 9-11-4 High order communication settings (Option) Tap the [Operation] button and then tap [MENU settings] – [System settings] - [High order communication], the following screen is displayed. On this screen, high order communication for this recorder can be set. *This screen is not displayed without communication interface option.

  • Page 140: Scale Adjustment

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 9-11-5 Scale adjustment Tap the [Operation] button and then tap [MENU settings] - [System settings] - [Scale adjustment], the following screen is displayed. On this screen, adjustment of the scale for this recorder can be set (Refer to '17 Scale adjustment'). -138-...

  • Page 141: Touch Panel Calibration

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 9-11-6 Touch panel calibration Tap the [Operation] button and then tap [MENU settings] - [System settings] - [Touch panel calibration], the following screen is displayed. On this screen, calibration of touch panel for this recorder can be set. The touch panel has been calibrated at the factory but the coordinates may be out of alignment as time passes.

  • Page 142: Display Menu Editing

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 9-11-7 Display menu editing Tap the [Operation] button and then tap [MENU settings] - [System settings] - [Display menu editing], the following screen is displayed. On this screen, items to be displayed on the [Select display] of the [DISPLAY] menu on the trend screen can be set.

  • Page 143: Di/Do Self Test (Option)

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 9-11-8 DI/DO Self test (Option) Tap the [Operation] button and then tap [MENU settings] - [System settings] - [DI/DO Self test], the following screen is displayed. On this screen, alarm output/digital input operation confirmation can be done. DI test DO test -141-...

  • Page 144: Other Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 9-11-9 Other settings Tap the [Operation] button and then tap [MENU settings] - [System settings] - [Other settings], the following screen is displayed. On this screen, language, filter level and selecting communication type, etc. for this recorder can be set.
  • Page 145 Modbus RTU that is connected as low order. (Modbus RTU) Compatible Low Used for reading input data of a CHINO instrument and data in PLC that is connected as low order. (read) Used for writing data of KR to PLC that is connected as low order.

  • Page 146: Setting/Displaying On Web Screen (Option)

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 10 Setting/displaying on Web screen (Option) 10-1 Display and settings using the Web screen By using the web browser, the settings relating to inputs and records of this recorder can be configured and the data can be displayed. Remarks Please see '8 HOME settings' and '9 MENU settings' also.

  • Page 147: Recorder Display

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 10-1-2 Recorder display The same contents as this recorder are displayed. If click the screen by mouse, it is possible to operate as same as touch panel operation like the main instrument. Because of the image file used, it takes more time for loading than other screens.

  • Page 148: Input Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 10-1-4 Input settings This is for changing the settings of the input parameters of this recorder. By clicking the [Set] button after entering each item, the setting contents are written in this recorder. The displaying channel block can be switched by selecting the link from the [Channel number] table at the upper part of the screen.

  • Page 149: Alarm Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 10-1-5 Alarm settings This is for changing the settings of the alarm parameters of this recorder. By clicking the [Set] button after entering each item, the setting contents are written in this recorder. The displaying channel block can be switched by selecting the link from the [Channel number] table at the upper part of the screen.

  • Page 150: Calculation Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 10-1-6 Calculation settings This is for selecting whether the calculation for each channel of this recorder is used or not, and for setting the formula. When the [Set] button is clicked after entering each item, the setting contents are written in this recorder.

  • Page 151: Group Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 10-1-7 Group settings This is for changing the settings of the record-related-parameters of this recorder. When the [Set] button is clicked after entering each item, the setting contents are written in this recorder. The settings of one group are displayed on one screen. The group to be displayed can be switched by selecting from the [Group number] table on the upper part of the screen.

  • Page 152: Marker Text Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 10-1-8 Marker text settings This is for changing the settings of the maker text parameters of this recorder. When the [Set] button is clicked after entering each item, the setting contents are written in this recorder. By setting the text at the last column (No.

  • Page 153: Recording In A Usb Memory

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 11 Recording in a USB memory 11-1 Outline By using the USB port equipped with this recorder, the data can be stored in the USB memory instead of the CF card, or the data stored in the CF card can be copied to the USB memory. 11-2 Connectable media Do not connect any media other than the following.

