- Page 1 ISO 9001 ISO14001 Manufacturer Kakogawa, Japan is approved by LRQA Ltd. to ISO 9001/14001 Instruction Manual Free Float Drain Trap Featured models: SS1VG-M/SS1VG-R 172-65393M-07 Publication date 31 January 2025 Copyright © 2025 TLV CO., LTD.
-
Page 2: Table Of Contents
Specifications ........................... 7 Configuration ..........................8 Installation ..........................9 The Need for a Pressure-balancing Line ................10 Secondary Side Precautions ....................11 Maintenance ........................... 12 Disassembly/Reassembly ...................... 13 Troubleshooting ........................16 TLV EXPRESS LIMITED WARRANTY ................... 17 Service ........................... 19... -
Page 3: Introduction
Under no circumstances will TLV CO., LTD. be liable for consequential economic loss damage or consequential damage to property or persons caused by explosions, poisoning or other accidents due to use with hazardous fluids. -
Page 4: Safety Considerations
• The three types of cautionary items above are very important for safety: be sure to observe all of them as they relate to installation, use, maintenance and repair. Furthermore, TLV accepts no responsibility for any accidents or damage occurring as a result of failure to observe these precautions. - Page 5 Caution When disassembling or removing the product, wait until the internal pressure equals atmospheric pressure and the surface of the product has cooled to room temperature. Disassembling or removing the product when it is hot or under pressure may lead to discharge of fluids, causing burns, other injuries or damage.
-
Page 6: Checking The Piping
Have maintenance valves been installed at the inlet and outlet? If the outlet is subject to back pressure, has a check valve (TLV-CK) been installed? Is the inlet pipe as short as possible, with as few bends as possible, and installed so the... -
Page 7: Specifications
For products with a metal valve seat (orifice), a minimum required condensate load is necessary to maintain a liquid seal. There is a chance of air/gas leak if the condensate load falls below this rate. Please refer to the chart below. Model Minimum Required Condensate Load SS1VG-M 0.5 kg/h... -
Page 8: Configuration
Configuration SS1VG-M SS1VG-R Metal valve seat (orifice) Rubber valve seat (orifice) ⑦ ⑦ ⑧ ⑧ ① ① ② ② ⑥ ⑥ ⑨ ⑨ ⑪ ⑪ ⑫ ⑫ ③ ③ ④ ④ ⑤ ⑤ ⑩ ⑩ ⑬ ⑬ Part Name Part Name... -
Page 9: Installation
If there is a problem, determine the cause using the “Troubleshooting” section in this manual. Tolerance Angle for Installation: 5° 5° 5° 5° 5° Make sure the product is installed with the raised TLV lettering on the body horizontal. -
Page 10: The Need For A Pressure-Balancing Line
The Need for a Pressure-balancing Line This product is designed to automatically discharge inflowing condensate. However, if the condensate completely fills the inlet path of the product, air or gas in the product body will not be able to escape, preventing displacement by condensate, and thus preventing condensate from entering the product. -
Page 11: Secondary Side Precautions
Secondary Side Precautions Caution Take measures to ensure the proper handling, such as recovery or dilution, of hazardous fluids discharged at product outlets. Outflow of fluid or fluid leaks may lead to hazards such as flammable conditions or corrosion, which may result in injury, fires, damage or other accidents. Be sure to take precautions on the secondary side when using flammable, toxic or other hazardous gases. -
Page 12: Maintenance
Maintenance Caution Take measures to prevent people from coming into direct contact with product outlets. Failure to do so may result in burns or other injury from the discharge of fluids. Be sure to use only the recommended components when repairing the product, and NEVER attempt to modify the product in any way. -
Page 13: Disassembly/Reassembly
Disassembly/Reassembly Warning NEVER apply direct heat to the float. The float may explode due to increased internal pressure, causing accidents leading to serious injury or damage to property and equipment. Caution When disassembling or removing the product, wait until the internal pressure equals atmospheric pressure and the surface of the product has cooled to room temperature. - Page 14 Disassembly/Reassembly of Components Inside the Body Part Name & No. During Disassembly During Reassembly Screw Remove the connector Consult the table of tightening torques Spring Washer and tighten to the proper torque Screen Remove without bending Insert the screen with the proper orientation, aligning screw holes Table of Tightening Torques Part Name &...
-
Page 15: Exploded View
Exploded View 11, 12 Part Name Part Name Body Cover Bolt Cover Nameplate Float Flange Valve Seat (Orifice) Screw Valve Seat (Orifice) Gasket Spring Washer Screen Connector Cover Gasket Not shown... -
Page 16: Troubleshooting
Troubleshooting Warning NEVER apply direct heat to the float. The float may explode due to increased internal pressure, causing accidents leading to serious injury or damage to property and equipment. Caution When disassembling or removing the product, wait until the internal pressure equals atmospheric pressure and the surface of the product has cooled to room temperature. -
Page 17: Tlv Express Limited Warranty
Subject to the limitations set forth below, TLV CO., LTD., a Japanese corporation ("TLV"), warrants that products which are sold by it, TLV International Inc. ("TII") or one of its group companies excluding TLV Corporation (a corporation of the United States of America), (hereinafter the "Products") are designed and manufactured by TLV, conform to the... - Page 18 HEREBY, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, DO NOT COVER, AND NEITHER TLV, TII NOR ITS TLV GROUP COMPANIES WILL IN ANY EVENT BE LIABLE FOR, INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING, BUT NOT LIMITED TO LOST PROFITS, THE COST OF DISASSEMBLY AND SHIPMENT OF THE DEFECTIVE PRODUCT, INJURY TO OTHER PROPERTY, DAMAGE TO BUYER’S OR THE FIRST...
-
Page 19: Service
Service For Service or Technical Assistance: Contact your TLV representative or your regional TLV office. In Europe: Tel: [49]-(0)7263-9150-0 Daimler-Benz-Straße 16-18, 74915 Waibstadt, Germany Tel: [44]-(0)1242-227223 Units 7 & 8, Furlong Business Park, Bishops Cleeve, Gloucestershire GL52 8TW, U.K. Tel:...
