Please read the manual before using the product. The manual and
packaging contain important information, please retain them prop-
erly for future references. Failure to follow the instructions in this
manual could be hazardous to your child.
In order to improve the product and quality, we may change the
parts of structure, appearance, packing method, assembly method
and function of the product without any notice. When there is any
difference between the manual and the product, please subject to
the actual product. We are sorry for any inconvenience.
Assembly Manual for
Battery-Operated Cars
Model:SX2388
TH17T1142
Products should be assembled by an adult. Protective equipment
should be worn. Do not use in traffic.Not suitable for children under 3
years. Choking hazard- small parts. In its unassembled state, it
contains potentially hazardous small parts. Please keep out of the
reach of young children. Be aware of the potential hazards when
using the toy in areas other than private property.
Executive standard：
EN71-1
EN71-2
EN71-3
EN62115
ASTM F963
Advertisement
Table of Contents
Related Manuals for HOLLICY SX2388
Summary of Contents for HOLLICY SX2388
- Page 1 EN71-2 Assembly Manual for EN71-3 Battery-Operated Cars EN62115 Model:SX2388 ASTM F963 TH17T1142 Products should be assembled by an adult. Protective equipment should be worn. Do not use in traffic.Not suitable for children under 3 years. Choking hazard- small parts. In its unassembled state, it contains potentially hazardous small parts.
- Page 2 Parts Parts Picture Picture Name Name Steering Car body ❶ ❷ wheel Front axle Rear ❸ ❹ component axle Steering Front ❺ ❻ axle wheel Rear Wheel ❽ ❼ wheel cover Foot rest Foot rest metal ❿ ❾ component Wrench ⓬...
- Page 3 ❷ ❶ ❼ ❽ ❼ ❹ ❿ ❿ ❾ ❽ ❾ ❽ ❸ ❽ ❻ ❻ ❺ ⓬ ⓭ ⓯ Needle-nose pliers (Not Included) ⓫...
- Page 4 Warning This product is not the vehicle for transportation, it should be used under adult guidance. Please refer to the actual product. Warning: This product is not a transportation vehicle and should be used under adult supervision. Parents should ensure that children have taken the safety measures before use.
-
Page 5: Assembly Instruction
Assembly instruction Car assembling should be performed by the adults. Handle small parts with care.To avoid choking hazards, keep children away during assembly. Children under 36 months are prohibited from using this product. Please carefully count all parts before assembly and properly dispose of the plastic bag.To avoid choking hazard, children are not allowed to play with the bag. -
Page 6: Front Wheel Assembly
3.Completed front axle assembly Attach the completed front axle to the correct position on car body ❶using the Phillips screwdriver, tighten them with 8 pieces M4*16 black truss head screw as shown in the pictures. M4*16 black truss head screw Completed front axle ❶... - Page 7 5.Rear axle & motor assembly Using the wrench ⓫, remove two lock nuts from rear axle, then remove two M10 washers, setting them aside for later use.Cut off the tie-wraps from two motors, insert the rear axle ❹ into the holes on the motors.
-
Page 8: Foot Rest Assembly
7.Foot rest metal component assembly Attach two foot rest metal components to the correct posi- ⓫ tion under car body, using the Phillips screwdriver, tighten them with 6 pieces M4*10 truss head screw as shown in the pictures . M4*10 truss head screw ⓫... -
Page 9: Steering Wheel Assembly
9.Steering axle assembly Thread the steering axle ❺ through the hole on steering motor and car body, insert the hook on steering axle ❺ with the hole on front axle , add a M10 washer, then insert the cotter pin into the hole on hook, using a needle-nose pliers, open the cotter pin as shown in pictures. -
Page 10: Battery Connection
11.Battery connection Before first use, remove two screws from the seat using a Phillips screwdriver, setting them aside for later. Then open the seat, connect two red plugs to establish a connection with the battery. Close the seat and secure it using two screws and a Phillips screwdriver. -
Page 11: Security Warning
SECURITY WARNING 1.The installation and charging of vehicle should always be supervised by an adult. 2.This product is limited to the children from 37 to 95 months,never allow more than 2 riders, the maximum load is 45KG for one kid, 90KG for two kids. - Page 12 USAGE DIRECTION 1. Before using it, ensure the following have been completed. ●Follow the steps outlined in the instructions to complete the car's installation, ensure the battery is connected,the power supply has been switched on. ●Ensure that all screw positions are securely tightened. ●Parents or guardian should ensure children have taken the necessary safety measures before use.
- Page 13 2、Operating(function reference diagram) To ensure MP3 player orn button High / low speed Inner pedal Inner pedal / outer Forward pedal switch / Reverse Outer pedal Power on / off switch （optional） Electric capacity display Big memory Mode Early education / Music / Volume up Story / Pause / Play Volume down...
-
Page 14: Remote Control Instruction
Remote control instruction Speed indicator Stop Forward Right Speed Back Left Code 2.4G Remoter Control Instructions For the first time need to code,this product has a memory function, so you won't need to match the code again after replacing the battery. ①.Long press "M"... - Page 15 WARNING: 1 . When operating the car, the distance between the car , with the child inside, and the remote control operated by an adult should not exceed 10 meters. 2 .The remote control is for adult use only; keep it out of the reach of children.
- Page 16 CHARGING WAY ● Before first use, open the seat, connect two red plugs to establish a connection with the battery, and charge it for 8-12 hours. ● Charging port is located near the seat, follow the charging steps as shown in the following pictures. ●...
-
Page 17: Maintenance And Service
MAINTENANCE AND SERVICE 1. Before use, parents should check whether all parts such as batteries, charger, wires, plug, outer body and other parts are in good condition, and ensure that screws are tight and that there are no potential safety hazards. -
Page 18: Troubleshooting
TROUBLESHOOTING If “power” switch is in OFF position If the fuse is not functioning properly Car does not If the battery is not connected, check the red and black wires. move or power on If the charger is plugged in, car will not power on. Unplug charger. If the pedal switch is not functioning properly If the wheels are stuck and cannot move If the battery is not fully charged. - Page 19 WARNING: This toy contains non-replaceable batteries. Adult supervision of young children is recommended. WARNING: Adult supervision is required to reduce the risk of injury. Never use in roadways, near motor vehicles, on or near steep inclines of steps, swimming pools or other bodies of water, always wear shoes, and never allow more 2 riders.
- Page 20 PINGHU SHUANGXI BABY CARRIER MANUFACTURE CO.,LTD. PINGHU BABY CARRIER INDUSTRY CITY, ZHEJIANG, CHINA...