  • Page 154: Communication Function Settings (Option)

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 12 Communication function settings (Option) 12-1 Low order (Modbus RTU) 12-1-1 Outline By using low order (Modbus RTU), data of instrument which supports Modbus RTU can be read and write. Maximum 31 instruments can be registered. 12-1-2 Setting method Tap the [Operation] button and then tap [MENU settings] - [System settings] - [Low order com (Modbus RTU)], the following screen is displayed.
  • Page 155 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Command Set communication command (function code). Commands to be able to set from KR are following. Read ReadBitSet(01) ReadBitData(02) ReadWordSet(03) ReadWordData(04) ExReadWordSet(60) ReadFloatData(04) Write WriteBitSet(05) WriteWordSet(06) WriteWordSet(16) ExWriteWordSet(61)  Data count Set number of data to perform communication (write/ read). Number of data available to be set is depending on the model code of the device.

  • Page 156: Input Setting Of Low Order Instrument

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 12-1-3 Input setting of low order instrument (1) On the setting menu screen of this recorder, tap [Input operation settings] - [Input setting]. (2) Tap the [Set] button of the column that displays low order unit. Input setting screen as follows is displayed.

  • Page 157: Compatible Low Order (Read)

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 12-2 Compatible low order (read) 12-2-1 Outline *To use low order communications (write), on [System settings] – [Other settings] of communication type, set 'Low order' (write). (Refer to '9-11-9 Other settings') Low order communications are functions that this recorder works as a master unit (high order instrument) communications and reading data of the other instruments which are connected as slave units (low order instruments) assigned for input channel of this recorder and then displaying and recording the data.

  • Page 158: Procedure Of Connection Setting To Low Order Instrument

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Lower-order communication (read) outline KR2D***G****** Model KR3D**-G**-*** Maximum 31 Connection quantity approximately 1 second per 1 instrument.* Data renewal period approximately 1 second for each instrument (no retry) * Communication time out Retain the data of last value. *1 Display of renewal may delay in this instrument depending on the condition of data renewal or communication response delay of low order side instrument.

  • Page 159: Register The Instrument To This Recorder

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 12-2-4 Register the instrument to this recorder (1) On the setting menu screen of this recorder, tap [System settings] - [Low order communication (read)]. ('Low order communication' is displayed only with the instrument that have optional low order communication.) (2) Select appropriate name of the model from a list of 'model'.* Register low order instrument...
  • Page 160 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual *2 On KR data of JU and JW is assigned as below for CH data. Voltage level CH01 Voltage level CH01 (average) Current value CH02 CH02 Current value (average) CH03 Electric power value CH03 Electric power value CH04 None assigned CH04 Load resistance value Voltage level...
  • Page 161 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual *3 The data of LT, DB, DP-G and KP is allocated in KR as CH data. Model name CH / Parameter DP-G CH01 ○ ○ ○ ○ ○ ○ ○ CH02 ○ ○ ○ ○ ○ ○ ○...

  • Page 162: Settings To Controllers

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 12-2-5 Settings to controllers On the registration screen of instruments (refer to '12-2-4 Register the instrument to this recorder), by pressing the [COM] button of the row, that a controller (LT series, DB) is registered, a portion of parameters for a controller can be set.
  • Page 163 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Operation parameters 2 It can be used for LT400 series and DB series controllers. For the controllers connected, the following operations can be executed. ・AUTO/MANUAL selection ・Manual output (auto/manual, valid only when the manual is selected) ・REMOTE/LOCAL selection ・Execution number selection (No.1 and No.2 only) ・Execution alarm value, Executing PID (DB series controllers only)
  • Page 164 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Event parameter [LT2/8] Display [LT3] Display [LT4] [DB] Display For the controllers connected, the following operations can be executed. ・Setting of event parameters 1 to 4 of execution No. 1 and 2. (*When the setting that exceeds the maximum and the minimum value of the EVENT value of each device is done, the error message is displayed.) -162-...
  • Page 165 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual The table below shows the change parameter of the controller in the system setting. (R: Read only R/W: Read and Write) Model name Controller menu Parameters name RUN/READY switching Operation parameters Execution number switching × × × ×...

  • Page 166: Register Plc To This Recorder

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 12-2-6 Register PLC to this recorder (1) On the setting menu screen of this recorder, tap [System settings] - [Low order communication (read)]. ('Low order communication' is displayed only with the instrument that have optional low order communication.) (2) Select the name of the model from the list of [Model].

  • Page 167: Register Ch Number Of Low Order Instrument

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 12-2-7 Register CH number of low order instrument (1)On the setting menu screen of this recorder, tap [Input operation settings] - [Input setting]. (2) Tap the ▼ of [Input type] of CH which is registered low order instrument. From the displayed list, select the model that is registered at '12-1-4 Register the instrument to this recorder' and '12-2-6 Register PLC to this recorder'.

