Summary of Contents for Sam4s Gcube Series

  • Page 1 Gcube Series Receipt Printer User Guide All specifications are subject to change without notice.
  • Page 3 Warning - U.S. This equipment has been tested and founded to comply with the limits for a Class A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 4 “OFF” and contact your dealer for assistance. INTRODUCTION The Gcube Series Roll Printer is designed for use with electronic instruments such as system ECR, POS, banking equipment, computer peripheral equipment, etc. The main features of the printer are as follows: 1.
  • Page 5 5. Characters can be scaled up to 64 times compared to it’s original size. 6. The data buffer allows the unit to receive print data even during printing. 7. Bar code printing is possible by using a bar code command. 8.
  • Page 6: Table Of Contents

    Contents Chapter 1. Setting Up the Printer ··································7 1.1. Unpacking ································································ 7 1.2. Connecting the Cables ············································ 8 1.3. Connecting the host device ····································· 9 1.4. Connecting the Drawer ··········································· 9 1.5. Connecting the Power Supply································ 10 1.6. Installing options & Replacing the Paper Roll ··················11 1.6.1.
  • Page 7: Chapter 1. Setting Up The Printer

    Your printer box should include these items. If any items are damaged or missing, please contact your dealer for assistance. Interface cable(option) Power-cord Roll paper Gcube Series Receipt Printer User Guide All specifications are subject to change without notice. Gcube Series Operator’s...
  • Page 8: Connecting The Cables

    < GCUBE-100S > Ethernet Reset Button Drawer Kick- Power supply connector connector out connector connector < GCUBE-100W > NOTES : Before connecting any of the cables, make sure the both printer and connectitng device are turned off. Gcube Series Receipt Printer...
  • Page 9: Connecting The Host Device

    1.3. Connecting the host device You need the appropriate interface cable. 1. Plug the cable connector securely into the printer’s interface connector. 2. Tighten the screws on both sides of the cable connector. 3. Attach the other end of the cable to the host device. 1.4.
  • Page 10: Connecting The Power Supply

    ➊ ➋ ↑ UP ➌ ➍ NOTES : To remove the DC cable connector, make sure the power supply’s power cord is unplugged and then grasp the connector at the arrow and pull it straight out. Gcube Series Receipt Printer...
  • Page 11: Installing Options & Replacing The Paper Roll

    1.6. Installing options & Replacing the Paper Roll 1.6.1. Wall Mount Installation 1. Using the bracket, mark it on the wall where you want to install the printer. 2. Make 3 holes in the marked places. 3. Install the wall mount bracket with screws as in picture 3. 4.
  • Page 12: Paper Roll Installation

    2. Remove the used paper roll core if there is one. 3. Insert the paper roll as shown. 4. Pull out a small amount of paper as shown in picture no.3. and close the printer cover. Tear off the paper as shown. ➌ ➍ Gcube Series Receipt Printer...
  • Page 13: Adjustments And Settings

    1.7. Adjustments and Settings Printer settings can be changed using NFC APP 1.7.1 How to install APP No.1 Easy Installation Mode » 1. Configure NFC Function from User’s Smart Phone into Read/Write, P2P Mode. (not workable in a Card Mode) 2.
  • Page 14: Change Device Setting

    4. When the message “Writing completed” appears while tagging the smart phone on the Printer, then tag the smart phone off Printer. 5. When the setting is well done, printer will print Self-Test Page after reset. ➊ ➋ ➌ ➍ Gcube Series Receipt Printer...
  • Page 15: Wifi Setting

    1.7. Adjustments and Settings 1.7.3 WiFi setting 1. Run a Smart WiFi Linke. 2. Select WiFI mode. Infra Mode and AP Mode can be selected. 1) Infra Mode - Set the network SSID and network key. Check the Infra Mode item. If you turn off DHCP, You can set the IP Address, Subnet Mask, Gateway Address, and Local Port.
  • Page 16: Using The Printer

    1.8.3. Panel lights : FND • ERROR FND This indicates when there is " Power on" error or no receipt paper left/almost used up. For detailed error type, kindly refer 2-3 Error Status and Erro Resolution on page <19-20>. Gcube Series Receipt Printer...
  • Page 17: Chapter 2. Appendix

    CHAPTER APPENDIX 2.1. Adjusting the Paper Near-End Sensor Location The sensor has five sensitivity settings. 1. Push the open button and open the printer cover. 2. If you find there is too m u c h p a p e r r e m a i n i n g w h e n t h e s e n s o r i s triggered, set the near end sensor to position #4 or #5.
  • Page 18: Printer Head Cleaning

    (ethanol, methanol, IPA) 4. Insert a paper roll and close the printer cover. Gcube Series Receipt Printer...
  • Page 19: Error Status And Error Resolution

    2.3. Error Status and Error Resolution When the printer error occurs, the alphabet corresponding to the error condition is shown on FND Error Status Indicator includes: • Cutter Jam When ERROR FND indicates "J", the printer is on Cutter Jam error status.
  • Page 20 This error occurs when the paper needs to be replaced. • Overheat This error occurs when the print head is overheated. Printing stops with an overtemperature error. When the printer head cools down, the error is cleared and printing continues. Gcube Series Receipt Printer...
  • Page 21: Specification

    2.4. Specification 2.4.1. General Printer specification Printing method Thermal Line Printing 180DPI (GCUBE-100) Resolution 203DPI (GCUBE-102) Printing width 72mm Paper width 80mm Font A : 42(GCUBE-100), 48(GCUBE-102) Characters per line(default) Font B : 56(GCUBE-100), 64(GCUBE-102) 59 lines/sec(250mm/sec, GCUBE-100) Printing speed 66 lines/sec(250mm/sec, GCUBE-102) Receive buffer size Max 64kbytes...
  • Page 22 MEMO Gcube Series Receipt Printer...
  • Page 24 Gcube Series Receipt Printer OPERATOR’S Manual JK68-61108A(Rev 02)
