INST. No FKR-201505-3F
This product is a special specification with the following functions added. For other specifications, refer to the
standard instruction manual. Please be noted that since it is special specifications, there are some differences
from the standard instruction manual.
In addition, the company names (organization names) and product names mentioned are trademarks and
registered products of respective companies.
○
TM and
R mark are omitted throughout the manual.
1 Overview
This function is to assist operation of AMS2750 Rev. G (Aerospace Material Specifications of the U.S.) and
CQI-9 (Special Process: Heat Treat System Assessment).
1-1 Accuracy of KR2S00/ KR3S00/ KR2D00/ KR3D00 after using Input value correction
function adjustment
This specification is provided so that the customer can use the input value correction function of this
device to meet the accuracy required by the AMS2750G and CQI-9.
Following is the accuracy when input value correction function (Up to 16 points) is used. This is the
performance under the standard operating conditions. For the standard operating conditions, refer to the
specification section of the general instruction manual.
Input type
R
S
K
TC
N
J
T
KR2S00/ KR3S00/ KR2D00/ KR3D00
Heat Treatment Assistance
Specification Instruction Manual
Measurement
range
400 to 1760°C
400 to 1760°C
0 to 1370°C
±0.6°C or ±0.1% of reading value, whichever is greater
0 to 1300°C
0 to 1200°C
0 to 400°C
*Accuracy typical value does not include the error of the standard device.
Accuracy typical value (including RJ error)
1 / 60
*