  • Page 168: Input Setting Of Low Order Instrument

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 12-2-8 Input setting of low order instrument (1) On the setting menu screen of this recorder, tap [Input operation settings] - [Input setting]. (2) Tap the [Set] button of the column that displays low order unit. Input setting screen as follows is displayed.
  • Page 169 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual (4) When changing the setting from this recorder for appropriate CH of low order instrument, perform following procedure. (For the instrument which is not capable of changing the setting, [Send] and [Send all] button are not displayed.) When change the setting of only displayed CH, tap [Send] button.

  • Page 170: Compatible Low Order (Write)

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 12-3 Compatible low order (write) 12-3-1 Outline *To use Low order communications (write), on [System settings] - [Other settings] of communication type, set 'Low order' (write). (Refer to '9-11-9 Other settings') Low order communications (write) has the function that this recorder communicates as high order instrument and write measurement and calculation data of this recorder to connected low order instrument.

  • Page 171: Register The Instrument To This Recorder

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 12-3-2 Register the instrument to this recorder (1) On the setting menu screen of this recorder, tap [System settings] - [Low order communication (write)]. ('Low order communication' is displayed only with the instrument that have optional low order communication.) (2) Select the name of the model from the list of 'model'.

  • Page 172: Low Order (Modbus Tcp)

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 12-4 Low order (Modbus TCP) 12-4-1 Outline *Please note that this function can not be used with '12-2 Compatible low order (read)', '12-3 Compatible low order (write)' and ‘12-5 KT-M’. Low order communication (Modbus TCP) is that KR functions as a master unit of the communication and assigns read data from a slave device as input channel of KR, as well as writes measured and calculated data of KR to the slave device.
  • Page 173 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Procedure to prepare communication (1) Change setting of KR. □ [MENU settings] - [Network settings] - [Ethernet settings] Set IP address etc. according to usage environment. □ [MENU settings] - [System settings] - [Low order com (Modbus TCP)] On the setting menu screen of MENU settings, select System settings then Low order communication to display following screen.

  • Page 174: Instrument Registration

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 12-4-2 Instrument registration Operates on MENU settings. It moves to the input screen when [set] button is tapped. From MENU settings, select low order communication and then instrument setting to display following screen on the left. Registration information of an instrument to be connected to KR is displayed. Screen on the right is displayed when [set] is tapped.
  • Page 175 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Set Unit ID ･Set unit number (instrument number, slave) of connecting instrument. ･Depending on the model, some instrument can only be connected by specific unit number, so refer to the instruction manual of corresponding device. If the connecting instrument is KR, set unit number to 1.
  • Page 176 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Copy parameter using copy function ・Example of copy Setting of screen above shows copying contents of No.1 to No.1 to 8. When the copy is done, setting is changed as shown below. Usage status of copy source, port number, and unit ID is copied at same status. IP address is continuous number from copy source and the instrument name is the name of the copy source plus '_' and number added.

  • Page 177: Data Configuration

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 12-4-3 Data configuration Operates on MENU settings. It moves to the input screen when [set] button is tapped. From MENU settings, select low order communication and then data configuration to display following screen on the left. Data connection information of an instrument to be connected to KR is displayed. Screen on the right is displayed when [set] is tapped.
  • Page 178 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Set Data count ・Set data count which performs communication (write/ read). ・The value that exceeds number of the corresponding channel can not be set.  Set KR top CH ・Set the top of the channels of which KR performs write and read. ・Channel to be able to read are as follows.

  • Page 179: Input Setting Of Low Order Instrument

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 12-4-4 Input setting of low order instrument (1) On the setting menu screen of this recorder, tap [Input operation settings] - [Input setting]. (2) Tap the [Set] button of the column that displays low order unit. Input setting screen as follows is displayed.

  • Page 180: Kt-M Input

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 12-5 KT-M input 12-5-1 Outline By using low order communication function, KR and KT-M can be connected. KR and KT-M communicate through RS-485 communication standard compliant serial communication. Data update interval is about 3 seconds.  Serial communication is used by KT-M, so both high order and low order can not be used by other applications.
  • Page 181 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual (3) Check input point by Low order communication [Input points]. KT-M maximum CH number 24 can be input. Save the setting by tapping [Return]. (4) Check that KT-M is set properly from MENU settings - input operation settings - input settings. Change tag and unit from [set] if necessary.
  • Page 182 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  KT-M input channel Channel of KT-M changes depending on the number of input channel of KR If it is analog input 12 points, CH13 of KR becomes 1CH of KT-M. (CH1 of KT-M is placed at position of KR input point + CH1) Arrangement of KT-M input channel can not be changed.

  • Page 183: Past Profile Replay (Option)

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 13 Past profile replay (Option) 13-1 Past profile replay Past profile replay is a recording function that replays and records CSV file (=reference file) created in advance during data recording. It is used to compare acquired data and the data in the reference file. (e.g.) CH1 and CH2: actual input channels, and CH49 and CH50: standard file data replay channels.
  • Page 184 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  File format Following is CSV format data file created by KR loaded on Excel. Row 1 indicates each column's item name: column A is date, B is time, and C and after are data. Column number on later mentioned calculation counts column C as the first one. ...
  • Page 185 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  To add information, input by single-byte characters. Remarks  Evaluation range is current replay position to next check point.  Check point available for 1 file is max. 30.  Alarm set value update function: [AO (rise)] [AU (fall)] By adding [AO CH□...

  • Page 186: Kr Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  File name shall be single-byte alphanumeric characters. It is necessary to enter the name at reference file selection screen (will be mentioned later), so a simple name is recommended.  Date information, time information, and data part shall be single-byte. Remarks ...

  • Page 187: Reference File Replay Operation

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 13-1-3 Reference file replay operation When the recording starts, reference file is read and the data replay starts. If p osition alignment function is written to the reference file, the operation follows the written contents. To adjust replay position manually, perform adjustment on [Position setting (Reference file)] screen during recording.
  • Page 188 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  CF card is being accessed on recording to refer to the reference file. Stop recording to insert/ remove CF card. If CF card is removed while it is being referred, previous value (data replayed previous to removal of the card) is retained, yet it does not recover even though the CF card is inserted again.

  • Page 189: Barcode Scan Function (Option)

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 14 Barcode scan function (Option) According to scanned barcode data, it performs marker writing, display group switch, and batch operation. With this option, barcode hand-held scanner [HC76TR] manufactured by DENSO CORPORATION can be connected to KR. 14-1 Outline According to scanned barcode data, it performs marker writing, display group switch, and batch operation.

  • Page 190: Setting

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual (All Code 39)  At 'Batch function' in use It is according to batch settings written in next chapter. Refer to the next chapter about the detail. 14-2 Setting 14-2-1 Common settings Set communication setting of KR/ HC76TR as follow to use this function. Communication interface RS-232C Half-duplex communication start-stop...

  • Page 191: Kr Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual Data (11-digit) C/D: Check Digit Transfer '0' for UPC-A digit adjustment (Transfer forbidden) Transfer UPC-A check digit (Transfer forbidden) (e.g.) For the case of Code 39 Start code Data Stop code (*) C/D: Check Digit Transfer Code 39 start code (Transfer forbidden) Transfer Code 39 check digit (Transfer forbidden) Transfer Code 39 stop code (Transfer forbidden) Change to Code 39 FULL ASCII (Change for bidden)
  • Page 192 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual Items in [Scan set] ･Scan content confirmation: Write the scan contents directly to the displayed group as marker text. Displays the marker text input screen containing the scan contents, and writes it to the displayed group when "OK" is selected. If the barcode was scanned before "OK", it will be added after the previous scan.

  • Page 193: Batch Function

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 15 Batch function Batch information can be added to the recording file by this function. Add information can be checked on CF card, USB memory screen 'File information', or on PC software ZAILA etc. 15-1 Batch settings 15-1-1 Batch ON/OFF [MENU settings] - [File settings] - each group [set].
  • Page 194 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  [Batch recording setting] screen: ･Number of lot number digit: 0 to 8 Set number of lot number digit used in recording. ･Lot number auto increment: Select from [ON] or [OFF]. If 'ON' is selected, lot number is automatically added at every start. ･Keep previous value of batch text: Select from [ON] or [OFF].

  • Page 195: File List Display Screen(Internal Memory/ Cf Card/ Usb Memory)

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 15-2 File list display screen(Internal memory/ CF card/ USB memory) [DISPLAY] - [Select display]- [Information] - each recording media (internal memory, CF card, or USB memory) Displays batch name, lot number, and start/ end date and time of each file saved in the file. When saving format is 'binary', file information screen of each file is displayed on CF card and USB memory screen.

  • Page 196: Recording Status Display Screen

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 15-3 Recording status display screen [Operation] - [Recording status] - [Recording status display]. Displays recording status of each group, and perform recording START/STOP. Displayed item: ･Recording status display Display each group status by 3 types: [Recording], [Waiting], or [STOP]. Recording start and waiting is available from status display right START/ STOP buttons.

  • Page 197: Batch Settings Window (Web Server Function)

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 15-4 Batch settings window (Web server function) [Batch settings] is added to the setting window accessed through a web browser. ･Display item: ･Group selection: Display group name of which batch information you want to display or set and click [Select] button.

  • Page 198: Supplement

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual It becomes setting error in the following conditions.  When KR is on recording or on setting (during displaying setting screen).  Invalid letter is included in the batch name. Invalid letters: [ : ] [ ; ] [ / ] [ ¥ ] [ | ] [ , ] [ * ] [ ? ] [ ' ] [ < ] [ > ] [ _ ] [ . ] Remarks ...
  • Page 199 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Recording information (CSV format) If saving a file in CSV format, following contents are added to standard 'recording data' and 'marker information'. ・Add contents Batch information, [line feed] Batch name, (batch name), [line feed] Lot number, (lot number), [line feed] (Batch text style 1), (Batch text character string 1), [line feed] (Batch text style 2), (Batch text character string 2), [line feed] (Batch text style 10), (Batch text character string 10), [line feed]...

  • Page 200: Barcode Recipe Maintenance Function (Option)

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 16 Barcode recipe maintenance function (Option) 16-1 Outline Write contents (setting parameter) of target recipe setting file (CSV format) to controllers through code data read from barcode. (Example) Recipe setting file (CSV format) KR2D/3D CF card RS-485 (1) Create recipe setting (parameters set to the controllers) file and implement to KR3D.

  • Page 201: Low Order Communication (Modbus Rtu) Settings

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 16-2-2 Low order communication (Modbus RTU) settings To display altered contents of controller parameter by the recipe file, register the instrument at low order communication (Modbus RTU) settings. (Refer to '12-1 Low order (Modbus RTU)') 16-3 Serial/ Ethernet converter (N Port Express) settings N Port Express DE-311 (1 port RS-232/422/485 serial device servers) manufactured by Moxa Inc.
  • Page 202 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual (4) Network Setting To change IP address of the Nport, mark check box of IP Address and change the set value. When OK is clicked, an altered content of checked item is reflected. Change other values if necessary. (5) OP Mode Mark check box of Chang OP Mode and select TCP Client for Port 1 and click More Setting.
  • Page 203 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual (6) TCP Client (More setting) Input IP address of KR to Destination IP Address. For other settings, input as shown in the window below. Connection of IP address set at Destination IP Address becomes valid. When the setting is finished, click OK. (7) Serial Settings Mark check box of Change Serial Port Setting and set as below.

  • Page 204: Hc76Tr Setting

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 16-4 HC76TR setting For setting of barcode hand-held scanner [HC76TR] manufactured by DENSO CORPORATION, refer to ' 14 Barcode scan function (Option) 14-2-2 HC76TR settings'. 16-5 About recipe file Recipe creating software sample (xlsm) is saved in instruction manual CD. Sample file is divided to 'Setting screen' sheet and 'CSV' sheet.

  • Page 205: Barcode Recipe Writing Procedure

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual < Recipe creating software: CSV sheet> (Setting example) *In this example controller KP2000 is connected as device (instrument) number 04. Function code Reference No. Setting contents Device (06) 232A…Hexadecimal 'Value' × 10^ 'Decimal point digit' (instrument) (=9002…Decimal) (0003) number (04)

  • Page 206: Scale Calibration

    The check and adjustment of measured values need careful cautions for the Remarks adjustment work besides tools such as standard tools and reference conditions. When the check and adjustment of measured values are required, contact your local CHINO's sales agent. -204-...

  • Page 207: Connections

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 17-4 Connections Connections depend upon the input types. Connect tools such as standard tools to the measuring input terminals to be adjusted. Turn off the power source before connections Caution Turn off the power source before connections for preventing electric shock.

  • Page 208: Zero And Span Adjustment

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 17-5 Zero and span adjustment Tap the [Operation] button and then tap [MENU settings] - [System settings] - [Scale adjustment], the following scale adjustment screen is displayed. On this screen, scale adjustment of each input channel can be set. Execute the range adjustment by inputting the zero and span values of the input range to each input terminal for adjustment.
  • Page 209 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual (2) When the window indicating the voltage value for inputting is displayed, input its value to this recorder. (3) Adjust the zero point. (Example) For the adjustment of the ± 69mV range  Input the voltage of 0V with the DC standard voltage generator. (4) After inputting the zero point for about 5 seconds, tap the [Go] button.

  • Page 210: Adjustment Of The Resistance Thermometer Input Range

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 17-5-2 Adjustment of the resistance thermometer input range Connect as shown in '17-4 Connection (2) In case of the resistance thermometer input'. Execute the adjustment by inputting the resistance value for the adjustment range. < Setting method > (1) Tap the [Go] button at the range to be adjusted.
  • Page 211 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual (5) Adjust the span point. (Example) For the adjustment of the Pt150 range  Input the resistance of 157.33Ω with the standard variable resistor. (6) After inputting the span point for about 5 seconds, tap the [Go] button. (7) After the adjustment of the span point, the screen is returned to the calibration screen for all ranges.

  • Page 212: Adjustment Of The Thermocouple Input Range

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 17-5-3 Adjustment of the thermocouple input range (Adjustment of the reference junction compensation (RJ at 0°C)) After the adjustment of the DC voltage input range, execute the adjustment of the thermocouple input range. If the adjustment of the DC voltage input range is Remarks performed after the adjustment of the thermocouple input range, the result of the adjustment would be influenced.
  • Page 213 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual (3) After about 30 seconds passed, tap the [Go] button. (4) After the adjustment, the screen is returned to the calibration screen for all ranges. (5) When the adjustments are completed, tap the [Return] button twice to return to the setting menu screen.

  • Page 214: Recommended Parts Replacement Interval

    For replacing parts, ask the service personnel authorized by Warning CHINO. Otherwise, this instrument may not recover properly and also accident may occur. Contact your local CHINO's sales agent to perform parts replacement.

  • Page 215: Troubleshooting

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 19 Troubleshooting 19-1 Trouble Troubleshooting methods are shown by symptoms. Read corresponding symptom items.  Not working Check Causes and remedial measures 1) Check if power is supplied to power Turn ON the external source power supply. terminals 2) Check if the power supply is as Feed power supply as specified (100 to 240...

  • Page 216: Battery Voltage Reduction

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 19-2 Battery voltage reduction If the power failure occurs at following state, data have not been Caution saved to the CF card and/or operation starting indication (refer below), etc. may be lost. To avoid this occurrence of event, stop acquiring data and execute 'writing from internal memory to the external memory'.
  • Page 217  When problem cannot be solved If the problem cannot be solved by performing the troubleshooting above, contact your sales agent or CHINO with information of: 1. Model, 2. Serial No., 3. Description of the problem, 4. Other notes. When repair of the instrument is needed, understand the following before having it to repair.

  • Page 218: Specifications

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 20 Specifications  General specifications Between primary and protective conductor terminals ……… 1 minute at 1500VAC Rated power voltage: 100-240 VAC, 50/60 Hz Between primary and secondary terminals (Universal power supply) …… 1 minute at 2300VAC Power consumption: *Primary terminals: Power terminals (L, N) KR2D……35VA MAX alarm output terminals...
  • Page 219 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Input specifications Input resistance: Thermocouple input……Approx. 1MΩ Measuring points: DC voltage input……… ±2V or less: Approx. 1MΩ KR2D……6 points, 12 points ±5V to ±50V: Approx. 1MΩ KR3D……12 points, 24 points, 36 points, 48 points Maximum input voltage: Input types: Universal input Thermocouple inputs (burnout disabled), DC voltage…...
  • Page 220 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual Data search (historical trend):  Start/end by day and time *Pre-triggering is available in the tap operations and Historical trend is displayed by selecting from the trigger signals. alarm display or the marker list Pre-triggering measurement count =950 data Marker display: Markers can be displayed on the trends *Storage channel and recording cycle are set for each record by the tap operation or by digital...
  • Page 221 INST.No.INE-930G KR2D/KR3D【General】Instruction Manual  Measurement ranges, Accuracy ratings and Display resolutions Note) The accuracy is under the reference operation condition. For the thermocouple inputs (internal RJ), the reference junction compensation accuracy is not included. Note) The indication equivalent to 1mV may vary under the test environment by EMC directives. * Only the CE/ UKCA corresponding model applies.

  • Page 222: Revision History

    INST.No.INE-930G KR2D/KR3D【General】Instruction Manual 21 Revision History Printed Edn. pages Description Mar. 2019 first edition － … Added caution "Handling of input terminal screw." Added "Note: Pretrigger can be set up to three groups." Added "If the range type set by the [Input operation settings] were digital input Pulse(+) or Pulse(-)..."...
